Quick Details
-
Warranty:
-
25 YEARS
-
Brand Name:
-
xcsolar
-
Model Number:
-
Scientists
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
166*166mm, 182*182mm, 210*210mm
-
Product name:
-
Powerful Solar Panels
-
Application:
-
Home Commercial Solar System
-
Solar cell:
-
166*166mm, 182*182mm, 210*210mm
-
Junction Box:
-
IP68 Rated
-
Weight:
-
21- 27KG Contact
-
Max. Power:
-
150w~700w
-
Frame:
-
Black Anodized Aluminium Alloy
-
Glass:
-
3.2mm Tempered Low Iron
-
Certificate:
-
IEC,ISO,TUV
Quick Details
-
Cell size:
-
166mmx166mm/182*182mm/210*210mm
-
Type:
-
PERC, Half Cell, Bifacial, Double-glass, All Black, HJT, N-TYPE, TOPCON, BIPV
-
Panel Efficiency:
-
200-800w
-
Warranty:
-
25 YEARS
-
Brand Name:
-
xcsolar
-
Model Number:
-
Scientists
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
166*166mm, 182*182mm, 210*210mm
-
Product name:
-
Powerful Solar Panels
-
Application:
-
Home Commercial Solar System
-
Solar cell:
-
166*166mm, 182*182mm, 210*210mm
-
Junction Box:
-
IP68 Rated
-
Weight:
-
21- 27KG Contact
-
Max. Power:
-
150w~700w
-
Frame:
-
Black Anodized Aluminium Alloy
-
Glass:
-
3.2mm Tempered Low Iron
-
Certificate:
-
IEC,ISO,TUV
|
Model Number
|
72HTH-560M
|
72HTH-565M
|
72HTH-570M
|
72HTH-575M
|
72HTH-580M
|
72HTH-585M
|
|
Maximum Power (Pmax/W)
|
560
|
565
|
570
|
575
|
580
|
585
|
|
Open Circuit Voltage (Voc/V)
|
51.61
|
51.76
|
51.91
|
52.06
|
52.21
|
52.36
|
|
Short Circuit Current (Isc/A)
|
13.94
|
14.01
|
14.07
|
14.14
|
14.20
|
14.27
|
|
Voltage at Maximum Power (Vmp/V)
|
43.46
|
43.61
|
43.76
|
43.91
|
44.06
|
44.21
|
|
Current at Maximum Power (Imp/A)
|
12.89
|
12.96
|
13.03
|
13.10
|
13.17
|
13.24
|
|
Module Efficiency (%)
|
21.7
|
21.9
|
22.1
|
22.3
|
22.5
|
22.6
|
