Quick Details
-
Brand:
-
AIXIN
-
Packaging:
-
Tray, Tray
-
Description:
-
spdif optical toslink connector
-
operating transfer rate:
-
25Mbps
-
Vcc:
-
2.7-5.5 V
-
fiber coupling:
-
-21~-25db
-
color:
-
black/gray/pink
-
Pin function:
-
1.GND 2.Vcc 3.Vin
-
Supplier Type:
-
Original manufacturer
Quick Details
-
Type:
-
fiber optic connector
-
Model Number:
-
DLT23M1
-
Place of Origin:
-
Guangdong, China
-
Brand:
-
AIXIN
-
Packaging:
-
Tray, Tray
-
Description:
-
spdif optical toslink connector
-
operating transfer rate:
-
25Mbps
-
Vcc:
-
2.7-5.5 V
-
fiber coupling:
-
-21~-25db
-
color:
-
black/gray/pink
-
Pin function:
-
1.GND 2.Vcc 3.Vin
-
Supplier Type:
-
Original manufacturer
Features
· High speed signal transmission
( 25 Mbps, NRZ signal )
· Input TTL compatible
· +3~+5V power source
Descriptions
The light transmitting unit is a standard-package product with connector and opto-electric component packaged with LED and drive IC. The function of unit changes the electric signal into light signal and be transmitted by plastic fiber.
The unit is operated at single+3V~ +5V and the input signal is TTL compatible. The DLT 23M1 has a maximum operating speed of 25 Mbps. The light signal is coupled into plastic fiber by connector. The unit has high performance at low dissipation current, steady light output and efficient light coupling.
Applications
· Audio equipment
· DVD player/Digical TV player
· PC, Notebook
· Sound card
Device Selection Guide
|
Chip |
Operating Voltage (Vcc) |
Dissipation Current(mA) |
Fiber Coupling Light Output (dBm) |
|
|||
|
IC Material |
LED λ p(nm) |
||||||
|
Typ. |
Min. |
Typ. |
Max. |
||||
|
Si |
650 |
2.7~5.5 |
5.5 |
-21 |
- |
-15 |
|
Package Dimensions
Notes: 1.All dimensions are in millimeters.
2.General Tolerance: ± 0.2mm
Pin Function
1. GND 2. Vcc 3. Vin
Reliability Test Items
|
No. |
Item |
Test Condition |
Test Hour/Cycle |
Samples |
Number (n) Failure (c) |
|
1 |
Soldering Heat |
260 °C ±5°C |
5 sec./2times |
22 |
n=22, c=0 |
|
2 |
High temp. & Hum. storage |
Ta=40°C, 90%RH |
500 |
22 |
n=22, c=0 |
|
3 |
High temp. storage |
Ta=80°C |
500 |
22 |
n=22, c=0 |
|
4 |
Low Temp. storage |
Ta=-30°C |
500 |
22 |
n=22, c=0 |
|
5 |
Temp. cycling |
-30 °C ~ 80°C (30min) (5min) (30min) |
20 |
22 |
n=22, c=0 |
|
6 |
High Temp. Operation life |
Ta=60°C, Vcc=5V ON |
500 |
22 |
n=22, c=0 |
|
7 |
Repeated operation |
500 times |
Coupling force < 2 kg 0.4kg <Detaching force <2kg |
22 |
n=22, c=0 |
|
8 |
Terminal Strength(tension) |
Weight: 500 g 30 sec./each terminal |
|
22 |
n=22, c=0 |
|
9 |
Terminal Strength(bending) |
Weight: 500 g 2 times/each terminal |
|
22 |
n=22, c=0 |
|
10 |
Mechanical Shock |
Acceleration: 1000m/s2 Pulse width: 6 ms 3 times/ X,Y,Z direction |
|
22 |
n=22, c=0 |
|
11 |
Vibration |
Frequency range: 10~55 Hz /sweep 1 min Overallamplitude:1.5 mm 2H./X,Y,Z direction |
|
22 |
n=22, c=0 |
Measuring Method
*1 Measuring method of optical output coupling fiber
2 Input voltage/power dissipation measuring method
3 Pulse response and jitter measuring method
PCB Layout For Electrical Circuit
Notes:
1. Unit:mm
2. Unspecified tolerance: ±0.3mm
3.Substrate Thickness:1.6mm
Precautions for Using Method
1.Connect a by-pass capacitor (0.1uF) close to the DLT 2 160A within 7 mm of the unit
lead frame.
2.Take proper electrostatic-discharge (ESD) precautions while handling these devices.
These devices are sensitive to ESD.
- 1. Please follow the conditions described in the diagram below.
Package
|
Item |
Quantity |
Total |
Size ( long*width*high ) |
|
Tray |
100 |
100 pcs |
13 . 5 * 27 * 1.8c m |
|
Inner box |
2 0 tray/box |
2 000 pcs |
29*29* 18.5 c m |
|
Outer box |
2 inner box/outer box |
4 000 pcs |
60*31* 21 .8 c m |
