Quick Details
-
Power (kW):
-
7.87
-
Name:
-
oscillating slot mortising machine
-
main spindle motor:
-
3kw*2
-
shake motor:
-
370w
-
oil pumg motor:
-
1.5kw
-
spindle speed:
-
6000r/min
-
min distance between spindles:
-
50mm
-
mortise thickness:
-
3-16mm
-
max mortiser depth:
-
100mm
-
max mortiser length:
-
100mm
-
table size:
-
350*2200mm
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
xinhonghui
-
Weight (KG):
-
1700 KG
-
Power (kW):
-
7.87
-
Name:
-
oscillating slot mortising machine
-
main spindle motor:
-
3kw*2
-
shake motor:
-
370w
-
oil pumg motor:
-
1.5kw
-
spindle speed:
-
6000r/min
-
min distance between spindles:
-
50mm
-
mortise thickness:
-
3-16mm
-
max mortiser depth:
-
100mm
-
max mortiser length:
-
100mm
-
table size:
-
350*2200mm
Product Description
|
main spindle motor
|
3kw*2
|
|
shake motor
|
3700w
|
|
oil pumg motor
|
1.5kw
|
|
spindle speed
|
6000r/min
|
|
spindle number
|
14pcs
|
|
min distance between spindles
|
50mm
|
|
mortise thickness
|
3-16mm
|
|
max mortiser length
|
100mm
|
|
max mortiser depth
|
100mm
|
|
table size
|
350*2200mm
|
|
weight
|
1700kg
|
|
overall dimensions
|
3100*900*1550mm
|
Features
1
.Combining mortising and boring operations in a single machine.
2.Applicable to solid wood bed, children's bed and other furniture manufacturing milling tenon, drilling processing, One machine
have dual function- tenon hole and drilling , it is a preferred equipment for furniture production.
3.Adopt hydraulic feed system, milling tenon and drill more powerful, smooth, high precision.
4.Workbench with electric lift, manual fine-tuning, convenient and efficient, improving production capacity.
5.The main components of the machine using well-known foreign brands, reliable performance.
