Guangzhou KAVAKI 200CC water cooling trimoto de carga motocarro Carguero

old storm  tricycle .

we can offer different sizes tricycle with different colors
we are tricycle factory .good price
MODEL Number TH150ZH

Displacement :150cc

Engine type:4-storke

Brake(f/r) drum

Load capacity:500

Max.speed  65m/h

Rated Power: 8.0

Detail product description

Tricycle-150cc

Product Type :TH150ZH-A5

Dimension(mm)  3150X1200X1300

Carton Dimension(mm)1700x1210x320

Engine Model:162FMJ

Engine type single sylinder,4 stroke ,Air-cooled

Cylinder Bore 62

Cylinder stroke 49.5

Cylinder Displacement(ml) 149.5

Compression Proportion 9.2:1

Rated Power(kw/rpm) 8.5(8000±500)

Maximun Torque( N.M/rpm) 10.0(7500±500)

Lding Speed(r/min) 1400100

Lowest Fuel Consumption (g/kWh)≤354

Gasoline Type SF  15W/40

Starting Method Electric/kick

Lighting Model C.D.I

Lubrication System Press Splash

Net Engine Weight(kg) 30.5

Spark Plug D8EA

Carburetor Circuit PZ26

Valve Stem Clearance (mm) 0.04-0.07

Front tyre /Rear tyre(F/R) 3.05-16/5.00-12

Primary Transmission Ratio 4.055

End Transmission Ratio 4.140

Gearshit Gears 5 Drive + 1 Reverse

Max Speed ( km/h) ≥50

Fuel Tank Capacity(L) ≥9.5

Climb Degree(°C) ≥10

Lowest Continuous Speed With Load( km/h) ≤20

Drive Type Axle Drive

Brake Model Drum

Brake Operation (F/R)hand Brake /Coaster Brake

Shock Absorber Model(F/R) cylinder/leaf Spring

Spoke ( F/R) web Plate /web plate

Battery Type  12V  9Ah

Wheel Base (mm) 2060

Wheel Gauge(mm) 106

Ground Clearance(mm) ≥170

Minimum Turning Diameter≥5500

Net Weight(kg) 300

1.  Guangdong factory cargo motor  tricycle

2.Guangzhou KAVAKI 200CC zongshen water cooled  tricycles

3. Guangzhou KAVAKI 200CC water cooling trimoto de carga motocarro Carguero

1) Tricycle detail description

Model	Tricycle
Displacement	20 0cc
economical consumption fuel (I/100 km )	2.8L
L X W X H (mm)	3350*1300*2100
ENGINE TYPE	164FML, 4-stroke, air-cooled
MAX. POWER ( kw/rpm)	12kw/8000r/min
IGNITION	CDI
Type of TRANSMISSION	SHAFT, 5 forward + 1 reverse
MAX SPEED ( km/h)	80km/h
NET WEIGHT (kg)	380kg
USEFUL CARGO (kg)	1200kg
LUBRICATION TYPE	Pressure & Splash
CLUTCH	Single Clutch
BRAKE (F/R)	disc/Drum
START METHOD	Kick & Electric start
FUEL TANK CAPACITY	18L
TIRE TYPE (F/R)	5.0-12/5.0-12
MEASUREMENT OF REAR CARGO BOX	1.3m*1.8m
Brand of engine	LIFAN
FUEL TYPE	Gasoline 90# 93# 97#
Number of Cylinder	1
Number of Seats	1
Number of axles	2
Number fo Passenger	1driver only
Type of Wheels	inner

2)  Tricycle Main certificates

l     Pass ISO9001:2000 International Quality System Certification

l      Corporation with “CCC”Certification in the profession

l      The company have passed national production permit inspection

l      The products reach European II standard

3)  Tricycle Installation positions and names of components

4)  Tricycle Detail picture

5)  Tricycle Package & Content

6)  Three wheel motorcycle Loading contianer picutre

7)  Three wheel motorcycle production line

8)  Three wheel motorcycle market show room and overseas show room

9)  Three wheel motorcycle Related Products

10)  Three wheel motorcycle Customization

Three wheel motorcycle  Configuration can be changed into customer's requirements

colour choice	Red Blue Yellow Silver Black etc
engine choice	air-cooling       :150 cc ,175 cc ,200 cc ,250 cc water-cooled  :150cc,175 cc,200cc  250cc.
cargo box options:	1.2 m * 1.7 m, 1.2 m * 1.8 m,1.3m* 2.00m,1.3m*2.2m etc.
rear axle optional:	normal reat axle, automobile rear axle ,5hole rear axle, and etc.
front shock absorber optional:	50 front shock absorber of LONBO,front shock absorberwuth damper,double front shock absorber of fonton,etc .
The tyres optional:	3.25-16,  4.5-12,  5.0-12. etc

11)  3 wheel  tricycle company advantage

1.New design technology,compact body structure ,increases the quantity and saves transportation costs .Be at the advances level in the same industry .

2.Adapts advanced surface treatment equipment and technology for the chassis,with high gloss electrophoretic paint,strong adhesion,full color and luster,high brightness

3.On the rear axle with reverse from Chongqing ,quality assurance,good handling and braking performance,safeand secure.

4.New cylindrical spring and automobile dampers to increase the loading capacity of our tricycle at the same time reduce operational vibration,more comfortable

5.The tricycle’s chassis system fully consider multiple traffic characteristics ,ground clearance have 21cm 23cm 27cm ,good performance,driving more smoothly.

6.Take full account of user needs,convenient to modify vehicle,widely usage,with good extensibility.

7.New appearance design style,popular motor tricycle design, beautiful structure .

8. Front mudguard:increase processing front fender clearance design ,muddy road also unimpeded.

9. New modeling side cover,and the harmonious collocation compact ,a smooth fluent,elegant and fashionable .

10. Seatcushion new modeling,according to human triangle on divisional design,reasonable distribution in comfortable space before and after.

11. Configuration upgrade:use 4.5-12 8PR quality tire ,three-wheeled swap tires,tire grounding the gender is strong,the vehicle driving more stable and hills free road.

12. Strengthen driving axle design,vehicle parts in the same case,compared with common driving axle,kilometers to save more than 10%average fuel consumption,economy stronger..

13. Aluminum alloy separate handlebar:from the car technology of high strength aluminum alloy separate handlebar ,not only appearance vogue dazzing ,more to provide a comfortable high position design,feel comfortable in fact long distance driving will not fatigue.

14.Light-weight muffler design more joint vehicle performance,which make the whole car be weight is reduced,fuel consumption replacement muffler design more joint vehicle performance,which make the whole car be weight is reduced,fuel consumption replacement,economical and environmental protection .

15. Three wheeler unique engine offers more power,making forward or reverse more easily even when taking full of goods or passengers .Treasure overlord quality promotion engine special field,the gear piston piston rings reinforce the key parts,engine high temperature resistant performance,stronger,better able to adapt to the long distance heavy demand.

12)  Three wheel motorcycle Factory Photos

Why us???

Only cooperating with us as a professional manufacturer of cargo tricycle in over 30 years experience.We own the below unique advantanges compared to our competitors:

• 1)To offer products to our customers with the best cost-effective,stable quality and outstanding after-sales service
• 2)Sustainable qualit improving and projects to meet various marketing demands
• 3)Fast delivery within 15days ,vonvenient and economy inland transportation,From the major chinese port--SHENZHEN
• 4) Factory  located in guangzhou panyu, about 20 minutes drive from guangzhou trade exhibition
• 5)Free spare parts 1% for each order .
• 6)More flexible payment terms for choice:T/T L/C cash etc.........

welcome to visit our factory!

Any question, please feel free to contact me!
