Quick Details
-
Filling Accuracy:
-
±2mm
-
Voltage:
-
AC110-380V
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
HZM
-
Dimension(L*W*H):
-
CUSTOMIZED
-
Weight:
-
2000 KG
-
Product name:
-
rinser filler capper
-
Name:
-
HZM
-
Advantage:
-
10 Years Experiences
-
Suitable for:
-
water
-
Capacity:
-
2000-72000bph
-
After-sales Service Provided:
-
Online Support
-
Type:
-
water beverage filler, Filling Machine
-
Keywords:
-
drink water line
-
Machine name:
-
Water Filling Machine Line
Quick Details
-
Machinery Capacity:
-
4000BPH, 8000BPH, 12000BPH, 20000BPH, 16000BPH
-
Packaging Material:
-
Plastic
-
Filling Material:
-
Water
-
Filling Accuracy:
-
±2mm
-
Voltage:
-
AC110-380V
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
HZM
-
Dimension(L*W*H):
-
CUSTOMIZED
-
Weight:
-
2000 KG
-
Product name:
-
rinser filler capper
-
Name:
-
HZM
-
Advantage:
-
10 Years Experiences
-
Suitable for:
-
water
-
Capacity:
-
2000-72000bph
-
After-sales Service Provided:
-
Online Support
-
Type:
-
water beverage filler, Filling Machine
-
Keywords:
-
drink water line
-
Machine name:
-
Water Filling Machine Line
PRODUCT OVERVIEW
Full automatic water filling machine for PET bottle integrates the functions of rinsing, filling and capping together. Based on advanced technology overseas and designed according to the filling processing demands of mineral water, pure water, drinking water etc.
PRODUCT FEATURES
1. This water filling machine has a compact structure, perfect control system, easy to operate and highly automated.
2. Only by changing the star-wheel, arch board can realize fill bottle shape change.
3. The parts contact with product is made of quality SUS316/304, anti-corrosive, and easy to clean.
4. Rapid flow, highly filling precision, nicety liquid level without any liquid loss to satisfy the filling process demand.
5. The capping head adopts constant torque magnetic device to guarantee capping quality and impact cap.
6. This water filling machine has a high efficient cap arranging system, perfect cap feeding with self-control and self-protection device.
7. The water filling machine adopts perfect overload protective device can ensure the operator and machine safety.
8. The control system has many functions, such as control producing speed, cap shortage detection, bottle block automatic stop and production counting etc.
9. The main electric and air-drive components are world famous brand products.
10. All control is advanced touch-screen operation and realize people-computer dialogue operation.
Rinsing Part
1. This bottle clamp grips bottle at neck position, avoiding bottle mouth thread contamination caused by rubber gripper block of a traditional bottle clamp.
2. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, saving rinsing water.
3. Covering of bottle clamps and elevator are product of Igus.
Filling Part
1. Filling valves are designed and manufactured with German technology, featuring high filling accuracy and high filling speed.
2. All sliding bushes of lifting device use Igus (Germany) anti-corrosion maintenance free bearing.
3. Filling valves are made of SUS316.
4. Hydraulic pump is float-ball controlled.
Capping Part
1. Highly effective acentric way for cap sorting to reduce the abrasion.
2. The fall guide rail has the device to prevent the reversal cap from passing and pick out the reversal cap.
3. It has the bottle check-up switch to control the cap flow and stop it in case no bottle to reduce the cap quantity.
MAIN TECHNICAL PARAMETERS
|
Model
|
XGF40-40-10
|
XGF50-50-15
|
XGF60-60-15
|
XGF72-72-18
|
XGF80-80-22
|
||||
|
Capacity
(for 500ml)
|
18,000BPH
|
24,000BPH
|
30,000BPH
|
36,000BPH
|
40,000BPH
|
||||
|
Bottle diameter
|
50～110mm
|
|
|
|
|
||||
|
Bottle height
|
160～310mm
|
|
|
|
|
||||
|
Air source pressure
|
0.7MPa
|
|
|
|
|
||||
|
Voltage
|
380/415V
|
|
|
|
|
||||
|
Main motor power
|
7.5KW
|
7.5KW
|
11.0KW
|
11.0KW
|
13.0KW
|
||||
|
Dimension
|
4360*3300*2700
|
4720*3545*2700
|
5770*5288*2700
|
6540*4800*2700
|
7800*6380*2700
|
||||
PRODUCT CONFIGURATIONS
|
Item
|
Remark
|
|
Main motor+ Reducer
|
SEW-Germany
|
|
Inverter
|
SIEMENS-Germany
|
|
PLC
|
SIEMENS-Germany
|
|
Touch screen
|
SIEMENS-Germany
|
|
Contactor
|
SCHNEIDER-France
|
|
Hot relay
|
SCHNEIDER-France
|
|
Air switch
|
SCHNEIDER-France
|
|
Photoelectric switch
|
LEUZE/BANNER-Germany
|
|
Pneumatic components
|
FESTO-Germany
|
|
Sliding bearing
|
IGUS-Germany
|
|
Lubrication system
|
BEKA-Germany
|
RELATED PRODUCTS
WHY CHOOSE HZM
Turnkey Solution Service
High-quality equipment, perfect service, abundant operation of the whole plant, strong turnkey service capability of the wholeplant, HZM helps customers achieve a high-efficiency operation of equipment.
High-quality equipment, perfect service, abundant operation of the whole plant, strong turnkey service capability of the wholeplant, HZM helps customers achieve a high-efficiency operation of equipment.
Installation / Debugging / Training
After the customers received the equipment, HZM will send experienced engineers to the customer's factory to do installation and commission services, and provide theoretical and technical training.
After the customers received the equipment, HZM will send experienced engineers to the customer's factory to do installation and commission services, and provide theoretical and technical training.
After-Sales Service
HZM meets customer requirement in the shortest time with a complete service platform and fast response mechanism.Provide 7*24 hours after-sales service, comprehensive after-sales protection, timely and effective problem solving mechanism.
HZM meets customer requirement in the shortest time with a complete service platform and fast response mechanism.Provide 7*24 hours after-sales service, comprehensive after-sales protection, timely and effective problem solving mechanism.
Spare Parts
Providing one-stop spare parts management service solutions, including unified order acceptance, reliable spare parts supply, first-class logistics network, professional service delivery management, to ensure the spare parts are sent to the right place at the right time.
Providing one-stop spare parts management service solutions, including unified order acceptance, reliable spare parts supply, first-class logistics network, professional service delivery management, to ensure the spare parts are sent to the right place at the right time.
Turnkey solution provider
HZM machinery is committed to be a reliable the liquid packaging machinery supplier. Our services range from planning process flow to project coordination and determining the connection of different equipment, so as to provide customers with high-quality, fast and customized services.
COOPERATION SUPPLIERS
FAQ
Q1：How can you guarantee the quality if I order from HZM?
1. Before assembly, we will strictly test each component to ensure the accuracy.
2. We will arrange experienced engineers to be responsible for each equipment.
3. We will test each equipment continuously for at least 12 hours before shipment.
Q2：What's your guarantee rules?
We provide quality machines with top brand components and qualified material. Our warrantee time is 2 years after installation and commissioning. Within 2 years the machines get quality problem, we will take full responsibility and provide services.
Q3：Can you provide installation service?
Yes, according to customers' requirement, we can provide on-line support or send engineers to customer's factory to do installation, commission and training.
Q4：Do you provide customized service?
Yes, we can help customers design factory layout, production layout, bottle type etc. We can also provide transformer, stablier, cabel, label, preform and other necessary materials.
