Quick Details
-
Model Number:
-
FXE UTV
-
Transmission:
-
CVT
-
Front & Rear tyre size:
-
25x8-12 / 25x10-12
-
Suspension Front:
-
Double A-arm Suspension
-
Suspension Rear:
-
4 Link Bar Rear Suspension
-
Max speed:
-
75km/h
-
Power type:
-
72V 5kw (3-5 kw available) DC PM Motor
-
Recharge mileage:
-
100Km
Quick Details
-
Certificate:
-
ce
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Fangpower
-
Model Number:
-
FXE UTV
-
Transmission:
-
CVT
-
Front & Rear tyre size:
-
25x8-12 / 25x10-12
-
Suspension Front:
-
Double A-arm Suspension
-
Suspension Rear:
-
4 Link Bar Rear Suspension
-
Max speed:
-
75km/h
-
Power type:
-
72V 5kw (3-5 kw available) DC PM Motor
-
Recharge mileage:
-
100Km
Product Description
|
MODEL
|
|
SUSPENSION / BRAKES
|
|
||
|
Rated power (kw)
|
72V 5kw (3-5 kw available) DC PM Motor
|
Suspension Front
|
Double A-arm Suspension
|
||
|
Controller
|
72V 300A Programmable Multi-Mode Controller
|
Suspension Rear
|
Fang power 4-Link® bar Rear Suspension
|
||
|
On-board charger
|
100-240V AC input; 72V/17A DC output CAN2.0
|
Brakes Front
|
220MM Front Dual Hydraulic Disk
|
||
|
Power battery
|
lithium iron phosphate 76.8V 106Ah
|
Brakes Rear
|
Rear Single Axle Hydraulic Disk
|
||
|
Charging time
|
5H
|
TIRES
|
|
||
|
Max speed
|
60KM/H
|
Front Tread
|
1250mm ( 49.2 in)
|
||
|
Recharge mileage
|
100Km
|
Rear Tread
|
1150mm ( 45.2in)
|
||
|
Battery water proof grade
|
IP67
|
Front & Rear tire size
|
25x8-12 / 25x10-12
|
||
|
DRIVETRAIN
|
|
MISC
|
|
||
|
Driveline Type
|
4X2
|
Loading information
|
8units/20″;; 24units/40HQ
|
||
|
Transmission
|
Constantly Variable Transmission F-N-R
|
Manufacturers Warranty
|
6 Months
|
||
|
Gear Selection
|
H-L
|
Top speed
|
75km/h
|
||
|
ELECTRICAL SYSTEM
|
|
Dry weight
|
400KGS
|
||
|
Forward Lights
|
Headlights-High & Low Beam LED LIGHT
|
Gross weight
|
470kgs
|
||
|
Rear Lights
|
Brake Lights & Left/Right Signal lights
|
Wheelbase
|
1980mm
|
||
|
Starting system
|
Electric start
|
Vehicle dimension(L×W×H)
|
2700x1450x1750mm
|
||
|
Ignition system
|
D.C.D.I
|
Packing size
|
2290x1400x815mm
|
||
|
Speed/Fuel meter
|
LED Meter
|
Ground clearance
|
300mm(11.8in)
|
||
|
Battery
|
12AH 12V
|
Safety
|
Driver & Passenger Seat belts/ Driver and Passenger safety net restraints.
|
||
