Quick Details
-
Brand Name:
-
VANJOIN
-
Model Number:
-
VJ7
-
Surface board:
-
5mm calcium silicate board
-
Inner materials:
-
EPS ,cement ,sand, fly ash
-
Fire rate:
-
4 hours
-
Windload:
-
65m/s
-
Anti-earthquake:
-
9 degree
-
Usage:
-
interior/exterior wall ,flooring ,roofing
-
Construction Speed:
-
2 workers can install 50-80m2 per day
-
Product name:
-
Prefabricated House EPS Concrete Wallboard Cement Sandwich Wall Panel
-
Cerificates:
-
CE, ISO, SGS, SASO, BV, Patent
Quick Details
-
Project Solution Capability:
-
NONE
-
Application:
-
Hotel, Villa, Apartment, Office Building, Hospital, School, Mall, Sports Venues, Leisure Facilities, Supermarket, Warehouse, Workshop, Park, Farmhouse, Courtyard
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
VANJOIN
-
Model Number:
-
VJ7
-
Surface board:
-
5mm calcium silicate board
-
Inner materials:
-
EPS ,cement ,sand, fly ash
-
Fire rate:
-
4 hours
-
Windload:
-
65m/s
-
Anti-earthquake:
-
9 degree
-
Usage:
-
interior/exterior wall ,flooring ,roofing
-
Construction Speed:
-
2 workers can install 50-80m2 per day
-
Product name:
-
Prefabricated House EPS Concrete Wallboard Cement Sandwich Wall Panel
-
Cerificates:
-
CE, ISO, SGS, SASO, BV, Patent
Free Samples are available for you!
Precast Concrete Lightweight Straw Ceramsite Cement Wall Panel
Brief Description of Vanjoin Sandwich Panels
|
Type |
EPS Sandwich wall panel |
|
Material |
Face boards are calcium silicate board, inner materials are eps foam, cement, sand, etc. |
|
Size |
Standard length 2270mm, width 610mm, thickness 60mm,75mm,90mm,100mm,120mm,150mm. |
|
Application |
External and internal wall for various low houses and high buildings |
|
Joining Method |
Tongue & groove type with cement mortar |
|
Supply ability |
300,000m2 per month. |
|
Delivery time |
Within 7 working days after receiving prepayment basis on MOQ. |
|
Payment terms |
T/T, L/C. |
|
Packing |
Standard exporting good quality packing |
|
Samples |
Free samples are available. |
|
Certificates |
CE,ISO,SGS,BV, with test reports and patents |
Types and Composition
Types:
EPS cement sandwich wall panel
Ceramicite sandwich wall panel
EPS&ceramicite sandwich wall panel
Composition:
Face board: 5mm calcium siliate board
Inner materials: EPS,cement,sand,additives
Specification &Weight & loading quantity of Vanjoin Sandwich Wall Panels
| Size (mm) | Weight (kg/m2) | Loading Quantity (m2/pcs) |
| 2270*610*60 | 45-48 | 436/315 |
| 2270*610*75 | 50-53 | 349/252 |
| 2270*610*90 | 55-58 | 287/207 |
| 2270*610*100 | 60-65 | 262/189 |
| 2270*610*120 | 65-75 | 212/153 |
| 2270*610*150 | 80-90 | 175/126 |
Outstanding Advantages of Vanjoin Sandwich Wall Panels
|
Lightweight |
1 person can carry panel easily |
|
Eco-friendly |
100% non-asbestos |
|
Fast Construction |
3 workers can install 60-80m2 per day |
|
Strong,Durable, Long Lifespan |
70 years |
|
Sound Insulation |
over 46dB |
|
Windproof |
65m/s |
|
Fireproof |
4 hours |
|
Anti-earthquake |
Grade 8-9 |
|
Best hanging force |
Single point hanging force is 50kg |
|
Weight capacity |
650kg / m3 |
Packing & Loading of Vanjoin Sandwich Wall Panels
Standard exporting packing
(wrapped with plastic thin film,p olyethylene foamed sheet,edge protect,packing belt,solid pallets). 18 pallets in a 20'GP
Application of VanjoinSandwich Wall Panels
Exterior wall, interior wall, flooring panel and roofing panel for low houses and high - rise buildings
Vanjoin Factory ( Top and Professional Manufacturer)
Production area: 80,000m2
Stacking area: 100,000m2
Production capacity: 3,000,000m2 per year
Export quantity: over 600 containers per month
Projects of Vanjoin Sandwich Wall Panels
Prefab house, prefab villa, prefab commercial building, prefab residential apartment,etc.
Certification of Vanjoin Sandwich Wall Panels
CE,SGS,BV,ISO9001:2008,ISO14001:2004,SASO,Patent,etc.
Vanjoin Customers
Our customers are from Philippines, Thailand, India, Nepal, Indonesia, Maldives,Malaysia,Iraq, Saudi Arabia, Portugal, Sweden,Cyprus,Irland,Russia, Brazil, Bolivia,Uruguay,Venezuela, Mexico, Costa Rico,Chile,Panama,Angola,Kenya,Nigeria,South Africa,etc.
Vanjoin Sales Team
Vanjoin sales team is the best and most professional team, you first choice.
We are also the professional supplier of wall panel production line and soft ceramic tile.
