No
|
Model
|
RF-435
|
|
|
||
|
1
|
heating zones numbers
|
4 zones ( up 4 + down 4 )
|
|
|
||
|
2
|
heating zone length
|
1400mm
|
|
|
||
|
3
|
heating method
|
up hot air down infrared
|
|
|
||
|
4
|
cooling zones number
|
1 zone
|
|
|
||
|
5
|
mesh belt width
|
300mm
|
|
|
||
|
6
|
transport direction
|
left to right
|
|
|
||
|
7
|
mesh belt height
|
350±20mm
|
|
|
||
|
8
|
transport speed
|
0-1800mm/min
|
|
|
||
|
9
|
power supply
|
3 phase 380V
|
|
|
||
|
10
|
start power
|
18 kw
|
|
|
||
|
11
|
working power
|
Approx 5 KW
|
|
|
||
|
12
|
temperature range
|
room temperature to 300
|
|
|
||
|
13
|
warm up time
|
about 15 minutes
|
|
|
||
|
14
|
temperature control method
|
DIP + SSR driven
|
|
|
||
|
15
|
temperature accuracy
|
±1℃
|
|
|
||
|
16
|
size
|
L2500 *W 645*H 1350 mm
|
|
|
||
|
17
|
weight
|
300 kg
|
|
|
||
