Quick Details
-
Brand Name:
-
SDDOM
-
Motor Power:
-
37kw*2
-
Charging Capacity:
-
3000L
-
Reclaiming capacity:
-
2000L
-
Speed of Mixing Drum:
-
14r/min
-
Water Supply Mode:
-
Water Pump
-
Working Cycle Period:
-
30s
-
Discharge Way:
-
Hydraulic Discharging
-
Outline Dimension:
-
3460x2320x2140 mm
-
Weight (KG):
-
2500 kg
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Product name:
-
Sicoma Standard MAO3000/2000 Twin Shaft Concrete Mixer for sale
-
Power type:
-
Electric Engine
-
Color:
-
Customer's Requirement
-
Keywords:
-
concrete cement mixer machine
-
Application:
-
Construction Industry
-
Model:
-
ktsa2000
-
Weight:
-
5.2t
-
Type:
-
Electric Twin Shaft Concrete Mixer
-
Name:
-
centrifugal planetary vertical mixer concrete mixer js1000 1m3
Quick Details
-
Mixing Power:
-
46kw
-
Productivity:
-
45m3/h
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
SDDOM
-
Motor Power:
-
37kw*2
-
Charging Capacity:
-
3000L
-
Reclaiming capacity:
-
2000L
-
Speed of Mixing Drum:
-
14r/min
-
Water Supply Mode:
-
Water Pump
-
Working Cycle Period:
-
30s
-
Discharge Way:
-
Hydraulic Discharging
-
Outline Dimension:
-
3460x2320x2140 mm
-
Weight (KG):
-
2500 kg
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Product name:
-
Sicoma Standard MAO3000/2000 Twin Shaft Concrete Mixer for sale
-
Power type:
-
Electric Engine
-
Color:
-
Customer's Requirement
-
Keywords:
-
concrete cement mixer machine
-
Application:
-
Construction Industry
-
Model:
-
ktsa2000
-
Weight:
-
5.2t
-
Type:
-
Electric Twin Shaft Concrete Mixer
-
Name:
-
centrifugal planetary vertical mixer concrete mixer js1000 1m3
|
Technical Parameter
|
|
Model
|
JS 750
|
JS 1250
|
JS 1500
|
JS 2000
|
JS 3000
|
JS 4000
|
|
Charging capacity(L)
|
1200
|
2000
|
2400
|
3200
|
4800
|
6400
|
|
Discharging capacity(L)
|
750
|
1250
|
1500
|
2000
|
3000
|
4000
|
|
Production capacity(m3/h)
|
42
|
75
|
90
|
120
|
180
|
240
|
|
Mixing axle rotation speed(r/min)
|
29.9
|
29.67
|
26.75
|
23.5
|
23.4
|
22.85
|
|
Mixer motor power(kw)
|
2*15
|
2*22
|
2*30
|
2*37
|
2*55
|
2*75
|
|
Librication oil pump
motor power(kw)
|
0.09
|
0.09
|
0.09
|
0.09
|
0.09
|
0.09
|
|
Hydraulic system
motor power(kw)
|
2.2
|
2.2
|
2.2
|
2.2
|
2.2
|
2.2
|
|
Electromagnetism valve
power supply(V)
|
DC24
|
DC24
|
DC24
|
DC24
|
DC24
|
DC24
|
|
Mixing time(s)
|
<=40
|
<=40
|
<=40
|
<=40
|
<=45
|
<=45
|
|
No. of mixing arm
|
12
|
12
|
16
|
16
|
18
|
22
|
|
Max diameter of
aggregate(Detritus/
Pebble)
|
60/80
|
60/80
|
60/80
|
80/120
|
100/150
|
100/150
|
|
External dimensions(LxWxH)
|
2900x
2650x
2100
|
3000x
2750x
2100
|
2900x
3000x
2150
|
3450x
3000x
2150
|
3900x
3300x
2230
|
4500x
3310x
2230
|
|
Transportation dimensions(LxWxH)
|
2900x
2100x
2100
|
3000x
2100x
2100
|
2900x
2320x
2150
|
3450x
2320x
2250
|
3900x
2600x
2230
|
4500x
2600x
2230
|
|
Entire machine weight(kg)
|
5000
|
5300
|
6500
|
7500
|
9300
|
11800
|
|
|
Main products
Mobile Concrete Batching Plant
Container cement Silo
Stackable Cement Silo
Planetary Mixer
Twin Shafts Mixer
Mobile Cement Silo
Bolted Cement Silo HZS type
Batching Plant
Big Bag Cement silo
1.Are you original manufacturer?
A: Yes. We SDDOM are factory in construction machinery in China with whole concrete mixing / silo storage convey
products you need.
2.What kind terms of payment can be accepted?
A: Normally we can work on T/T term or L/C term.
3.Which incoterm 2010 terms can we work?
A: Normally we work on EXW, FOB, CFR, CIF, DAP
4.What about the delivery time?
A: 7-30 days after receiving the deposit.
5.What about the warranty time?
A: 12 months after delivery generally.
6.What about the MOQ?
2.What kind terms of payment can be accepted?
A: Normally we can work on T/T term or L/C term.
3.Which incoterm 2010 terms can we work?
A: Normally we work on EXW, FOB, CFR, CIF, DAP
4.What about the delivery time?
A: 7-30 days after receiving the deposit.
5.What about the warranty time?
A: 12 months after delivery generally.
6.What about the MOQ?
A: MOQ 1 unit
