Quick Details
-
Number of Row:
-
Single row
-
Model Number:
-
SUE204
-
Seals Type:
-
SL/TJ Type Seal
-
Place of Origin:
-
Fujian, China
-
Material:
-
Stainless steel 440, heat treated
-
Load type:
-
Standard duty
-
Locking style:
-
Concentric locking
-
Feature:
-
Wider inner ring, with food grade grease and silicon rubber seals
-
Certificate:
-
IATF 16949(BV) /ISO14001/ISO45001
-
Service:
-
OEM Customized Services
Quick Details
-
Applicable Industries:
-
Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Home Use, Retail, Printing Shops, Construction works , Energy & Mining
-
Bore Size:
-
20 - 60 mm
-
Precision Rating:
-
High precision
-
Number of Row:
-
Single row
-
Model Number:
-
SUE204
-
Seals Type:
-
SL/TJ Type Seal
-
Place of Origin:
-
Fujian, China
-
Material:
-
Stainless steel 440, heat treated
-
Load type:
-
Standard duty
-
Locking style:
-
Concentric locking
-
Feature:
-
Wider inner ring, with food grade grease and silicon rubber seals
-
Certificate:
-
IATF 16949(BV) /ISO14001/ISO45001
-
Service:
-
OEM Customized Services
Product Description
1.Spherical Bearing SUE Series
| Bearing No. | Shaft Dia | Dimensions (mm) |
Load rating
( KN ) |
Weight (kg) | |||||||||||
| d | D | B | C | S | S1 | B1 | B2 | d1 | ds | Ca | Dynamic | Static | |||
| (in) | (mm) | Cr | Cor | ||||||||||||
| SUE204 | 20 | 47 | 31 | 17 | 12.7 | 18.3 | 33.0 | 9.5 | 40.8 | M4X0.7 | 4.3 | 12.82 | 6.65 | 0.18 | |
| SUE204-12 | 3/4 | 47 | 31 | 17 | 12.7 | 18.3 | 33.0 | 9.5 | 40.8 | M4X0.7 | 4.3 | 0.18 | |||
| SUE205 | 25 | 52 | 34.1 | 17 | 14.3 | 19.8 | 35.4 | 9.5 | 49.0 | M4X0.7 | 4 | 14.03 | 8.05 | 0.21 | |
| SUE205-13 | 13/16 | 52 | 34.1 | 17 | 14.3 | 19.8 | 35.4 | 9.5 | 49.0 | M4X0.7 | 4 | 0.21 | |||
| SUE205-14 | 7/8 | 52 | 34.1 | 17 | 14.3 | 19.8 | 35.4 | 9.5 | 49.0 | M4X0.7 | 4 | 0.21 | |||
| SUE205-15 | 15/16 | 52 | 34.1 | 17 | 14.3 | 19.8 | 35.4 | 9.5 | 49.0 | M4X0.7 | 4 | 0.21 | |||
| SUE205-16 | 1 | 52 | 34.1 | 17 | 14.3 | 19.8 | 35.4 | 9.5 | 49.0 | M4X0.7 | 4 | 0.21 | |||
| SUE206 | 30 | 62 | 38.1 | 19 | 15.9 | 22.2 | 39.8 | 9.5 | 55.5 | M4X0.7 | 5.3 | 19.47 | 11.43 | 0.33 | |
| SUE206-17 | 1-1/16 | 62 | 38.1 | 19 | 15.9 | 22.2 | 39.8 | 9.5 | 55.5 | M4X0.7 | 5.3 | 0.33 | |||
| SUE206-18 | 1-1/8 | 62 | 38.1 | 19 | 15.9 | 22.2 | 39.8 | 9.5 | 55.5 | M4X0.7 | 5.3 | 0.33 | |||
| SUE206-19 | 1-3/16 | 62 | 38.1 | 19 | 15.9 | 22.2 | 39.8 | 9.5 | 55.5 | M4X0.7 | 5.3 | 0.33 | |||
| SUE206-20 | 1-1/4 | 62 | 38.1 | 19 | 15.9 | 22.2 | 39.8 | 9.5 | 55.5 | M4X0.7 | 5.3 | 0.33 | |||
| SUE207 | 35 | 72 | 42.9 | 20 | 17.5 | 25.4 | 43.9 | 11.0 | 64.0 | M5x0.8 | 5.8 | 25.69 | 15.55 | 0.51 | |
| SUE207-20 | 1-1/4 | 72 | 42.9 | 20 | 17.5 | 25.4 | 43.9 | 11.0 | 64.0 | M5x0.8 | 5.8 | 0.51 | |||
| SUE207-21 | 1-5/16 | 72 | 42.9 | 20 | 17.5 | 25.4 | 43.9 | 11.0 | 64.0 | M5x0.8 | 5.8 | 0.51 | |||
| SUE207-22 | 1-3/8 | 72 | 42.9 | 20 | 17.5 | 25.4 | 43.9 | 11.0 | 64.0 | M5x0.8 | 5.8 | 0.51 | |||
| SUE207-23 | 1-7/16 | 72 | 42.9 | 20 | 17.5 | 25.4 | 43.9 | 11.0 | 64.0 | M5x0.8 | 5.8 | 0.51 | |||
| SUE208 | 40 | 80 | 49.2 | 21 | 19.0 | 30.2 | 50.2 | 11.0 | 68.0 | M5X0.8 | 6.2 | 29.51 | 18.14 | 0.68 | |
| SUE208-24 | 1-1/2 | 80 | 49.2 | 21 | 19.0 | 30.2 | 50.2 | 11.0 | 68.0 | M5X0.8 | 6.2 | 0.68 | |||
| SUE208-25 | 1-9/16 | 80 | 49.2 | 21 | 19.0 | 30.2 | 50.2 | 11.0 | 68.0 | M5X0.8 | 6.2 | 0.68 | |||
| SUE209 | 45 | 85 | 49.2 | 22 | 19.0 | 30.2 | 50.2 | 11.0 | 74.0 | M5X0.8 | 6.5 | 31.85 | 20.8 | 0.78 | |
| SUE209-26 | 1-5/8 | 85 | 49.2 | 22 | 19.0 | 30.2 | 50.2 | 11.0 | 74.0 | M5X0.8 | 6.5 | 0.78 | |||
| SUE209-27 | 1-11/16 | 85 | 49.2 | 22 | 19.0 | 30.2 | 50.2 | 11.0 | 74.0 | M5X0.8 | 6.5 | 0.78 | |||
| SUE209-28 | 1-3/4 | 85 | 49.2 | 22 | 19.0 | 30.2 | 50.2 | 11.0 | 74.0 | M5X0.8 | 6.5 | 0.78 | |||
| SUE210 | 50 | 90 | 51.6 | 24 | 19.0 | 32.6 | 52.6 | 14.5 | 81.0 | M6x1 | 7 | 34.99 | 23.7 | 0.85 | |
| SUE210-30 | 1-7/8 | 90 | 51.6 | 24 | 19.0 | 32.6 | 52.6 | 14.5 | 81.0 | M6x1 | 7 | 0.85 | |||
| SUE210-31 | 1-15/16 | 90 | 51.6 | 24 | 19.0 | 32.6 | 52.6 | 14.5 | 81.0 | M6x1 | 7 | 0.85 | |||
| SUE210-32 | 2 | 90 | 51.6 | 24 | 19.0 | 32.6 | 52.6 | 14.5 | 81.0 | M6x1 | 7 | 0.85 | |||
| SUE211 | 55 | 100 | 55.6 | 25 | 22.2 | 33.4 | 56.6 | 14.5 | 92.0 | M6x1 | 7.4 | 43.34 | 29.39 | 1.16 | |
| SUE211-32 | 2 | 100 | 55.6 | 25 | 22.2 | 33.4 | 56.6 | 14.5 | 92.0 | M6x1 | 7.4 | 1.16 | |||
| SUE211-33 | 2-1/16 | 100 | 55.6 | 25 | 22.2 | 33.4 | 56.6 | 14.5 | 92.0 | M6x1 | 7.4 | 1.16 | |||
| SUE211-34 | 2-1/8 | 100 | 55.6 | 25 | 22.2 | 33.4 | 56.6 | 14.5 | 92.0 | M6x1 | 7.4 | 1.16 | |||
| SUE211-35 | 2-3/16 | 100 | 55.6 | 25 | 22.2 | 33.4 | 56.6 | 14.5 | 92.0 | M6x1 | 7.4 | 1.16 | |||
| SUE212 | 60 | 110 | 65.1 | 27 | 25.4 | 39.7 | 66.6 | 17.5 | 103.0 | M8x1.25 | 7.6 | 47.68 | 33.43 | 1.59 | |
| SUE212-36 | 2-1/4 | 110 | 65.1 | 27 | 25.4 | 39.7 | 66.6 | 17.5 | 103.0 | M8x1.25 | 7.6 | 1.59 | |||
| SUE212-37 | 2-5/16 | 110 | 65.1 | 27 | 25.4 | 39.7 | 66.6 | 17.5 | 103.0 | M8x1.25 | 7.6 | 1.59 | |||
| SUE212-38 | 2-3/8 | 110 | 65.1 | 27 | 25.4 | 39.7 | 66.6 | 17.5 | 103.0 | M8x1.25 | 7.6 | 1.59 | |||
| SUE212-39 | 2-7/16 | 110 | 65.1 | 27 | 25.4 | 39.7 | 66.6 | 17.5 | 103.0 | M8x1.25 | 7.6 | 1.59 | |||
2.Special features
1) Material for chrome steel and stainless steel available
2)Low noise and high speed
3)Large load capacity
4)High quality and long life
5)OEM welcome
