Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
FST
-
Single Pulse Energy:
-
80-120J
-
Pulse Width:
-
0.1-10ms
-
Wavelength:
-
1070nm
-
Focal Spot Diameter:
-
0.2-2mm
-
Dimensions:
-
550*940*680mm
-
Weight (KG):
-
122 KG
-
Core Components:
-
laser power
-
Model:
-
Fiber laser welding machine
-
Laser wavelength:
-
1070nm
-
Laser power:
-
1000W/1500W/2000W/3000W
-
Operating mode:
-
Continuo us/pulse
-
Length of fiber-optical:
-
10m(standard)
-
Interface of fiber-optical:
-
QBH
-
Module life:
-
100000hrs
-
Power supply:
-
220V/380V
-
Cooling method:
-
Water Cooling
-
Laser Energy Stability:
-
<2%
Quick Details
-
Max. Output Power:
-
3000w
-
Use:
-
metal welding
-
Laser Source Brand:
-
Raycus/JPT/IPG/MAX
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
FST
-
Single Pulse Energy:
-
80-120J
-
Pulse Width:
-
0.1-10ms
-
Wavelength:
-
1070nm
-
Focal Spot Diameter:
-
0.2-2mm
-
Dimensions:
-
550*940*680mm
-
Weight (KG):
-
122 KG
-
Core Components:
-
laser power
-
Model:
-
Fiber laser welding machine
-
Laser wavelength:
-
1070nm
-
Laser power:
-
1000W/1500W/2000W/3000W
-
Operating mode:
-
Continuo us/pulse
-
Length of fiber-optical:
-
10m(standard)
-
Interface of fiber-optical:
-
QBH
-
Module life:
-
100000hrs
-
Power supply:
-
220V/380V
-
Cooling method:
-
Water Cooling
-
Laser Energy Stability:
-
<2%
Product description
Product Details
Application Industry
|
Model
|
Fiber laser welding machine
|
|
Laser wavelength
|
1070nm
|
|
Laser power
|
1000W/1500W/2000W
|
|
Operating mode
|
Continuous/pulse
|
|
Length of fiber-optical
|
10m(standard)
|
|
Interface of fiber-optical
|
QBH
|
|
Module life
|
100000hrs
|
|
Power supply
|
220V / 380V
|
|
Cooling method
|
Water Cooling
|
|
Laser Energy Stability
|
<2%
|
|
Air humidity
|
10-90%
|
|
Recommended welding thickness
|
1000W Stainless steel, carbon steel 0-2mm
|
|
Red light positioning
|
Support
|
|
Recommended welding thickness
|
|
|
|
|
||||
|
1000W
|
Stainless steel, carbon steel 0-2mm, Galvanized sheet, aluminum 0-1.5mm
|
|
|
|
||||
|
1500W
|
Stainless steel, carbon steel 0-3mm, Galvanized sheet, aluminum 0-2mm
|
|
|
|
||||
|
2000W
|
Stainless steel, carbon steel 0-4mm, Galvanized sheet, aluminum 0-3mm
|
|
|
|
||||
|
3000W
|
Stainless steel, carbon steel 0-6mm, Galvanized sheet, aluminum 0-4mm
|
|
|
|
||||
