Quick Details
-
Oiled or Non-oiled:
-
Non-oiled
-
Invoicing:
-
by theoretical weight
-
Place of Origin:
-
CHN
-
Brand Name:
-
HX
-
Outer Diameter:
-
0 - 100 mm
-
Thickness:
-
Customized
-
Grade:
-
Carbon Steel
-
Product name:
-
pre galvanized steel pipes
-
Zinc coating:
-
Z30-150g/m2
-
Sample:
-
free offer
-
Ends:
-
Plain, bevelled, threaded with coupling
-
Business type:
-
Manufacturer
-
Type:
-
Welded Steel Pipe
-
Keyword:
-
Galvanzied Steel Pipe
-
MOQ:
-
One 20GP Container
-
Wall Thickness:
-
Customized
Quick Details
-
Section Shape:
-
Round
-
Surface Treatment:
-
galvanized
-
Tolerance:
-
±1%
-
Oiled or Non-oiled:
-
Non-oiled
-
Invoicing:
-
by theoretical weight
-
Place of Origin:
-
CHN
-
Brand Name:
-
HX
-
Outer Diameter:
-
0 - 100 mm
-
Thickness:
-
Customized
-
Grade:
-
Carbon Steel
-
Product name:
-
pre galvanized steel pipes
-
Zinc coating:
-
Z30-150g/m2
-
Sample:
-
free offer
-
Ends:
-
Plain, bevelled, threaded with coupling
-
Business type:
-
Manufacturer
-
Type:
-
Welded Steel Pipe
-
Keyword:
-
Galvanzied Steel Pipe
-
MOQ:
-
One 20GP Container
-
Wall Thickness:
-
Customized
Product Description
|
COMMODITY NAME
|
GALVANIZED CARBON STEEL PIPE/ TUBE
|
|
MATERIAL GRADE
|
Q195 = S195 / A53 Grade A
|
|
PIPE SURFACE
|
GALVANIZED (zinc coated)
|
|
ZINC COATING
|
30 G/M2 ( OR CUSTOMIZED)
|
|
PIPE ENDS
|
PLAIN ENDS / BEVEL ENDS WITH PLASTIC CAPS/ THREADED BOTH ENDS WITH COUPLING AND CAPS/ GROOVED ENDS
|
|
CERTIFICATES
|
ISO 9001/CE/UL/FM/SGS
|
|
TRADE TERMS
|
FOB/ CFR/ CIF/ EXW/ FCA
|
|
PAYMENT TERMS
|
30%&70% T/T ; 100% LC AT SIGHT (others can be negotiated)
|
|
DELIVERY TIME
|
30 DAYS AFTER RECEIVE DEPOSIT OR LC
|
|
BRAND
|
HAOXUAN
|
|
HOT SALES MARKET
|
Southeast Asia, South Asia, Middle East, Europe, Middle&South America, Africa and Oceania
|
|
Size
|
Diameter
(mm) |
Thickness
(mm) |
Szie
(mm) |
Thickness
(mm) |
Size
(mm) |
Thickness
(mm) |
|
1/2"
|
20
|
0.8-2.2
|
20*40
|
0.8-2.0
|
16*16
|
0.8-1.5
|
|
3/4"
|
25
|
0.8-2.2
|
25*50
|
0.8-2.0
|
19*19
|
0.8-2.0
|
|
|
25.4
|
0.8-2.2
|
30*40
|
0.8-2.0
|
20*20
|
0.8-2.0
|
|
1"
|
32
|
0.8-2.2
|
30*50
|
0.8-2.0
|
25*25
|
0.8-2.0
|
|
|
38
|
1.0-2.2
|
37*57
|
0.8-2.0
|
30*30
|
0.8-2.0
|
|
11/4"
|
40
|
1.0-2.2
|
40*60
|
0.8-2.0
|
32*32
|
0.8-2.0
|
|
|
42
|
1.0-2.3
|
37*77
|
0.8-2.0
|
35*35
|
0.8-2.0
|
|
11/2"
|
47
|
1.0-2.3
|
25*75
|
0.9-2.0
|
38*38
|
0.8-2.0
|
|
|
48
|
1.0-2.3
|
40*80
|
1.0-2.2
|
40*40
|
0.8-2.0
|
|
2"
|
59
|
1.0-2.3
|
50*100
|
1.0-2.2
|
50*50
|
0.8-2.2
|
|
|
60.3
|
1.0-2.3
|
50*75
|
1.0-2.2
|
60*60
|
1.0-2.2
|
|
2 1/2"
|
75
|
1.0-2.3
|
38*75
|
1.0-2.2
|
75*75
|
1.0-2.2
|
|
3"
|
87
|
1.0-2.3
|
50*150
|
1.3-2.2
|
80*80
|
1.0-2.2
|
Hot-dip galvanizing pipe reacts molten metal with an iron matrix to produce an alloy layer, thereby combining the matrix and the coating.
In order to make the galvanized pipe better connected, the galvanized steel pipe can be bent, grooved, drilled and other processing techniques.
The process flow is: clarinet - alkali washing - water washing - pickling - water rinsing - dipping agent - drying - hot dip galvanizing - external blowing - internal blowing - air cooling - water cooling - Passivation - Water rinsing - Inspection - Weighing - Storage.
Hot-dip galvanized steel pipes are widely used in construction, machinery, coal mines, chemical industry, electric power, railway vehicles, automobile industry, highways, bridges, containers, sports facilities, agricultural machinery, petroleum machinery, prospecting machinery, greenhouse construction and other manufacturing industries.
