Quick Details
-
Place of Origin:
-
Ho Chi Minh City, Vietnam
-
Brand Name:
-
Kim Tin
-
Model Number:
-
AWS E 6013, E 6013, E7016
-
Operating Current:
-
-30℃-40℃
-
Application:
-
Welding steel materials
-
Product Name:
-
Welding Rod
-
Usages:
-
Welding Tool
-
Color:
-
Grey
-
Certification:
-
ABS, CWB, TUV, DB, JIS, CE, ISO9001
-
Keyword:
-
CARBON WELDING ELECTRODE AWS E6013
-
Advantage:
-
Small Splash
-
Type:
-
Manufaturer
-
Standard:
-
AWS A.5.1 E6013
-
Packing:
-
20kg/carton
-
Samples:
-
Freely
Quick Details
-
Material:
-
Carbon steel
-
Welding Current:
-
50-240A
-
Operating Temperature:
-
Standard Temperature
-
Place of Origin:
-
Ho Chi Minh City, Vietnam
-
Brand Name:
-
Kim Tin
-
Model Number:
-
AWS E 6013, E 6013, E7016
-
Operating Current:
-
-30℃-40℃
-
Application:
-
Welding steel materials
-
Product Name:
-
Welding Rod
-
Usages:
-
Welding Tool
-
Color:
-
Grey
-
Certification:
-
ABS, CWB, TUV, DB, JIS, CE, ISO9001
-
Keyword:
-
CARBON WELDING ELECTRODE AWS E6013
-
Advantage:
-
Small Splash
-
Type:
-
Manufaturer
-
Standard:
-
AWS A.5.1 E6013
-
Packing:
-
20kg/carton
-
Samples:
-
Freely
Product Description
|
Packing details
|
- 2.5mm: 2.5kg/box
- 3.2mm/4.0mm: 5kg/box
- 20kg/carton
|
|
|
|
|||
|
MOQ
|
5kg
|
|
|
|
|||
|
Warranty
|
3 years
|
|
|
|
|||
|
Payment
|
L/C, T/T
|
|
|
|
|||
Specification
|
Item
|
Value
|
|
Warranty
|
3 years
|
|
Customized support
|
OEM, ODM, OBM
|
|
Place of Origin
|
Vietnam
|
|
|
Ho Chi Minh City
|
|
Brand Name
|
Kim Tin
|
|
Model Number
|
AWS E 6013, E 6013, E7016
|
|
Material
|
Carbon steel
|
|
Operating Current
|
-30℃-40℃
|
|
Welding Current
|
50-240A
|
|
Operating Temperature
|
Standard Temperature
|
|
Application
|
Welding steel materials
|
|
Product Name
|
Welding Rod
|
|
Usages
|
Welding Tool
|
|
Color
|
Grey
|
|
Certification
|
ABS, CWB, TUV, DB, JIS, CE, ISO9001
|
|
Keyword
|
CARBON WELDING ELECTRODE AWS E6013
|
|
Advantage
|
Small Splash
|
|
Type
|
Manufaturer
|
|
Standard
|
AWS A.5.1 E6013
|
|
Packing
|
20kg/carton
|
|
Samples
|
Freely
|
Product Paramenters
Features and application:
- The cover of KT-421 is made out of titanium to ensure a favorable welding process.
- KT-421 low carbon steel welding rod is suitable for welding Carbon steel and low alloy steel with medium load structure such as: industrial factory structure, machine details, railing, iron door,....
- KT-421 low carbon steel welding rod is suitable for welding Carbon steel and low alloy steel with medium load structure such as: industrial factory structure, machine details, railing, iron door,....
- Welds are bright, easy to remove slag, clean slag, light electricity, less smoke, less splashing.
- It can be welded in all different welding positions: flat welding, horizontal welding, bare welding, ...
- Good arc priming sensitivity: the maximum dwell time for re-priming is not less than 60 seconds.
|
Wire Chemical Composition (%)
|
C
|
Mn
|
Si
|
P
|
S
|
|
|
0.10 max
|
0.35~0.55
|
0.35 max
|
0.030 max
|
0.030 max
|
|
Deposited Metal Mechanical Properties
|
Tensile Strength
(MPa)
|
Yield Strength
(MPa)
|
Elongation (%)
|
AKV Impact Energy at 0ºC (J)
|
|
|
430 min
|
345 min
|
24 min
|
50 min
|
|
Diameter (mm)
|
|
Ø 2.5
|
Ø 3.2
|
Ø 4.0
|
Ø 5.0
|
|
|
Length (mm)
|
|
300
|
350
|
400
|
400
|
|
|
Welding current (A)
|
Flat welding position
|
50-90
|
90-140
|
140-190
|
180-240
|
|
|
|
Overhead, vertical welding position
|
50-90
|
90-140
|
140-190
|
180-240
|
|
Usage instruction:
-
Fully prepare labor safety factors before welding. The welding power source should be stable.
- When the welding rod is wet, the solder is prone to smoke, splashing and instability. Therefore, the weld is pitted, it needs to be dried at 100
ºC
- 150
ºC
for 40-60 minutes before use.
- Removes oil and dirt from the surface of the solder.
- Ensure the weld gap, bevel the weld in accordance with the regulations to achieve a solid weld.
- Select the welding current according to the instructions to get a deep penetration weld, high workability.
