Ton:2 tons, 3 tons, 5 tons, 8 tons, 10 tons, 15 tons, 25 tons, 30 tons, 50 tons, 60 tons.
Driving type: 4x2, 6x4, 8x4 left hand drive / right hand drive
- Product Details
- {{item.text}}
Quick Details
-
Dimensions (L x W x H) (mm):
-
7480*2300*2500
-
Place of Origin:
-
HUB
-
Wheelbase:
-
3815mm
-
Tire Size:
-
7.50r16lt
Quick Details
-
Emission Standard:
-
Euro 3
-
Condition:
-
New
-
Brand Name:
-
Super-above
-
Dimensions (L x W x H) (mm):
-
7480*2300*2500
-
Place of Origin:
-
HUB
-
Wheelbase:
-
3815mm
-
Tire Size:
-
7.50r16lt
Products Description
Super-Above Brand New 4X2 Single Cab 2 Doors 2 Seats Diesel 5 Ton Left Steering Wrecker Towing Truck
Technical parameters
|
Vehicle Main Dimensions
|
Dimensions(L x W x H)mm
|
|
|
8490X2350X2410
|
|||
|
|
Wheel base (mm)
|
|
|
4475
|
|||
|
|
Overhang (front/rear) (mm)
|
|
|
1110/2905
|
|||
|
|
Wheel track (front/rear) (mm)
|
|
|
1680/1650
|
|||
|
|
Approach/Departure angle(°)
|
|
|
43364
|
|||
|
Weight in KGS
|
GVW.
|
|
|
9410
|
|||
|
|
Curb Weight
|
|
|
5670
|
|||
|
Max. driving speed(km/h)
|
|
|
|
95
|
|||
|
Allowable passengers in cab
|
|
|
|
2
|
|||
|
Engine
|
|
Model
|
|
4KH1-TC
|
|||
|
|
|
Type
|
|
4-stroke direct injection , 4cylinder in-line with water cooling, turbo-charging and inter-cooling
|
|||
|
|
|
Horse Power(HP)
|
|
190
|
|||
|
|
|
Emission standard
|
|
Euro2/3/4/5/6
|
|||
|
Platform organ
|
|
Length(mm)×Width(mm)
|
|
6200*2400
|
|||
|
|
|
Operating stroke(mm)
|
|
2680
|
|||
|
|
|
Min. angle of slope(°)
|
|
8
|
|||
|
|
|
Rated loading weight(kg)
|
|
8000
|
|||
|
|
|
Rated winch traction weight(kg)
|
|
8000
|
|||
|
|
|
Length of steel wire rope(m)
|
|
21
|
|||
|
|
|
Ground clearance of cage floor(mm)
|
|
470
|
|||
|
Hoisting organ
|
|
Max. length of extended boom(mm)
|
|
1680
|
|||
|
|
|
Rated lifting weight(kg)
|
|
3635
|
|||
|
|
|
Max. extended lifting weight(kg)
|
|
2500
|
|||
|
|
|
Rated traction weight(kg)
|
|
10000
|
|||
|
|
|
Elevation of boom (upper/ lower)(°)
|
|
9~-10
|
|||
|
|
|
Max. length of extended boom(mm)
|
|
1680
|
|||
|
|
|
Rated lifting weight(kg)
|
|
3635
|
|||
|
Gearbox
|
|
5 forwards & 1 reverse
|
|
|
|||
|
Fuel tank (L)
|
|
120L
|
|
|
|||
|
Tire
|
|
8.25-16-14PR, 6 pieces+1 spare tire
|
|
|
|||
|
Operation control system
|
|
Electrically hydraulic control
|
|
|
|||
Details Images
Sales Service
About Us
Packaging & Shipping
FAQ
1:Are you original manufacture?
A:Yes, we are an official leading manufacture in constrution machinery in china and we have the whole series products you need.
2:What kind terms of payment can be accepted?
A:Normally we can work on T/T term or L/C term.
3:Whick incoterms 2010 terms can we work?
A:Normally we work on FOB,CFR,CIF.
4:What about the delivery time?
A:7-30 days after receving the deposit.
5:What about the warrenty time?
A:12 months afer shipment or 2000 working hours.
6:What about the Minimum Order Quantity?
A:The MOQ is 1 pcs.
