Quick Details
-
Warranty:
-
1 Year for Wind Turbine
-
Certification:
-
CE
-
Output Voltage:
-
DC 48/96V
-
rotor diameter:
-
3800mm
-
Product name:
-
Motor Wind Generator
-
Application:
-
Wind Power System
-
Wind turbine type:
-
Horizontal/Vertical Wind Trubine
-
Blade Material:
-
Extra-strong fiber glass
-
Start-up wind speed:
-
3m/s
-
Keywords:
-
Wind Turbine
-
Rated wind speed:
-
10m/s
-
Generator type:
-
3phases permanent magnetism synchronization generator
-
Name:
-
3KW Wind Power Generator
-
Rated speed:
-
300r/m
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
Sunway
-
Model Number:
-
WT-3000
-
Warranty:
-
1 Year for Wind Turbine
-
Certification:
-
CE
-
Output Voltage:
-
DC 48/96V
-
rotor diameter:
-
3800mm
-
Product name:
-
Motor Wind Generator
-
Application:
-
Wind Power System
-
Wind turbine type:
-
Horizontal/Vertical Wind Trubine
-
Blade Material:
-
Extra-strong fiber glass
-
Start-up wind speed:
-
3m/s
-
Keywords:
-
Wind Turbine
-
Rated wind speed:
-
10m/s
-
Generator type:
-
3phases permanent magnetism synchronization generator
-
Name:
-
3KW Wind Power Generator
-
Rated speed:
-
300r/m
Wind turbines work on a simple principle: instead of using electricity to make wind—like a fan—wind turbines use wind to make electricity. Wind turns the propeller-like blades of a turbine around a rotor, which spins a generator, which creates electricity.
Product Parameters
|
Product Name
|
3KW Wind Turbine for Wind and Solar Hybrid System
|
|
Model
|
WT-3000
|
|
Rated power
|
3KW
|
|
Starting wind speed
|
3m/s
|
|
Working wind spped
|
3-25m/s
|
|
Rated wind speed
|
10m/s
|
|
Security wind speed
|
40m/s
|
|
Rated DC voltage
|
96V
|
|
Rated speed
|
300r/m
|
|
Rotor diameter
|
3800mm
|
|
Protection
|
Electromagnetic torque control and electricity brake
|
|
Type
|
3phases permanent magnetism synchronization generator
|
|
Blade material
|
Extra-strong fiber glass
|
|
Packing material
|
Plywood box and foam material
|
|
Generator weight(kg)
|
85KG
|
Working Principle
Wind turbine produce unstable three phase AC, solar panel produce unstable DC, and send to the CPU in the controller, the controller have rectify functions, it will rectify the unstable AC and DC to stable DC, so the battery can save the electricity. Through the off grid inverter to transfer the DC to AC, the battery can be send to the household equipments.
Feartures of Wind Turbine
1. Rare earth permanent-magnet generator
2. Small vibration and tiny friction, stable rotation in higher speed
3. Streamlined wind turbine body and blade outline design
4. Blades have 2 kinds, 300w-1kw for high-rigidity FRP materials and blades are dynamic-balanced
5. Noise level below 55dB around the wind turbine tower
6. State of the art, workmanship and beautiful appearance
5. Noise level below 55dB around the wind turbine tower
6. State of the art, workmanship and beautiful appearance
Product Packaging
If you purchase wind generator from us, wind turbine will be packed with wooden;If you purchase solar and wind hybrid system from us, wind generator packed with wooden,controller and inverter will be packed with carton, solar panel will be packed with pallet.
Application
Wind Turbine for Park
Mid-scale Wind Turbine
Grassland Wind Motor
Residential Use Wind Generator
Offshore Wind Energy System
Wind Turbine for Farm
Other products
FAQ
Q1:Wich model wind generator is suitable for me?
A1: Please contact with our sales, Sunway will help you choose the most suitable model for you.
Q2:What about the delivery?
A2: If the model of wind turbine you need is in stock, we can delivery wind generator in 10days to 25days after receiving your payment, and we can help you ship all over the world.
Q3：For home use, which one is better?
A3: Normally we sell 5kw & 10kw solar wind hybrid system for home use.
Q4: Which style of wind generator do you produce?
A4: Sunway can produce both on grid and off grid, horizon style and vertical style. Also, Sunway supply full set of solar energy system, solar and wind hybrid system, and solar pump system, etc.,
Q5: Does installtion Easy ?
A5: Very easy, every customer can do it by themselves, Sunway will supply all the components for installtion and detailed
installtion manual for your reference, if any questions, pls feel free to contact with our sales maganer and engineer.
Q6: What size of wind turbine or motor do you produce?
A6:We produce from 150W to 300KW wind turbine, can supply parts or whole unit.
Q7: How long is the lifetime of wind generator?
A7: The life time of wind turbine is more than 20 years. By the way, lifespan of solar panel is more than 30 years, another parts is 6-15 years.
Q8: What can be included for this system?
A8: Full set of wind energy system: wind turbine(wind generator+blades+tower), wind controller, inverter, battery.
Full set of solar and wind hybrid system: solar panels,wind turbine(wind generator+blades+tower),wind and solar hybrid controller, inverter, battery, solar pv cable, roof or ground bracket, and pv connectors, DC combiner box, etc.,
Q9: What is your payment method?
A9: Sunway accept T/T, Western Union and Alibaba Trade Assurance (prefer to this one)
30% or 50% advance, balance before shipment, if total cost more than USD200,000, Sunway accept L/C at sight.
A1: Please contact with our sales, Sunway will help you choose the most suitable model for you.
Q2:What about the delivery?
A2: If the model of wind turbine you need is in stock, we can delivery wind generator in 10days to 25days after receiving your payment, and we can help you ship all over the world.
Q3：For home use, which one is better?
A3: Normally we sell 5kw & 10kw solar wind hybrid system for home use.
Q4: Which style of wind generator do you produce?
A4: Sunway can produce both on grid and off grid, horizon style and vertical style. Also, Sunway supply full set of solar energy system, solar and wind hybrid system, and solar pump system, etc.,
Q5: Does installtion Easy ?
A5: Very easy, every customer can do it by themselves, Sunway will supply all the components for installtion and detailed
installtion manual for your reference, if any questions, pls feel free to contact with our sales maganer and engineer.
Q6: What size of wind turbine or motor do you produce?
A6:We produce from 150W to 300KW wind turbine, can supply parts or whole unit.
Q7: How long is the lifetime of wind generator?
A7: The life time of wind turbine is more than 20 years. By the way, lifespan of solar panel is more than 30 years, another parts is 6-15 years.
Q8: What can be included for this system?
A8: Full set of wind energy system: wind turbine(wind generator+blades+tower), wind controller, inverter, battery.
Full set of solar and wind hybrid system: solar panels,wind turbine(wind generator+blades+tower),wind and solar hybrid controller, inverter, battery, solar pv cable, roof or ground bracket, and pv connectors, DC combiner box, etc.,
Q9: What is your payment method?
A9: Sunway accept T/T, Western Union and Alibaba Trade Assurance (prefer to this one)
30% or 50% advance, balance before shipment, if total cost more than USD200,000, Sunway accept L/C at sight.
