Quick Details
-
Fork Length:
-
1220mm
-
Fork Width:
-
120mm
-
Overall Dimensions:
-
/
-
Weight (KG):
-
9600 kg
-
Certification:
-
ISO/CE
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
SINOMADA
-
Fork Length:
-
1220mm
-
Fork Width:
-
120mm
-
Overall Dimensions:
-
/
-
Weight (KG):
-
9600 kg
-
Certification:
-
ISO/CE
Contact Me
Ellie Hu
Phone / Whatsapp: +86-17373130042
Facebook: Wenjuan Hu
Instagram: Sakura-Wangwang
Pls feel free to contact me if you need more information. Looking forward to your news!
Parameters
| MODEL | LG70DT |
|---|---|
| Power type | Diesel |
| Rated capacity (Kg) | 7000 |
| J Load centre (mm) | 600 |
| h1 STD Max lifting height (mm) | 3000 |
| h3 Free lifting height (mm) | 205 |
| L5*W*T STD Fork size (mm) | 1220×150×65 |
| Mast tilt angle (deg) | 6/12 |
| L3 Front overhang (mm) | 595 |
| L4 Rear overhang (mm) | 695 |
| Overall dimension | |
| L1 Overall length(mm) | 4760 |
| W1Overall width (mm) | 2000 |
| h2 Mast lowered height (mm) | 2500 |
| h4 Overhead guard height (mm) | 2464 |
| R1 Min.turning radius (mm) | 3415 |
| Min .intersecting aisle (mm) | 5400 |
| Speed(load/unload) | |
| Max.traveling speed (km/h)(F/R) | 27/27 |
| Max,lifting speed (mm/s)(load/unload) | 330/450 |
| Max.gradient (%) | 20 |
| Dead weight (kg) | 8981 |
| S/P Tread(frnt/rear)(mm) | 1470/1700 |
| L2 Axle distance (mm) | 2250 |
| Min.ground clearance | |
| m2 Mast (mm) | 216 |
| m1 Frame (mm) | 248 |
| STD Engine | Xichai CA6110/125G2 |
| Rated power(kw) | 83 |
