Quick Details
-
Power (kW):
-
3.75
-
Product name:
-
clinch nut insertion machine
-
Application:
-
Metal Steel Parts Junction
-
Voltage:
-
220V/380V/400/415V/440Vcustomized
-
Nominal pressure:
-
2KN - 97KN
-
Fastener Range:
-
M2 - M12
-
Clinching Ability:
-
1mm to 6mm combined thickness
-
Leakproof counter:
-
Standard
-
Laser locating:
-
Option
-
Adjustable Stroke:
-
3/8"-6"(10-150mm)
-
Repeat Precision:
-
+/-1%
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
HPX
-
Weight (KG):
-
1100
-
Power (kW):
-
3.75
-
Product name:
-
clinch nut insertion machine
-
Application:
-
Metal Steel Parts Junction
-
Voltage:
-
220V/380V/400/415V/440Vcustomized
-
Nominal pressure:
-
2KN - 97KN
-
Fastener Range:
-
M2 - M12
-
Clinching Ability:
-
1mm to 6mm combined thickness
-
Leakproof counter:
-
Standard
-
Laser locating:
-
Option
-
Adjustable Stroke:
-
3/8"-6"(10-150mm)
-
Repeat Precision:
-
+/-1%
Products Description
|
Product Name
|
Fastener Insertion Machine
|
|
C Type Throat Depth
|
650mm (25.6")
|
|
C Type Throat Height
|
450mm (17.7"")
|
|
Stroke Length
|
0 to 8"(0 to 200mm)
|
|
Dual pump hydraulic system
|
200mm/second
|
|
Protection Press Hand System
|
Standard
|
|
Force Range
|
6KN - 97KN
|
|
Fastener Range
|
M12 Nut/ M10 Stud/ M6 Standoff in carbon steel
|
|
Dwell Time (holding pressure)
|
During 6 second
|
|
Adjustable Stroke
|
3/8"-6"(10-150mm)
|
|
Clinching Ability
|
1mm to 6mm combined thickness
|
|
Repeat Precision
|
+/-1%
|
|
Auto Feeding System
|
Option
|
|
Lot pre-miss rivet system
|
Standard
|
|
Laser Positioning Instruction
|
Option
|
|
Working Table height
|
1050MM(Adjustbale scope 80MM)
|
|
Gross Weight
|
1100KG
|
|
Input Power Capacity/Voltage
|
380V 3 phase 5 core 50-60HZ
|
|
Single Machine Dimesion(MM)
|
47"*66"*92"(1200*1700*2350mm)
|
Rrocessed Materials
