Quick Details
-
Model Number:
-
PT-306
-
Product name:
-
Air Compressor Pressure Transmitter
-
Pressure range:
-
0-16bar, or others
-
Accuracy:
-
0.5%FS 1%FS
-
Material:
-
304/316SS
-
Work temperature:
-
-40℃-125℃
-
Process connection:
-
G1/4, 1/4NPT, R1/4 or others
-
Electrical connection:
-
Packard connector with 3-meter cable
-
Output signal:
-
4-20mA or 0.5-4.5V or 0-5V
-
Overload pressure:
-
200%FS
-
Certification:
-
CE
Quick Details
-
Warranty:
-
1 YEAR
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OULD
-
Model Number:
-
PT-306
-
Product name:
-
Air Compressor Pressure Transmitter
-
Pressure range:
-
0-16bar, or others
-
Accuracy:
-
0.5%FS 1%FS
-
Material:
-
304/316SS
-
Work temperature:
-
-40℃-125℃
-
Process connection:
-
G1/4, 1/4NPT, R1/4 or others
-
Electrical connection:
-
Packard connector with 3-meter cable
-
Output signal:
-
4-20mA or 0.5-4.5V or 0-5V
-
Overload pressure:
-
200%FS
-
Certification:
-
CE
Product Features
Dimensions: (mm)
Electrical connection:
|
|
4 ~ 20mA
|
0 ~ 5VDC , 0.5 ~ 4.5VDC
|
|
Red
|
Power +
|
Power +
|
|
Black
|
Output
|
Power -
|
|
Green or white
|
N/A
|
Output
|
Specifications:
Measuring range: Gauge pressure 0~1bar~50bar
Safety overload pressure: 200%FS
Comprehensive accuracy: +0.5%FS
Temperature compensation range: -40~85°C
Temperature drift: +0.03%/C
Long-term stability: +0.3%FS/year
Working temperature:-40~85°C
Storage temperature:-40~125C
Output signal: absolute value 0-5V/equal ratio 0-5V/4-20mA
Supply voltage (V): 6-36 or 3.0-5.5/3.0-5.5/11-36
Work (mA):2.5 (TYP)
Load(2):>10K/S50 (U-11)
Electrical connection: Wires/terminals
Protection level: IP65
Process connection: NPT 1/8, G1/4, etc. can be customized
Material: stainless steel, alumina, NBR (fluorine rubber, etc. optional)
Vibration: 10gRMS, (20~2000)Hz
Impact: 100g, 11ms
Insulation: greater than 100MR @250VDC
Response time: less than 1ms (@ 90%FS)
CE certification: EMC: IEC61326-1 Class B
Electrostatic discharge immunity: EC61000-4-2
Electromagnetic field immunity: IEC61000-4-3
EFT immunity: IEC61000-4-4
Surge immunity: IEC61000-4-5
You may need a long cable to use with this sender,Tell us by clicking the button below 1m/2m/3m/5m:
If you are not sure what kind of pressure sensor is right for your project.
please contact us
