Quick Details
-
Design Style:
-
Modern
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
SuperWindowHouse
-
Model Number:
-
MDF door
-
Curtain Type:
-
Hanging\Sliding\Louver\Roller blind
-
Product name:
-
MDF DOOR
-
Lock:
-
Automatic Lock
-
Frame option:
-
Construction Frame
-
Glass:
-
Double Tempered Glass
-
Glass Type:
-
Double Tempered Impact Glazing
-
Standards:
-
NAMI
-
Screen:
-
Fiberglass Mesh Screen
-
Surface Treatment:
-
Powder Coated Smooth Finished
-
Window type:
-
Insualted Glass UPVC Window
-
Name:
-
Aluminum Double Hung Window
Quick Details
-
Feature:
-
Magnetic Screen, Folding Screen
-
Function:
-
Invisible
-
Application:
-
Courtyard/Laundry/Kitchen/Exterior/Staircase/Gym
-
Design Style:
-
Modern
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
SuperWindowHouse
-
Model Number:
-
MDF door
-
Curtain Type:
-
Hanging\Sliding\Louver\Roller blind
-
Product name:
-
MDF DOOR
-
Lock:
-
Automatic Lock
-
Frame option:
-
Construction Frame
-
Glass:
-
Double Tempered Glass
-
Glass Type:
-
Double Tempered Impact Glazing
-
Standards:
-
NAMI
-
Screen:
-
Fiberglass Mesh Screen
-
Surface Treatment:
-
Powder Coated Smooth Finished
-
Window type:
-
Insualted Glass UPVC Window
-
Name:
-
Aluminum Double Hung Window
1.Related Products
PModern PVC wooden Villa door design Lacquer Apartment Room Interior Door Wood Veneer Interior Wooden Door
1.Product Introduction
Aluminum alloy hung window has big opening area and save indoor space,well sealed, good heat thermal insulation performance, good air tightness, good water tightness, better security.
|
Style |
Aluminum Alloy Hung Window |
|
|
Profile Brand |
Chinese Top Brand,1.2mm/1.4mm/2.0mm/3.0mm Wall Thickness |
Customized |
|
Profile |
Aluminum Profile Or Thermal Break Profile White Color,Champagne Color Or Woodgrain Color |
Customized |
|
Surface Treatment |
Anodizing,Power Coating,PVDF Coating,Electrophoresis,Etc |
Customized |
|
Glass |
Single Or Double Tempered Glass,Laminated Glass,Low-E Glass,Etc |
Customized |
|
Hardware |
German Top Brand ‘ROTO’ Or Australian ‘Doric’,Chinese Top Brand |
Customized |
|
Screen |
Retractable Screen,Accordion Screen,Folding Screen,Etc |
Customized |
|
Rubber Strip |
European Standard EPDM |
Customized |
|
Free Sample |
Ready Within 5 Days,Delivery By DHL/TNT |
|
|
Quality Control |
As2047/As2208/Ce/Soccap/Iso9001:2008 |
|
2. Product Detail
Glass is an important part of aluminum alloy window. It has the functions of light transmission, heat insulation, waterproof and windproof. Good glass also has the functions of anti- hurricane, dimming and UV protection.
Hardware accessory is also an important part of the aluminum alloy window. Good hardware plays a vital role in the insulation, airtightness and water tightness of the doors and windows.
3. Profile Detail
|
Profiles |
1.Non-thermal break aluminum profiles
3. Frame: 6063/6065 and different aluminum profiles produced by our own factory |
|
Non-thermal break aluminum hung window 1.Common series:65/80mm 2. the biggest glass thickness:22mm 3.The profile thickness: 1.4mm |
|
|
Thermal break aluminum ung window 1.Common series: 80mm 2. the biggest glass thickness:22mm 3. The profile thickness: 1.4mm |
|
|
Color: Silver oxide, electrophoretic champagne,spraying white/dark grey/ light grey/coffee/brown/red/black, wood grain,others,customized |
4. Glass Details
Low-e glass\frosted glazing\ grey/blue/green tinted glass,etc.
1.Single:3mm~12mm
2. Double: 5mm 6A 5mm/5mm 9A 5mm/6mm 9A 6mm, etc.
3.Triple: 5mm 6A 5mm 6A 5mm and others
4.Tinted/Reflected/Frosted Glass (Tempered Glass)
5. Hardware Accessories
Crescent lock+controller+roller/pulley
6. Product P arameters
|
Item |
Parameter |
Item |
Parameter |
|
K/U (insulation) |
< 1.1 |
Glass thickness/mm |
3-30 |
|
Airtightness/ m3/(m2.h) |
≤0.5 |
Profile Width/mm |
50-135 |
|
Watertighness/Pa |
≥700 |
Transmittance |
60%-98% up to glass type |
|
wind pressure/ KPa |
≥5.0 |
Fire-proof level |
AAAAA |
|
Profile thickness/mm |
0.8-3.0 |
Anti-theft level |
AAAAA |
7. Processing Procedure
cutting profile - assemble profiles- install hardware- installing EPDM sealing strip- installing glass- glue-assemble pannel
8.Quanlity Control
1. Raw material quality testing: the color, thickness and strength of profiles will be checked after the profiles arrive at the factory. After the glass to the factory, the color and thickness of the glass will be checked again , and the sealing performance of hollow glass will be checked. Hardware color will be checked and tests how well the hardware works.
2. In the production process, there will be special quality inspectors to check each process of production.
3. After the product is finished, the group corner , sealing, size, use effect and so on will be tested.
9. Product Package
1. Stretch film packaging
2. 5 carton packaging
3. Fumigation-free wooden frame packaging
4. Packed in wooden cases with fully enclosed and fumigation-free plywood
Different packing methods can be applied to FCL and LCL.
