Quick Details
-
Thickness:
-
0.18 - 0.35 mm, 0.18mm-0.35mm
-
Standard:
-
ASTM IEO EN JIS GB, GB ASTM JIS
-
Place of Origin:
-
China, BAO Steel
-
Model Number:
-
Common type,High induction type
-
Application:
-
Transformer Core,Motor
-
Certificate:
-
ISO9001 RoHS
-
MOQ:
-
25 ton
-
Sample:
-
Free-sample
-
Products Shapes:
-
Coil/sheet/strip
Quick Details
-
Type:
-
Oriented Silicon Steel
-
Tolerance:
-
±1%
-
Grade:
-
Silicon steel
-
Thickness:
-
0.18 - 0.35 mm, 0.18mm-0.35mm
-
Standard:
-
ASTM IEO EN JIS GB, GB ASTM JIS
-
Place of Origin:
-
China, BAO Steel
-
Model Number:
-
Common type,High induction type
-
Application:
-
Transformer Core,Motor
-
Certificate:
-
ISO9001 RoHS
-
MOQ:
-
25 ton
-
Sample:
-
Free-sample
-
Products Shapes:
-
Coil/sheet/strip
Product Introduction
Silicon steel, also known as electrical steel or silicon steel sheet, is a special steel that contains a certain proportion of silicon. The main feature of this steel is that it has a high permeability, while having a low hysteresis loss, making it an ideal material for the manufacture of transformers, generators, motors and other electrical equipment.
Genaral Parameters
|
Type
|
Oriented silicon steel/CRGO Coil&Strip
|
|
|
|
|||
|
Standard
|
IEC 60404-8-7 ASTM A876 EN 10106 JIS C2553 GB/T 3655
|
|
|
|
|||
|
Grade
|
Common type:
B23G110 B27G120 B30G120 B30G130 B35G135 B35G145
High induction type:
B18P075 B18P080 B20P05 B20P080 B20P085 B23P085 B23P090
B23P095 B23P100 B27P090 B27P090 B27P100 B30P095 B30P100 B30P110 B30P120 B35P115 B35P125 B35P135 etc.
Domain refinement type：
B18R055 B18R060 B18R065 B18R070 B20R060 B20R070 B20R080 B23R070 B23R080 B23R090 B27R090 B30R100 etc.
Heat resistant scoring type:
B23HS75 B23HS80 B23HS85
Distribution special:
B23RD080 B23RD085 B23RD090
|
|
|
|
|||
|
Insulation coating
|
S
|
|
|
|
|||
|
Edge condition
|
Cut edge EC
|
|
|
|
|||
|
Thickness
|
0.18mm 0.20mm 0.23mm 0.27mm 0.30mm 0.35mm
|
|
|
|
|||
|
Width
|
20mm-1250mm as clients request
|
|
|
|
|||
|
Technique
|
Cold rolled
|
|
|
|
|||
|
Applications
(Common type)
|
Large motors,Large transformers,Medium and small transformers,Distributing transformers,Voltage regulator,Reactor and magnetic amplifier,Mutual inductor,TV transformer,Radio transformer etc.
|
|
|
|
|||
|
Samples
|
Free
|
|
|
|
|||
|
MOQ
|
25 ton
|
|
|
|
|||
|
Origion
|
Bao Steel
|
|
|
|
|||
Detailed parameters of B23G110 B18P075 B23R080(Sample)
Please contact us if you would like a detailed parameter sheet for other grades
Details Images
Production Flow
Packing & Delivery
Standard Marine packing, can be customized according to customer requirements.
1) Bundle 2) In Bulk 3) Water proof plastic wrap.
20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high)
40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high)
40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high)
1) Bundle 2) In Bulk 3) Water proof plastic wrap.
20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high)
40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high)
40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high)
