Quick Details
-
Controller Type:
-
MPPT
-
Model Number:
-
APG3000
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
PYSUN
-
Continuous Max. Output Power:
-
3000W
-
Battery:
-
25.6V 120A
-
Photovoltaic Panel Access:
-
PV Voltage ≤ 100V, PV Current ≤ 30A
-
Ac Charging:
-
Input: AC165V-240V; Output: 29.2V/15A
-
Dc Output:
-
USB:5V/1A, 2.1A; DC: 12V/10A
-
Conversion Efficiency:
-
≥93%
-
Weight:
-
30KG
-
Size:
-
550mm*415mm*860mm
-
Operating Temperature:
-
-10℃-40℃
-
Storage Temperature:
-
-20℃-70℃
Quick Details
-
Power Source:
-
AC Adaptor, Solar Panel
-
Battery Type:
-
LiFePO4
-
Inverter Type:
-
Pure Sine Wave
-
Controller Type:
-
MPPT
-
Model Number:
-
APG3000
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
PYSUN
-
Continuous Max. Output Power:
-
3000W
-
Battery:
-
25.6V 120A
-
Photovoltaic Panel Access:
-
PV Voltage ≤ 100V, PV Current ≤ 30A
-
Ac Charging:
-
Input: AC165V-240V; Output: 29.2V/15A
-
Dc Output:
-
USB:5V/1A, 2.1A; DC: 12V/10A
-
Conversion Efficiency:
-
≥93%
-
Weight:
-
30KG
-
Size:
-
550mm*415mm*860mm
-
Operating Temperature:
-
-10℃-40℃
-
Storage Temperature:
-
-20℃-70℃
|
Model No.
|
APG3000
|
APG5000
|
|
|
Battery Parameters:
|
25.6V 120A
|
51.2V 100A
|
|
|
Weight:
|
30KG
|
75KG
|
|
|
Dimensions:
|
550mm*415mm*860mm
|
620mm*415mm*860mm
|
|
|
Input Voltage (VDC):
|
20-29.2V
|
40-55V
|
|
|
Output Frequency (Hz):
|
50/60Hz±5%
|
50/60Hz±5%
|
|
|
Output Power:
|
3000W
|
5000W
|
|
|
Max. PV Output Power:
|
5000W
|
9000W
|
|
|
Max. PV input Power&Current
|
PV input voltage ≤ 100V PV input current ≤ 30A
|
PV input voltage: 30-150V PV input current: ≤ 60A
|
|
|
Output Waveform:
|
Pure sine wave
|
Pure sine wave
|
|
|
Conversion Efficiency:
|
≥93%
|
≥93%
|
|
|
AC Charging Parameter:
|
Input: AC 165V-240V Output: 29.2V/15A
|
Input: AC 165V-240V
|
|
|
DC Output:
|
1.USB:5V/1A 2.1A
2.DC: 12V/10A
|
1.USB:5V/1A 2.1A
2.DC: 12V/10A
|
|
|
Inverter Protection Function:
|
Input under-voltage, over-voltage, anti-reverse connection protection, output overload, over-temperature, short-circuit protection.
|
|
|
|
Operating Environment Temperature:
|
-10~-40℃
|
-10~-40℃
|
|
|
Storage Environment Temperature:
|
-20~70℃
|
-20~70℃
|
|
|
Altitude:
|
0-15000m
|
0-15000m
|
|
Suzhou Joylive Intelligent Technology Co., Ltd.
was established in 2016 and is committed to "Smart Home Energy" solutions. The main products include
household energy storage systems
,
inverters
,
battery packs
,
portable power station
,
EV charger stations
, and villa lifts, etc. Our mission is to provide the safe, reliable, efficient and economical green energy solutions to the home users worldwide.
Customization is welcomed. If you have any interest on our products, or any question, please don’t hesitate to contact us.
Joylive, all for the joyful life!
Our household energy storage system adopts safer LiFePO4 battery technology. In the structural design, it adopts high
protection level, anti-mistouch design and the other technologies which greatly improve the safety of the products. Meanwhile, the users can check the operation status and power consumption of the equipment at any time via the App. With EMC, IEC62109, VDE4105, G99, EN50549, UN38.3, NRS097 and other international certificates, the high-quality operation and safety performance are ensured. Other advantages such as fast charging, easy installation, and long battery life. Welcome inquiry！
protection level, anti-mistouch design and the other technologies which greatly improve the safety of the products. Meanwhile, the users can check the operation status and power consumption of the equipment at any time via the App. With EMC, IEC62109, VDE4105, G99, EN50549, UN38.3, NRS097 and other international certificates, the high-quality operation and safety performance are ensured. Other advantages such as fast charging, easy installation, and long battery life. Welcome inquiry！
Our portable power station product covers battery capacities from 300Wh to 5000Wh, and battery life from 1000+ cycles to 6000+ cycles based on different types. The product integrates USB-A, USB-C, 220V AC sockets, solar charging, cigarette lighter, and DC5521 various interfaces.
Customization is welcomed. If you have any interest on our products, or any question, please don’t hesitate to contact us.
Joylive, all for the joyful life!
Q: What battery does the product use?
A:
It adopts high-quality lithium Ion NCM battery.
PYSUN Solar Power Station Portable Power Station 3000W Lithium Battery Mini Solar Energy Power Station Generator Outside
Q: What equipment can be powered by the AC output port of the product?
A:
With a rated power of 3000W,the AC output port can power most household appliances. Before use, please ensure that the total load power is below the rated power.
PYSUN Solar Power Station Portable Power Station 3000W Lithium Battery Mini Solar Energy Power Station Generator Outside
Q: How long can the product charge my device?
A:
This device will automatically estimate the remaining usage time according to the current load power, and display it in the Time Remaining section on the screen.
PYSUN Solar Power Station Portable Power Station 3000W Lithium Battery Mini Solar Energy Power Station Generator Outside
Q: How do I know if the product is charging?
A:
When charging, the input power will be showed on the screen, and the power circle flashes the cur『ent power level. At the same time, the charging indicator lights up.
PYSUN Solar Power Station Portable Power Station 3000W Lithium Battery Mini Solar Energy Power Station Generator Outside
Q: How to clean the product?
A:
Please wipe gently with a dry, soft, clean cloth or paper towel.
PYSUN Solar Power Station Portable Power Station 3000W Lithium Battery Mini Solar Energy Power Station Generator Outside
Q: How to store the product?
A:
Before storing, please turn off the product, and then store it in a dry, ventilated place indoors. Do not place it near water. For long-time storage, please charge the battery to more than 60% and make sure to charge it every three months to extend battery life.
PYSUN Solar Power Station Portable Power Station 3000W Lithium Battery Mini Solar Energy Power Station Generator Outside
Q: Can I bring my products on the airplane?
A:
No.
