Ready Stock Longi Lr5-54hib-410m Solar Panel 410w Full Black Half Cut Perc Mono Solar Module In Europe
Ready Stock Longi Lr5-54hib-410m Solar Panel 410w Full Black Half Cut Perc Mono Solar Module In Europe
Ready Stock Longi Lr5-54hib-410m Solar Panel 410w Full Black Half Cut Perc Mono Solar Module In Europe
Ready Stock Longi Lr5-54hib-410m Solar Panel 410w Full Black Half Cut Perc Mono Solar Module In Europe
Ready Stock Longi Lr5-54hib-410m Solar Panel 410w Full Black Half Cut Perc Mono Solar Module In Europe
Ready Stock Longi Lr5-54hib-410m Solar Panel 410w Full Black Half Cut Perc Mono Solar Module In Europe
Ready Stock Longi Lr5-54hib-410m Solar Panel 410w Full Black Half Cut Perc Mono Solar Module In Europe
Ready Stock Longi Lr5-54hib-410m Solar Panel 410w Full Black Half Cut Perc Mono Solar Module In Europe

Ready Stock Longi Lr5-54hib-410m Solar Panel 410w Full Black Half Cut Perc Mono Solar Module In Europe

FOB Reference Price: Get Latest Price
≥80600 Pieces
US $0.2
≥411840 Pieces
US $0.19
≥1000000 Pieces
US $0.16
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Warranty:
25 years warranty
Brand Name:
Longi
Model Number:
LR5-54HTB 435-445M
Place of Origin:
China
Panel Dimensions:
1722 * 1134 * 30 mm
Product name:
Longi Hi-MO6 108 Half Cells Black Solar Panel
Junction Box:
IP68,3 diodes
Frame:
Anodized Aluminium Alloy
Weight:
20.8kg
Front Glass:
3.2mm Coated Tempered Glass
Solar cell:
108(6*18)
Application:
Solar Energy System
Packing:
36pcs per pallet
Certificate:
CE

Quick Details

Cell size:
182mmx182mm
Type:
All Black, PERC, Mono
Panel Efficiency:
22.3%-22.8%
Warranty:
25 years warranty
Brand Name:
Longi
Model Number:
LR5-54HTB 435-445M
Place of Origin:
China
Panel Dimensions:
1722 * 1134 * 30 mm
Product name:
Longi Hi-MO6 108 Half Cells Black Solar Panel
Junction Box:
IP68,3 diodes
Frame:
Anodized Aluminium Alloy
Weight:
20.8kg
Front Glass:
3.2mm Coated Tempered Glass
Solar cell:
108(6*18)
Application:
Solar Energy System
Packing:
36pcs per pallet
Certificate:
CE
Product Description
ELECTRICAL DATA(STC)
Module Number
LR5-54HTB-435M
LR5-54HTB-440M
LR5-54HTB-445M
Testing Condition
STC     NOCT
STC     NOCT
STC     NOCT
Maximum Power (Pmax/W)
435      325
440      329
445      333
Open Circuit Voltage (Voc/V)
39.63      37.21
39.83      37.40
40.03      37.58
Short Circuit Current (Isc/A)
14.08      11.37
14.15      11.43
14.23      11.49
Voltage at Maximum Power(Vmp/V)
33.36      30.44
33.56       30.62
33.76      30.81
Current at Maximum Power(Imp/A)
13.05      10.68
13.12      10.75
13.19      10.82
Module Efficiency(%)
22.3
22.5
22.8
Voc and Isc Tolerance                                                                            ±3%
Maximum System Voltage                                                                    DC1500V(IEC)

Max Series Fuse Rating                                                                          25A

Operate Temperature Scope                                                                  -40°C+85°C

Nominal Operating Cell Temperature                                                    45±2°C

Standard Test Conditions: Irradiance 1000 W/m2； Cell temperature 25 C. Spectra at 1.5AM
NOCT(Nominal Operating Cell Temperature)：Irradiance 800W/㎡,Ambient Temperature 20℃， Spectra at AM1.5 Wind at 1m/s
Mechanical Data of Solar Module
Cell orientation
108Cells
Frame
Anodized Aluminium Alloy
Frame Thickness
30mm
Weight of module
20.8kg
Module Dimensions
1722*1134*30mm
Junction Box
IP68, three diodes
Main Components

Solar Cell
--High Anti-PID resistant
--Low breakage rate
-- Color sorting ensure consistent      appearance on each module
-- Service life is as long as 25 years
- - No Busbar


Junction box
--Long service life
-- Heat dissipation
-- IP68 protection level
-- Conventional standalone edition and engineering custom edition
--Quality diode ensures module running safety

Frame
-- Conventional frame
-- Boost bearing capability and prolong service life
-- Serrated-clip design tensile strength
-- Seal-lip design glue injection
-- Silver or black frames are optional
