Quick Details
-
Product Name:
-
IP Camera Module
-
Resolution:
-
H.265 5 Mega Pixel
-
Image Sensor:
-
1/2.8" Sony IMX335
-
Human body Detection:
-
Support
-
WiFi and TF Card Slot:
-
Optional
-
Motorized Lens:
-
Support
-
PoE Board:
-
Support
-
DSP:
-
HI3516EV300
-
Board Size:
-
38*38mm (single pcb)
-
Style:
-
PCBA
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
TT
-
Model Number:
-
TT-IP5MC
-
Product Name:
-
IP Camera Module
-
Resolution:
-
H.265 5 Mega Pixel
-
Image Sensor:
-
1/2.8" Sony IMX335
-
Human body Detection:
-
Support
-
WiFi and TF Card Slot:
-
Optional
-
Motorized Lens:
-
Support
-
PoE Board:
-
Support
-
DSP:
-
HI3516EV300
-
Board Size:
-
38*38mm (single pcb)
-
Style:
-
PCBA
Product Description
|
Product Name
|
5.0mp IP Camera Module
|
|
Model
|
TT-IP5MC
|
|
Function
|
Onvif, TF Card Optional, Wifi Optional, Motorized Lens Optional, PoE Optional
|
Major Features
1/2.8" 5.0mp Sony CMOS Sensor
Support H.265/H.264
Support 3-Stream
Main Stream: 2560*1920 / 2560*1440 / 2304*1296 / 1920*1080 / 1280*720
Sub-Stream 1: 448P (800 * 448) / 704 * 576 / 640 * 360 / 352 * 288;
Sub-Stream 2: 640 * 360 / 352 * 288
Support WDR, 3D-NR, BLC, AWB.
Support ONVIF protocol, can access any third-party NVR
Support ICR filter for Day/Night Function
Support Screen Mast, 4 blocks.
Support Audio Input
Support Motion Detection, Mobile detection alarm automatically send email alert
Support OSD, Support network time;
Support Mobile Smart Phone Monitoring (iOS, Android), Web, VMS
Support automatic maintenance function;
Support PoE power supply (optional);
Support FTP function;
Supports electrodeless infrared dimming, electrodeless white light dimming
Support H.265/H.264
Support 3-Stream
Main Stream: 2560*1920 / 2560*1440 / 2304*1296 / 1920*1080 / 1280*720
Sub-Stream 1: 448P (800 * 448) / 704 * 576 / 640 * 360 / 352 * 288;
Sub-Stream 2: 640 * 360 / 352 * 288
Support WDR, 3D-NR, BLC, AWB.
Support ONVIF protocol, can access any third-party NVR
Support ICR filter for Day/Night Function
Support Screen Mast, 4 blocks.
Support Audio Input
Support Motion Detection, Mobile detection alarm automatically send email alert
Support OSD, Support network time;
Support Mobile Smart Phone Monitoring (iOS, Android), Web, VMS
Support automatic maintenance function;
Support PoE power supply (optional);
Support FTP function;
Supports electrodeless infrared dimming, electrodeless white light dimming
Product Specifications
|
Camera
|
|
|
|
DSP
|
Hi-3516EV300
|
|
|
Sensor
|
1/2.8” Sony CMOS Sensor IMX335
|
|
|
Functions
|
|
|
|
Day/Night
|
Support IRC
|
|
|
Shutter
|
1/25-1/10000
|
|
|
White balance
|
Automatic White Balance (AWB)
|
|
|
BLC
|
Support Backlight Compensation (BLC)
|
|
|
Digital noise reduction
|
Support 3D Noise Reduction (3D-NR)
|
|
|
Wide dynamic
|
Support for Digital Wide Dynamics (WDR)
|
|
|
Motion Detection
|
Support Motion Detection
|
|
|
Privacy mask
|
Support for 4 areas
|
|
|
Mirror
|
Support Mirror Image
|
|
|
OSD
|
Support OSD Settings, OSD interface free moving
|
|
|
Timed restart
|
Support for scheduled restart
|
|
|
Video
|
|
|
|
Compression
|
H.265/H.264；
|
|
|
Resolution
|
Main Stream: 2560*1920 / 2560*1440 / 2304*1296 / 1920*1080 / 1280*720
|
|
|
|
Sub-Stream 1: 448P (800 * 448) / 704 * 576 / 640 * 360 / 352 * 288
|
|
|
|
Sub-Stream 2: 640 * 360 / 352 * 288
|
|
|
Video Frame Rate
|
15fps(50HZ), 15fps(60HZ)
|
|
|
Bit Rate
|
128Kbps~12Mbps CBR/VBR adjustable
|
|
|
Video Adjustment
|
Brightness, Saturation, Chroma, Contrast, Sharpness Adjustment
|
|
|
Ethernet
|
RJ-45 (10/100Base-T)
|
|
|
Wi-Fi
|
Optional
|
|
|
Network Protocol
|
HTTP, TCP/IP, IPv4, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, IP Search (Support P6S IP camera, DVR, NVS and etc.)
|
|
|
Access Protocol
|
Support ONVIF 2.4/P6S Private Protocol / Hikvision Protocol
|
|
|
Maximum No. of Users
|
4
|
|
|
Client
|
iPhone, iPad, Android, Windows
|
|
|
Audio
|
|
|
|
Audio
|
G.711U
|
|
|
Audio Input
|
1 Channel Audio Input
|
|
|
Audio Output
|
1 Channel Audio Output
|
|
|
General
|
|
|
|
Board Size
|
38 * 38 Single Layer PCB
|
|
|
Temp. and Hum.
|
-20℃～+65℃
|
|
|
Power
|
DC12V 5W
|
|
