Quick Details
-
Place of Origin:
-
Hebei, China
-
Model Number:
-
AG-haynes wire mesh
-
Brand Name:
-
Aegis
-
color:
-
Silver
-
Hole shape:
-
Square Hole
-
Width:
-
1/1.2/1.8/2 meters
-
Roll Length:
-
30 metres or customized
Quick Details
-
Material:
-
Haynes
-
Type:
-
Weave Wire Mesh
-
Application:
-
Filters
-
Place of Origin:
-
Hebei, China
-
Model Number:
-
AG-haynes wire mesh
-
Brand Name:
-
Aegis
-
color:
-
Silver
-
Hole shape:
-
Square Hole
-
Width:
-
1/1.2/1.8/2 meters
-
Roll Length:
-
30 metres or customized
Special material metal woven mesh
Nickel - Nickel is widely used in woven wire cloth as a corrosion resistant medium. It protects itself by forming a passive oxide film, thus resisting corrosion in many oxidizing environments. In today's industry, nickel is replaced with stainless steel when Possible for cost savings.
Monel - This alloy is essentially non-corrodible. Composed of 67% nickel, 28% copper and 5% others. Monel is more corrosion resistant than copper in oxidizing conditions and more resistant than nickel under reducing conditions. Monel has good strength characteristics and has traditionally been used in food processing. As with nickel, it can be replaced with stainless steel.
Alloy B - This alloy is used for corrosion resistance to hydrochloric acid in most concentrations and at temperatures up to the boiling point. It is not recommended for high temperature service.
Alloy C-276 - This alloy is well suited to corrosion resistance service against strong oxidizing agents such as ferric chloride and cupric chloride. Good elevated temperature properties in the 1600 to 1800 range
Carpenter 20 Cb-3 - A corrosion resistant alloy especially useful against hot sulfuric acid. Not normally used for high temperature service.
Incoloy Alloy 800 - The nickel and chromium content here are similiar to Carpenter 20 Cb-3, while the copper and molybdenum content are reduced. Used in high temperature and corrosive environments.
Inconel Alloy 600 - 72% nickel and 15% chromium content makes Inconel 600 suitable for high temperature applications where corrosion resistance is important. Frequently used for heat-treating baskets. :
Nichrome - A 60% nickel and 15% chromium alloy used in certain chemical conditions at temperatures up to 1700. Contains 1% silicon which helps keep scaling to a minimum. Subject to carbide precipitating characteristics.
Nichrome V - Similar to Nichrome, this alloy has a higher nickel content - 80% nickel and 20% chromium. It is used in severe chemical conditions at elevated temperatures up to 2000
FeCrAlY (commonly referred to as Hoskins 875 ® Hoskins Mfg Corp)C .03% Cr 21-24% Al 5-6% Mn .50% Si .2-1% S .005% P .03% Y .01% B .005% Fe balance
FeCrAlY is a heat resisting alloy with excellent oxidation resistant characteristics. The addition of Yttrium inhibits scaling. This alloy has a maximum service temperature of 2430 F, but exhibits cold brittleness below 750-1200 F after service temperatures above 1000 F. Common uses are high temperature furnaces, radiant heaters, quartz heaters, and heating elements for toasters.
Details Images
Related Products
Product packaging
Remark：
1：
Our company can customize wire mesh with special specifications and special weaving methods
2：we can customized metal filter products（filter cap，filter disc，filter panel，sintered wire mesh，sintered fiber felt
