30000m3 /year aac cable and hebel aac block and aac block production line price
30000m3 /year aac cable and hebel aac block and aac block production line price
30000m3 /year aac cable and hebel aac block and aac block production line price
30000m3 /year aac cable and hebel aac block and aac block production line price
30000m3 /year aac cable and hebel aac block and aac block production line price
30000m3 /year aac cable and hebel aac block and aac block production line price
30000m3 /year aac cable and hebel aac block and aac block production line price
30000m3 /year aac cable and hebel aac block and aac block production line price

30000m3 /year aac cable and hebel aac block and aac block production line price

FOB Reference Price: Get Latest Price
≥1 Sets
US $400000
≥3 Sets
US $350000
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Brick size:
400*100*200 mm
Processing:
aerated autoclave concrete
Place of Origin:
Shandong, China
Brand Name:
HONGFA
Voltage:
According to clients volt
Dimension(L*W*H):
8200x6500x1850
Marketing Type:
Hot Product 2023
Weight (KG):
25000 kg
After-sales Service Provided:
Video technical support
Raw material:
sand or fly ash
mould size:
4.2x1.2x0.6m
side pallet size:
4.2x0.6m
Beater power:
7.5kw
ferry trolly size:
4..5x2.5x0.57m
Curing type:
steam curing
steam time:
7.5h
steam pressure:
1.3MPA
Autoclave temperature:
190℃

Quick Details

Type:
Aerated autocalved concrete machinery
Brick Raw Material:
Sand
Production Capacity (Pieces/8 hours):
150000m3/year
Brick size:
400*100*200 mm
Processing:
aerated autoclave concrete
Place of Origin:
Shandong, China
Brand Name:
HONGFA
Voltage:
According to clients volt
Dimension(L*W*H):
8200x6500x1850
Marketing Type:
Hot Product 2023
Weight (KG):
25000 kg
After-sales Service Provided:
Video technical support
Raw material:
sand or fly ash
mould size:
4.2x1.2x0.6m
side pallet size:
4.2x0.6m
Beater power:
7.5kw
ferry trolly size:
4..5x2.5x0.57m
Curing type:
steam curing
steam time:
7.5h
steam pressure:
1.3MPA
Autoclave temperature:
190℃
Product Description


aac production line

30000m3 /year aac cable and hebel aac block and aac block production line price

AAC (Autoclaved aerated concrete) block Main raw materials of AAC are siliceous material (sand, fly ash and Silicon tailings) and Calcium materials (lime and cement) mixed with foaming agent (aluminum powder). It is the product of light porous silicate through the following processes: batching, mixing, pouring, hardening, cutting, autoclaving and curing etc. Because of large amount of well-distributed tiny pores after foaming, it is named autoclaved aerated concrete.

Main Features

1. Light weight, can reduce the building's own weight and cost, and help improve the earthquake resistance of buildings
2. Good thermal insulation performance and low thermal conductivity
3. It has processability. It has the same processability as wood. It can be sawed, planed, drilled and nailed, which is conducive
to construction and can be operated on site.
4. Strong pressure resistance
5. The aerated block is resistant to high temperature, and the compressive strength of the aerated concrete is slightly increased
when the temperature is below 600 °C. When the temperature is around 600 °C, the compressive strength is close to the compressive
strength at normal temperature, so The fire performance of aerated concrete for building materials meets national first-class fire
protection standards.




The production AAC Block making machine process includes raw material preparation, batching pouring, static stop curing, cutting, autoclaving curing, out of autoclave and packing .

Specification of aac block making machine process


Raw material preparation section of AAC block making machine
1.Raw materials need to be ground before being processed. In order to meet the fineness requirements of the feed, block materials
such as quicklime and natural gypsum need to be crushed.

2.Grinding can give full play to the activity of the material;The ground slurry has better water retention and higher viscosity
due to the dissolution of some components , which can make the slurry have proper consistency and liquidity
Material Batching and Pouring process of aac block making machine
1.Measure various raw materials, adjust the temperature and concentration, and feed materials to the mixing equipment in sequence according to the process requirements
2.The pouring process is one of the unique processes that distinguish aerated concrete from other concretes. The prepared raw
materials are stirred to meet the specified time temperature and consistency requirements to obtain slurry, then pour into the
mold.
Static stop curing in curing section of aac block making machine
1.The poured mold is pushed into the resting room with a conveyor chain for initial gas generation and initial setting. The room
temperature is 50-70°C, and the time is 1.5-2 hours.
2.The resting process is mainly to promote the slurry to continue to complete the hardening process, so that the embryo body
reaches a certain hardness for cutting
Cutting section of aac block making machine
The cutting process is to divide and shape the AAC body to meet the appearance and size requirements. The cutting process reflects
the characteristics of air-entrained concrete, which is convenient for large-volume molding, flexible and diverse in shape and
size, and large-scale mechanized production
Out of autoclave section of aac block making machine
1.The poured mold is pushed into the resting room with a conveyor chain for initial gas generation and initial setting. The room
temperature is 50-70°C, and the time is 1.5-2 hours.
2.The resting process is mainly to promote the slurry to continue to complete the hardening process, so that the embryo body
reaches a certain hardness for cutting
Packing aac block section of aac block making machine
1.The poured mold is pushed into the resting room with a conveyor chain for initial gas generation and initial setting. The room
temperature is 50-70°C, and the time is 1.5-2 hours.
2.The resting process is mainly to promote the slurry to continue to complete the hardening process, so that the embryo body
reaches a certain hardness for cutting

AAC block products application


Packaging & Shipping
Successful case
Customer feedback
