Quick Details
-
Market Segement:
-
Mining transportation
-
Engine Capacity:
-
> 8L
-
Gross Vehicle Weight:
-
31000kg
-
Drive Wheel:
-
8*4
-
After-sales Service Provided:
-
Video technical support, Overseas Call Centers, Online support, Shop warranty
-
Place of Origin:
-
Shanxi, China
-
Gear Box Brand:
-
SHACMAN
-
Dimensions (L x W x H) (mm):
-
10329*2500*3450mm
-
Cargo Tank Dimension:
-
7400*2300*1500mm
-
Cab:
-
F3000 Cab,Single bed,Air conditioner
-
Payload(kg):
-
40000KG
-
Rated mass(kg):
-
13670kg
-
Tank capacity(L):
-
380L
-
Approach / departure angel:
-
16/66
-
Max. gradeability:
-
28 %
-
Axle number:
-
4
-
Color:
-
Optional
-
PTO:
-
QH50
Quick Details
-
Condition:
-
New
-
Horsepower:
-
351 - 400hp
-
Emission Standard:
-
Euro 2
-
Market Segement:
-
Mining transportation
-
Engine Capacity:
-
> 8L
-
Gross Vehicle Weight:
-
31000kg
-
Drive Wheel:
-
8*4
-
After-sales Service Provided:
-
Video technical support, Overseas Call Centers, Online support, Shop warranty
-
Place of Origin:
-
Shanxi, China
-
Gear Box Brand:
-
SHACMAN
-
Dimensions (L x W x H) (mm):
-
10329*2500*3450mm
-
Cargo Tank Dimension:
-
7400*2300*1500mm
-
Cab:
-
F3000 Cab,Single bed,Air conditioner
-
Payload(kg):
-
40000KG
-
Rated mass(kg):
-
13670kg
-
Tank capacity(L):
-
380L
-
Approach / departure angel:
-
16/66
-
Max. gradeability:
-
28 %
-
Axle number:
-
4
-
Color:
-
Optional
-
PTO:
-
QH50
Products Description
Dump
Truck F3000 on Sale
Product Parameters
|
SHACMAN F3000 8*4 DUMP TRUCK
|
|
|
|
Cab
|
F3000 Cab,Single bed,Air conditioner
|
|
|
Dimension(Lx W xH)(mm)
|
10329*2500*3450mm
|
|
|
Total mass(kg)
|
31000kg
|
|
|
Kerb mass(kg)
|
14600kg
|
|
|
Rated mass(kg)
|
15930kg
|
|
|
Payload(kg)
|
40000kg
|
|
|
Approach / departure angel
|
28/21
|
|
|
Front/rear suspension(mm)
|
14525/2029
|
|
|
Max. gradeability (%)
|
28
|
|
|
Engine brand
|
Weichai Engine
|
|
|
Engine model
|
WP10.340E32,340hp
|
|
|
Rated output power
|
250kw
|
|
|
Torque(N.m r. p. m)
|
1250N.m/1200-1600rpm
|
|
|
Rated speed(rpm)
|
2200rpm
|
|
|
Emission Standard
|
EU-II
|
|
|
Fuel type
|
Diesel
|
|
|
Displacement(L)
|
9.726L
|
|
|
Driving type
|
8*4
|
|
|
Axle number
|
4
|
|
|
Wheel base(mm)
|
1800+3575+1400mm
|
|
|
Clutch
|
φ430 diaphragm spring
|
|
|
Gearbox
|
FAST 10JSD140,10 Forward&2 Reverse,Manual
|
|
|
PTO
|
QH50
|
|
|
Front axle
|
7.5T MAN 2*7500kg
|
|
|
Rear axle
|
16T MAN 2*16000kg
|
|
|
Ratio
|
5.262
|
|
|
Steering
|
Top brand technology left-hand drive(LHD)
|
|
|
Type
|
12.00R20,12+1pc
|
|
|
Tank capacity(L)
|
380L
|
|
|
Max. speed (km/h)
|
82km/h
|
|
|
Color
|
Optional
|
|
|
Cargo box size(mm)
|
7400*2300*1500mm bottom10mm,side8mm
|
|
|
Lifting style
|
Front lifting(made in China)
|
|
