Quick Details
-
Brand Name:
-
Jonson
-
Model Number:
-
JX-20
-
Power (W):
-
20KW
-
Voltage (V):
-
380V
-
Type:
-
Induction heating boiler
-
Rated Power:
-
20KW
-
Electrical protection level:
-
33IP
-
Hot water temperature:
-
25-95 Celsius degree
-
Adapt to Ambient Temperature:
-
-20 ~ 40 Degrees Celsius
-
Adapt to Environmental Humidity:
-
Less Than or Equal to 95%
-
Structure:
-
Floor-standing
-
Rated Voltage:
-
380V
-
Heat conversion efficiency:
-
≥98%
-
plastic robot:
-
340V~430V
Quick Details
-
Warranty:
-
1 Year
-
Application:
-
Hotel, Outdoor, Garage, Commercial, Household
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Jonson
-
Model Number:
-
JX-20
-
Power (W):
-
20KW
-
Voltage (V):
-
380V
-
Type:
-
Induction heating boiler
-
Rated Power:
-
20KW
-
Electrical protection level:
-
33IP
-
Hot water temperature:
-
25-95 Celsius degree
-
Adapt to Ambient Temperature:
-
-20 ~ 40 Degrees Celsius
-
Adapt to Environmental Humidity:
-
Less Than or Equal to 95%
-
Structure:
-
Floor-standing
-
Rated Voltage:
-
380V
-
Heat conversion efficiency:
-
≥98%
-
plastic robot:
-
340V~430V
Jiangxin electromagnetic heating boiler has the following characteristics after transformation:
1. In the future, the power grid will replace the pipe network: reduce the heat loss, maintenance and construction capital investment of the public pipe network, without road excavation;
2. More than 50% electricity saving: three-dimensional integrated heating, "energy efficiency greater than 99, W (eddy current heating) S (short circuit heating) M (magnetic flux leakage heating);"
3. Intelligence: high degree of automation, with functions of remote APP detection and display of real-time data, high temperature alarm, remote switch on and off, and remote temperature adjustment, truly unattended;
4. Long life: It is designed and manufactured with industrial quality. The whole machine has a service life of 20 years. The system basically requires no maintenance, which is really a revolution in heating equipment;
5. Cost saving: heat storage water tank can be installed to use valley electric heating to reduce operating cost;
6. The unique patented technology of Valley Electric Storage transforms Valley Electric into 95 ℃ thermal energy storage "subverting revolution";
7. Zero emission of environmental protection: no open fire, no combustion, no waste, no harmful gas emission, no pollution, no noise, which is incomparable to coal-fired, oil fired and gas fired boilers;
8. Simple management: it has the technical advantages of one key start, digital input, simple operation, full automatic operation, etc;
9. Small size: modular combination, small floor area, reduced construction investment;
10. Safety and worry free: Based on the principle of heat generated by electromagnetic induction eddy current, water and electricity are completely separated, and there is no danger of electric leakage. It is safe to use.
Product Paramenters
|
rated power
|
Three-phase 20KW
|
|
Rated input current
|
27-30(A)
|
|
Rated output current
|
30-50(A)
|
|
Rated voltage frequency
|
AC 380V/50Hz-60Hz
|
|
Voltage adaptation range
|
constant power output at 300 ~ 400V
|
|
Adapt to ambient temperature
|
-20ºC~50ºC
|
|
working frequency
|
5~40KHz
|
|
Main circuit structure
|
Full bridge series resonance
|
|
Control System
|
DSP-based high-speed automatic phase-locking tracking control system
|
|
Application mode
|
Open application platform
|
|
monitor
|
Programmable digital display
|
|
start time
|
<1S
|
|
Instantaneous overcurrent protection time
|
≤2US
|
|
Power overload protection
|
130% instantaneous protection
|
