- Product Details
- {{item.text}}
Quick Details
-
Power:
-
1.1KW ,220V/AC
-
Min. Lifting Height:
-
80mm
-
Table Size:
-
900*1426mm
-
Overall Dimensions:
-
1350*1960mm
-
Weight:
-
500 kg
-
Lift bottom plate size:
-
900X1426mm
-
Form size of the whole machine:
-
1275*1976mm
-
maximum working height:
-
3200mm
-
Minimum working height:
-
80mm
-
Access mode:
-
90°/180°
-
Lift speed:
-
80mm/s
-
maximum load:
-
350KG
-
control source:
-
220V/AC
-
power of motor:
-
1.1KW ,220V/AC
-
source:
-
220V/50HZ/25A
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
gradin
-
Power:
-
1.1KW ,220V/AC
-
Min. Lifting Height:
-
80mm
-
Table Size:
-
900*1426mm
-
Overall Dimensions:
-
1350*1960mm
-
Weight:
-
500 kg
-
Lift bottom plate size:
-
900X1426mm
-
Form size of the whole machine:
-
1275*1976mm
-
maximum working height:
-
3200mm
-
Minimum working height:
-
80mm
-
Access mode:
-
90°/180°
-
Lift speed:
-
80mm/s
-
maximum load:
-
350KG
-
control source:
-
220V/AC
-
power of motor:
-
1.1KW ,220V/AC
-
source:
-
220V/50HZ/25A
Product configuration sheet
|
Lift bottom plate size
|
900X1426mm
|
|
Form size of the whole machine
|
1275*1976mm
|
|
maximum working height
|
3200mm
|
|
Minimum working height
|
80mm
|
|
Access mode
|
90°/180°
|
|
Lift speed
|
80mm/s
|
|
maximum load
|
350KG
|
|
control source
|
220V/AC
|
|
power of motor
|
1.1KW 220V/AC
|
|
source
|
220W/50HZ/25A
|
|
|
|
Show the details
Way to install
No foundation pit installation, directly fixed to the concrete floor (in the case of outdoor application without bottom pit, the concrete floor under the platform shall not be lower than the surrounding ground)
External control device
The outbound call box is placed on the wall near the upper and lower stop floors of the equipment, and the remote control can also be selected
Emergency stop
Press the emergency button switch to control the machine operation
Hand operation
When the manual hydraulic valve is opened or the screw is manually rotated, the lifting base plate can be manually lowered.
Why Choose Us
Founded in 2000,Jinan Quentin Machinery Co., Ltd. is located in the capital city of Shandong province - Jinan city, well known for its developed machinery industry and convenient transportation(300 km from Qingdao port). We are a professional manufacturer specialized in R&D, manufacturing, sales and service of all kinds of aerial work platforms and hydraulic lift platforms. As one of the leading companies in vertical material transportation and aerial work platforms, we have been committing ourselves in providing our customers with safer, more convenient and more efficient products. We have a strong team with 39 R&D professionals, 132 veteran workers and 42 commercial experts. In 2016, our sales revenue reached 30,000,000 USD.
With an investment of 20,000,000 USD, our current production base covers 60,0000 square meters, equipped with assembling workshop, structure workshop, paint workshop,final product test field, hydraulic lab, electric lab, R&D center,administration center and staff apartments.
With more than 15 years of efforts, Jinan Quentin Machinery has become a leading company in the industry participating in establishing various national standards and industrial standards.We have been cooperating with several domestic machinery institutes with more than 60 patents.
Certifications
FAQ
1.Are you a factory or trading company?
Yes, we're factory with over 10 years exporting experience.
2. Do you offer OEM&ODM service?
Yes, like lifting capacity, lifting height, size of platform, painting color, logo, manual etc.
3. How can I get the after-sales service?
We offer Videos, Pictures, User Manual, Technical guidance and 24 hours online service
4.What's the quality warranty?
24 months. Spare parts provided freely within quality warranty.
