Quick Details
-
Model Number:
-
Coriolis mass flow meter
-
Product Name:
-
Endress+Hauser Coriolis Proline Promass E 300 Flowmeter
-
Accuracy:
-
± 0.05% FS
-
Application:
-
Industrial Process Control
-
Pressure type:
-
Differential Presssure (D)
-
Pressure range:
-
-100kPa ~ 0 ~ 5KPa ... 100MPa
-
Power supply:
-
24VDC
-
Output signal:
-
RS 458
-
Keywords:
-
mass flow meter
-
Housing material:
-
316
-
Display:
-
LCD Digital
Quick Details
-
Type:
-
Variable Area Oil Flowmeters
-
Place of Origin:
-
Shaanxi, China
-
Brand Name:
-
E+H
-
Model Number:
-
Coriolis mass flow meter
-
Product Name:
-
Endress+Hauser Coriolis Proline Promass E 300 Flowmeter
-
Accuracy:
-
± 0.05% FS
-
Application:
-
Industrial Process Control
-
Pressure type:
-
Differential Presssure (D)
-
Pressure range:
-
-100kPa ~ 0 ~ 5KPa ... 100MPa
-
Power supply:
-
24VDC
-
Output signal:
-
RS 458
-
Keywords:
-
mass flow meter
-
Housing material:
-
316
-
Display:
-
LCD Digital
Endress+Hauser Proline Promag H 300 Electromagnetic Flowmeter Flow Meter
Endress hauser E + H Coriolis mass flow meter is a high – accuracy digital and intellectual product meet the market needs of Chinese mainland. This series of product adopt sensor chip with highest performance and are designed incorporating with monolithic computer technology and sensor digital conversion technology, of which core component adopts 24–bit AD MCU micro – processor to ensure high quality of the transducer relying on its strong function and high – speed operation capacity. The overall designed framework is to meet the requirements of increasingly enhanced industrial site application with a view to reliability, stability, high accuracy, and intellectualization. Meanwhile, the supporting software of the product also features strong function and without manually operating device to ensure good interaction. Application digital signal processing technology is made for good disturbance immunity. It also features zero point automatic stable follow – up capacity and temperature automatic compensation capacity.
|
1. National defense scientific research |
5. Scientific research and laboratory calibration |
|||||||||
|
2. Nuclear power generation and chemical |
6. Petroleum survey and investigation |
|||||||||
|
3. Military |
7. High – end equipment accessories |
|||||||||
|
4. Airspace and aerospace |
8. Support for engineering projects |
|||||||||
|
|
|
|||||||||
|
Technical Data |
||||||||||
|
Measuring range |
-100kPa ~ 0 ~ 5KPa … 100MPa |
|||||||||
|
Overloading capacity |
Two times of FS pressure (where over pressure for 100MPa is designed with 1.1 times of FS pressure) |
|||||||||
|
Pressure type |
Gauge pressure or absolute pressure |
|||||||||
|
Medium to be measured |
The gas or liquid compatible with 316 stainless steel |
|||||||||
|
Overall accuracy |
±0.05% FS |
± 0.075% FS |
± 0.1% FS |
± 0.25% FS |
||||||
|
Long-term stability |
Typical: ± 0. 0 1% FS / year |
Maximum: ± 0. 0 2% FS / year |
||||||||
|
Zero point temperature drifting |
Typical: ± 0.005% FS |
Maximum: ± 0.01% FS / ℃ |
||||||||
|
Sensitivity temperature drifting |
Typical: ± 0.005% FS |
Maximum: ± 0.01% FS / ℃ |
||||||||
|
Range of operating temperature |
-40 ~ 85 ℃ |
|||||||||
|
Range of compensating temperature |
-10 ~ 60 ℃ |
|||||||||
|
R ange of ambient temperature |
-20~60 ℃ |
|||||||||
|
Range of power supplying |
5 ~ 9V DC (generally 5VDC) |
|||||||||
|
Digital output |
RS485 / USB / RS232 |
|||||||||
|
Baud rate |
1200 , 2400 , 9600 , 19200 , 28800 , 57600 , 115200 , 230400 |
|||||||||
|
Data format |
1–bit start bit, 8–bit data bit, 1–bit stop bit |
|||||||||
|
Odd and even calibration |
None |
|||||||||
|
Sampling rate |
10 points / second – 1 point / 50 minutes |
|||||||||
|
Thermal lagging |
± 0.1% FS (typical) |
|||||||||
|
Insulation resistance |
100MΩ, 500V DC |
|||||||||
|
Response time |
≤2ms |
|||||||||
|
Enclosure protection degree |
P lug type: IP65 -IEC60529; cable type: IP67 -IEC60529 |
|||||||||
|
S afe e xplosion – proof |
Ex ia II CT5 |
|||||||||
|
Pressure connection |
See product selection table and process connecting drawing (may be defined by the customer). |
|||||||||
|
Electrical wiring connection |
See product selection table and process connecting drawing (may be defined by the customer). |
|||||||||
|
Tolerance of vibration |
≤ ± 0.01% FS(Axles X, Y, and Z, 200Hz / g) |
|||||||||
|
Material of structure |
Membrane: 316L;Enclosure:1Cr18Ni9Ti stainless steel |
Enclosure: 1Cr18Ni9Ti stainless steel |
||||||||
|
• • • Features of Product • • • |
|
• • • Application of Product • • • |
||||||||
|
1. Baud rate from 1200 to 230400 bps |
|
1. 20 – bit effective resolution |
||||||||
|
2.Overall accuracy up to ± 0.05% FS under special condition |
|
2. Absolute pressure, gauge pressure, and differential pressure |
||||||||
|
3. Optional many kinds of pressure unit, may be user – defined |
|
3. Zero point and FS output setting |
||||||||
|
4. Sampling rate form 10 points / second to 1 point / 50 minutes |
|
4. Readable temperature value of the medium to be measured |
||||||||
|
5. RS 485 universal serial bus (USB) loop may connected with 63 sensor, as a maximal |
|
|
||||||||
|
6. Communication with the computer via control software in Chinese as well as USB, RS - 232 / 485 port, with easy operation |
||||||||||
|
7. Provided with micro – processor for digital compensation, control, and communication 8.USB, RS - 232 / 485 port directly connecting with the computer |
||||||||||
