Quick Details
-
Ejector Stroke(mm):
-
100 mm
-
Ejector Force(kN):
-
33 kN
-
Theoretical Shot Volume(cm³):
-
249 cm³
-
Injection Rate (g/s):
-
108 g/s
-
Injection Weight (g):
-
226 g
-
Screw diameter (mm):
-
42 mm
-
Distance between Tie Bars:
-
415mm*375mm
-
Weight (KG):
-
3800
-
Place of Origin:
-
Zhejiang, China
-
Open Stroke(mm):
-
350 mm
-
Model Number:
-
FHG138
-
Brand Name:
-
FUHONG
-
Power (kW):
-
13 kW
-
Product name:
-
pen shell injection molding moulding making machine
-
Injection pressure:
-
148mpa-188mpa
-
Space between tie-bars:
-
415mm*375mm
-
Mould thickness:
-
180mm-440mm
-
Ejector stroke:
-
100mm
-
Heating power:
-
8.8kw
-
MACHINE DIMENSION:
-
4.75m*1.4m*1.85m
-
Injection Rate:
-
98g/s-124g/s
-
Injection Weight:
-
205g-280g
-
Plastic Type:
-
thermoplastic
-
Certification:
-
TUV C E
Quick Details
-
Distance between Tie Bars(Width)(mm):
-
415mm
-
Distance between Tie Bars(Height)(mm):
-
375mm
-
Mold Height(mm):
-
180 - 440 mm
-
Ejector Stroke(mm):
-
100 mm
-
Ejector Force(kN):
-
33 kN
-
Theoretical Shot Volume(cm³):
-
249 cm³
-
Injection Rate (g/s):
-
108 g/s
-
Injection Weight (g):
-
226 g
-
Screw diameter (mm):
-
42 mm
-
Distance between Tie Bars:
-
415mm*375mm
-
Weight (KG):
-
3800
-
Place of Origin:
-
Zhejiang, China
-
Open Stroke(mm):
-
350 mm
-
Model Number:
-
FHG138
-
Brand Name:
-
FUHONG
-
Power (kW):
-
13 kW
-
Product name:
-
pen shell injection molding moulding making machine
-
Injection pressure:
-
148mpa-188mpa
-
Space between tie-bars:
-
415mm*375mm
-
Mould thickness:
-
180mm-440mm
-
Ejector stroke:
-
100mm
-
Heating power:
-
8.8kw
-
MACHINE DIMENSION:
-
4.75m*1.4m*1.85m
-
Injection Rate:
-
98g/s-124g/s
-
Injection Weight:
-
205g-280g
-
Plastic Type:
-
thermoplastic
-
Certification:
-
TUV C E
|
ITEM
|
|
UNIT
|
FHG138
|
|
|
|||
|
Injection Unit
|
Screw Diameter
|
mm
|
40
|
42
|
45
|
|||
|
|
Injection Volume
|
cm3
|
228
|
252
|
289
|
|||
|
|
Shot Weight
|
g
|
208
|
229
|
263
|
|||
|
|
Injection Pressure
|
Mpa
|
180
|
163
|
142
|
|||
|
Clamping Unit
|
Clamping Force
|
KN
|
1380
|
|
|
|||
|
|
Opening Stroke
|
mm
|
380
|
|
|
|||
|
|
Mould Thickness(Min-Max)
|
mm
|
160-420
|
|
|
|||
|
|
Space Between Tie-Bars
|
mm
|
420×420
|
|
|
|||
|
|
Ejector Force
|
KN
|
33
|
|
|
|||
|
|
Ejector Stroke
|
mm
|
115
|
|
|
|||
|
Others
|
Motor Power
|
KW
|
13
|
|
|
|||
|
|
Heating Power
|
KW
|
8.8
|
|
|
|||
|
|
Pump Pressure
|
Mpa
|
16
|
|
|
|||
|
|
Machine Dimension
|
m
|
4.54×1.27×1.65
|
|
|
|||
|
|
Machine Weight
|
Ton
|
3.3
|
|
|
|||
Axuiliary Equipment
Related Products
About Us
Payment & Shipping
1.How to choose injection molding machine?
The injection weight should be about 1.2× product's weight; The tie bar space should be bigger than the mold dimension; Contact with us for more information.
2.How to pay?
30% deposit T/T in advance, the balance 70% payment by T/T before delivery (we accept payment by T/T, L/C etc.)
3.Is that possible for your company to send engineer to install machine for commissioning, even train our workers?
Yes, we can send our engineer to your factory for installing, commissioning, training. We have some engineers flying among different countries for after sale service and technical support. As per experience, if everything OK usually 5-15 days is enough. Therefore, before shipment, we need you to prepare invitation letter for visa. However, please be noted that all cost happened for visa, travel, hotel should be paid in advance by customers. In addition, we cannot guarantee each visa is successful.
4.If we buy your machines, is there any warranty?
Yes, definitely. Totally 24-months warranty after shipment for mechanical parts, hydraulic parts, electric components (The screw just has 6-months). We are responsible for broken parts within 24-months. We will supply those parts in freeway but the possible transportation cost should be paid by clients.
5.What is different with A,B,C screw, What is the price different?
The screw model is designed for different material and requirements, the screw diameter Changes from small, middle and big. There is no price difference in the price for choosing A/B/C screw types.
