The titanium tube is light in weight, high in strength and superior in mechanical properties. It is widely used in heat exchange equipment, such as tube and tube heat exchangers, coil heat exchangers, serpentine tube heat exchangers, condensers, evaporators and transportation pipelines. Many nuclear power industries use titanium tubes as standard tubes for their units
- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
titanium tube
-
Material:
-
Pure titanium/Titanium alloy
-
Outer Diameter:
-
1-350mm
-
Length:
-
≤3000mm
-
Application:
-
Industrial
-
Grade:
-
g2/g3/g5
-
Wall Thickness:
-
0.3-120mm
-
Inside Diameter:
-
2-219mm
-
Product Name:
-
Titanium Tubing
-
Grade::
-
Gr1,Gr2,Gr5,Gr7,Gr9,Gr10,Gr12
-
Processing Service::
-
Bending, Welding, Decoiling, Cutting, Punching
-
Processing::
-
Bending/Welding/Cutting
-
Product Name::
-
Titanium Seamless Tubes
-
Application::
-
Industrial
-
Type::
-
Round Titanium Tube
-
MOQ:
-
1ton
-
Payment:
-
T/T
-
Shape:
-
Round.square.Rectangle
Quick Details
-
Standard:
-
ASTM B862,ASTM B338,ASME SB862,ASME SB338
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
huiyuan
-
Model Number:
-
titanium tube
-
Material:
-
Pure titanium/Titanium alloy
-
Outer Diameter:
-
1-350mm
-
Length:
-
≤3000mm
-
Application:
-
Industrial
-
Grade:
-
g2/g3/g5
-
Wall Thickness:
-
0.3-120mm
-
Inside Diameter:
-
2-219mm
-
Product Name:
-
Titanium Tubing
-
Grade::
-
Gr1,Gr2,Gr5,Gr7,Gr9,Gr10,Gr12
-
Processing Service::
-
Bending, Welding, Decoiling, Cutting, Punching
-
Processing::
-
Bending/Welding/Cutting
-
Product Name::
-
Titanium Seamless Tubes
-
Application::
-
Industrial
-
Type::
-
Round Titanium Tube
-
MOQ:
-
1ton
-
Payment:
-
T/T
-
Shape:
-
Round.square.Rectangle
Product Description
|
Titanium Welded Pipe
|
|
|
|
|
||||
|
Product
|
Titanium and Titanium alloy welded tube
|
|
|
|
||||
|
Size
|
OD: 19.0mm (0.75") and 25.4mm (1.0"), Length: 1000mm-15000mm (39.4"-590.6"), Thickness: 0.5mm-0.7mm (0.02"-0.028")
Or Customized |
|
|
|
||||
|
Material
|
Gr.1, Gr.2, Gr.9
|
|
|
|
||||
|
Standard
|
ASTM B337, ASTM SB338, ASTM B861, ASTM B862,etc.
|
|
|
|
||||
|
Shape
|
Round
|
|
|
|
||||
|
Titanium Seamless Pipe
|
|
|
|
|
||||
|
Product
|
Titanium and Titanium alloy seamless tube & pipe
|
|
|
|
||||
|
Size
|
Cold-rolled:
OD: 8.0mm-114.0mm (0.32"-4.49"), WT: 0.5mm-7.5mm (0.02"-0.30"), Length: 4000mm (157.5") max (OD.: 8.0mm-15.0mm, 0.32"-0.59"), 12000mm (472.4") max (OD. over 15mm, 0.59") Extruded: OD: 25mm-210mm (0.98"-8.27"), WT: 4mm-30mm (0.157"-1.18"), Length: 1000mm-10000mm (39.4"-393.7") |
|
|
|
||||
|
Material
|
Gr.1, Gr.2, Gr.3, Gr.7, Gr.9, Gr.12, etc.
|
|
|
|
||||
|
Standard
|
ASTM B 338, ASTM B 337, ASTM B 861
|
|
|
|
||||
|
Shape
|
Round
|
|
|
|
||||
Specification
|
OD(mm)
|
8.0-10.0
|
10.0-15.0
|
15.0-20.0
|
20.0-25.0
|
25.0-30.0
|
30.0-35.0
|
|
WT(mm)
|
0.15-2.0
|
0.2-2.0
|
0.4-2.7
|
0.45-3.2
|
0.45-3.3
|
0.45-3.4
|
|
OD(mm)
|
35.0-40.0
|
41.0-45.0
|
46.0-50.0
|
51.0-55.0
|
56.0-60.0
|
61.0-65.0
|
|
WT(mm)
|
0.5-3.5
|
0.6-3.8
|
0.6-3.8
|
0.6-4.4
|
0.8-4.6
|
0.9-4.7
|
|
OD(mm)
|
66.0-70.0>
|
71.0-75.0>
|
76.0-95.0
|
96.0-114.0
|
-
|
-
|
|
WT(mm)
|
1.0-4.9
|
1.2-6.0>
|
1.2-7.1
|
1.3-7.5
|
-
|
-
|
Application Area
Titanium pipes implement two national standards according to the different requirements and performance: GB/T3624-2010 GB/T3625-2007 ASTM B337 338
Supply grades: TA0, TA1, TA2, TA9, TA10, BT1-00, BT1-0, Gr1, Gr2
