Adjust the bending angle of the pipe, and can set different angles from 5° to 180°
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
ADV
-
Year:
-
2022
-
Power (kW):
-
3
-
Weight (KG):
-
300
-
Product name:
-
ADV B-38 CNC Tube Bending Machine
-
Bending diameter range:
-
10-38mm steel pipe (wall thickness less than 2mm)
-
Bending angle range:
-
5 degrees - 180 degrees
-
Spindle speed:
-
20 rpm
-
Rated voltage:
-
three-phase AC 380V 50HZ
-
Bending Angles Quantity:
-
9
-
Foot switch voltage:
-
DC 5V
-
Machine size:
-
920*650*850 mm
Quick Details
-
Machine Type:
-
Bending machine
-
Max. Bending Angle (Deg):
-
180
-
Bending Precision (Deg):
-
±1
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
ADV
-
Year:
-
2022
-
Power (kW):
-
3
-
Weight (KG):
-
300
-
Product name:
-
ADV B-38 CNC Tube Bending Machine
-
Bending diameter range:
-
10-38mm steel pipe (wall thickness less than 2mm)
-
Bending angle range:
-
5 degrees - 180 degrees
-
Spindle speed:
-
20 rpm
-
Rated voltage:
-
three-phase AC 380V 50HZ
-
Bending Angles Quantity:
-
9
-
Foot switch voltage:
-
DC 5V
-
Machine size:
-
920*650*850 mm
Machine Description
Tips:ADV B-26
Automatic CNC tube bending machine
with available diameter 10-26mm
1. ADV B-26/38/51/76 CNC steel tube bending machine is mainly used for bending different kinds of tube materials,
for example round or square mild carbon steel tube.
2.
The standard available diameter is 26mm, 38mm, 51mm, 76mm or customized.
3.
Use Micro CNC computer panel control the bending angles and batches.
4.
Foot switch add CNC operation,let the tube processing so easy and convenient.
5.
Gear drive is durable and maintenance is convenient,only add the grease oil into the gear box.
Machine Parameters
|
Semi-Automatic CNC Pipe Bending Machine Technical Parameter
|
|
|
|
|
||||
|
Model
|
ADV B-26
|
ADV B-38
|
ADV B-51
|
ADV B-76
|
||||
|
Motor Power
|
2.2 kw
|
3 kw
|
3 kw
|
4kw
|
||||
|
Bending round tube diameter
|
≤26mm
|
≤38mm
|
≤51mm
|
≤76mm
|
||||
|
Bending square tube width
|
≤20*20 mm
|
≤30*30 mm
|
≤40*40 mm
|
≤50*50 mm
|
||||
|
Thickness Scope
|
≤2m
|
≤3m
|
≤3m
|
≤5m
|
||||
|
High bending speed
|
10-20r/min
|
10-20r/min
|
4-6r/min
|
3-5r/min
|
||||
|
Bending Angles Quantity
|
9
|
9
|
9
|
9
|
||||
|
Bending angle range
|
5° - 180°
|
5° - 180°
|
5° - 180°
|
5° - 180°
|
||||
|
Foot switch voltage
|
DC 5V
|
DC 5V
|
DC 5V
|
DC 5V
|
||||
|
Dimensions(mm)
|
850x600x850
|
920x650x850
|
930x680x850
|
940x750x850
|
||||
|
Weight
|
220kg
|
300kg
|
350kg
|
400kg
|
||||
Machine Parts
CNC panel of pipe bending machine
Custom molds
Optional custom molds for wear resistance, long life, and ensure no wrinkle in the bend
Quick clamp
Screw clamp
How to purchase different pipe moulds?
Mold customization needs to provide pipe material, size, wall thickness, bending radius (or bending angle).
Machine Application
Application Industries:
1. Furniture industry: steel table tube, steel chair tube, steel bed tube, steel towel rack, etc.
2. Construction industry: steel guardrails, steel doors, steel handrails and steel windows, etc.
3. Public facilities industry: flagpoles, outdoor sports equipment, bus and subway handrails, etc.
2. Construction industry: steel guardrails, steel doors, steel handrails and steel windows, etc.
3. Public facilities industry: flagpoles, outdoor sports equipment, bus and subway handrails, etc.
Application Materials:
ADV B-26/38/51/76 CNC tube bending machine
is suitable for stainless steel, steel, aluminium, copper, etc.
We Support FREE Testing Samples for Customers
If you have any questions about the ADV B tube bending machine or other related questions, please contact us without hesitation
