Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Meeblue
-
Product Name:
-
Wifi Bluetooth gateway W1
-
Power:
-
by USB cable
-
Demension:
-
80mm*60mm*11.5mm
-
Range:
-
100M in open area
-
Color:
-
Black, Customize.
-
Input:
-
5V, 500mA, mini-USB
-
Wireless:
-
IEEE 802.11b/g/n
-
Network modes:
-
Wi-Fi Direct, soft-AP
-
Frequency band:
-
2.400 to 2.484 GHz
-
Channel Bandwidth:
-
20MHz
Quick Details
-
Model Number:
-
W1
-
Application:
-
iBeacon/Eddystone/WIFI/location
-
Type:
-
bluetooth gateway
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Meeblue
-
Product Name:
-
Wifi Bluetooth gateway W1
-
Power:
-
by USB cable
-
Demension:
-
80mm*60mm*11.5mm
-
Range:
-
100M in open area
-
Color:
-
Black, Customize.
-
Input:
-
5V, 500mA, mini-USB
-
Wireless:
-
IEEE 802.11b/g/n
-
Network modes:
-
Wi-Fi Direct, soft-AP
-
Frequency band:
-
2.400 to 2.484 GHz
-
Channel Bandwidth:
-
20MHz
Meeblue Profile
Meeblue is a creative technology design and development company based in Shenzhen China. Having developed a variety of smart bluetooth solutions across different industries, we are devoted to IOT solutions and indoor navigation flied. We are focused on R&D and manufacture mobile Internet technology products, including hardware production, firmware building, software development and electronics engineering.
Product Details
BLE and WIFI gateway for data collection and uploading
Bluetooth Beacon Gateway is a powerful IoT Gateway, which scans nearby Bluetooth devices and upload to server via 3G/4G cellular/Wi-Fi/Ethernet connectivity beacon gateway without using smartphones or apps. The Beacon Gateway collects the data from iBeacon, Eddystone, BLE sensor and other BLE 4.0/4.1/4.2/5.0 devices, and upload to the local or remote cloud server by MQTT/HTTPS protocol over 3G/4G, ethernet, Wi-Fi or WiFI hopping. And W1 Beacon Gateway also support update the beacons parameter remotely.
W1 Bluetooth gateway support GPS function, it can use for monitoring temperature in cold chain logistics, asset tracking real-time GPS locations.
Work Flow
Product Specifications
|
|
Values
|
Remarks
|
|
Chipset
|
Nordic52832 QFAA
|
|
|
Size
|
80mm*60mm*11.5mm
|
not including antenna
|
|
Frequency band
|
2.400 – 2.484 GHz
|
|
|
Input
|
5V, 500mA, mini-USB
|
Low power consumption, 70mA typical working current
|
|
Bluetooth Range
|
100M range in open space
|
|
|
Wifi
|
2.4GHz frequency band
|
Connect to Cloud server or local server；100M range in open space
|
Support
|
Tool app
|
CheckBlue
|
|
SDK or Demo
|
ios and Android
|
|
Update
|
OTA
|
|
Wi-Fi / Ethernet / Cellular
|
Yes
|
|
iBeacon/Eddystone/Kensor and other BLE device
|
Yes
|
|
HTTP/HTTPS MQTT/TLS MQTT
|
Yes
|
|
WiFi Enterprise Encryption
|
Yes
|
|
Powerful Network Diagnostics
|
Yes
|
|
Hardware level WatchDog, ensure 24-hours Full Time Data Upload
|
Yes
|
|
Optional 4G LTE module & GPS module
|
Yes
|
|
Web portal for configuration
|
Yes
|
|
CE/FCC Certified
|
Yes
|
