Quick Details
-
Dimension(L*W*H):
-
18040*4050*3615
-
Weight:
-
158t
-
Key Selling Points::
-
Eco-friendly
-
Torque::
-
280KN.M
-
Drilling Diameter::
-
2500mm
-
Drilling Depth::
-
62m
-
Drilling Speed::
-
5~28r/min
-
Engine Model::
-
Cu-m-ins QSM11
-
Rated Power::
-
298kw
-
Rated Engine Speed::
-
2100r/min
-
Max.Crowd Force::
-
260kN
-
Operating Mass::
-
93t
-
Certification:
-
CE/ISO
Quick Details
-
Place of Origin:
-
Guangxi, China
-
Brand Name:
-
Oriemac
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
18040*4050*3615
-
Weight:
-
158t
-
Key Selling Points::
-
Eco-friendly
-
Torque::
-
280KN.M
-
Drilling Diameter::
-
2500mm
-
Drilling Depth::
-
62m
-
Drilling Speed::
-
5~28r/min
-
Engine Model::
-
Cu-m-ins QSM11
-
Rated Power::
-
298kw
-
Rated Engine Speed::
-
2100r/min
-
Max.Crowd Force::
-
260kN
-
Operating Mass::
-
93t
-
Certification:
-
CE/ISO
Drilling machinery 94m Rotary Drilling Rig ZR280C-2
-
-
Rotary drive with three motors, which ensures large torque, high reserve coefficient and stronger construction capacity.
-
High construction efficiency due to big flow main pump, multi-gear rotary drive, and two-speed crowd cylinder.
-
More stable structure and stronger bearing capacity due to large supporting angle of the mast cylinder, lower center of gravity, and reinforced chassis.
-
New generation cab with better vision, more comfortable operation, new electrical control panel. 360 degree full view monitoring.
-
Options:5th generation rotary drive, auto-lubrication, spin-off.
Specification
| NAME | SPEC. | |
|---|---|---|
| Torque(KN.M) | 280 | |
| Drilling Diameter(mm) | 2500 | |
| Drilling Depth(m) | inter-locking | 58/62 |
| Friction | 88/94 | |
| Drilling Speed(r/min) | 5~28 | |
| Engine Model | QSM11 | |
| Rated Power(kw) | 298 | |
| Rated Engine Speed(r/min) | 2100 | |
| Max.Crowd Force(kN) | 260 | |
| Max.Crowd Cylinder Pull(kN) | 260 | |
| Line Pull(main winch)(kN) | 290 | |
| Line Speed(main winch)(m/min) | 68 | |
| Line Pull(aux.winch)(kN) | 90 | |
| Line Speed(aux.winch)(m/min) | 66 | |
| Operating Mass(t) | 93 | |
| Traction Force(kN) | 557 | |
| Rope diameter(Main winch)(mm) | 32 | |
| Rope diameter(auxiliary winch)(mm) | 22 | |
| NAME | SPEC. | |
|---|---|---|
| Torque(KN.M) | 220 | |
| Drilling Diameter(mm) | 2000 | |
| Drilling Depth(m) | inter-locking | 48 |
| Friction | 60 | |
| Drilling Speed(r/min) | 7~26 | |
| Engine Model | QSL9 | |
| Rated Power(kw) | 242 | |
| Rated Engine Speed(r/min) | 2000 | |
| Max.Crowd Force(kN) | 180 | |
| Max.Crowd Cylinder Pull(kN) | 200 | |
| Line Pull(main winch)(kN) | 200 | |
| Line Speed(main winch)(m/min) | 63 | |
| Line Pull(aux.winch)(kN) | 90 | |
| Line Speed(aux.winch)(m/min) | 66 | |
| Operating Mass(t) | 73 | |
| Traction Force(kN) | 423 | |
| Rope diameter(Main winch)(mm) | 28 | |
| Rope diameter(auxiliary winch)(mm) | 22 | |
