Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Hongda
-
Voltage:
-
220V/380V/415V/660V
-
Dimension(L*W*H):
-
As the model
-
Marketing Type:
-
Hot Product 2021
-
Weight (KG):
-
100 kg
-
Product name:
-
Screw Conveyor
-
Application:
-
Chemical / Food / Mining Industry
-
Usage:
-
Conveying Material
-
Feature:
-
Smooth Running
-
Frame Material:
-
SUS304/Carbon Steel
-
Length:
-
Customized 1~100m
-
Advantage:
-
Long Operation Life
-
Motor:
-
Reduction Motor
-
Applicable Material:
-
Dry Powder / Granule
-
After-sales Service:
-
Problems Within 48 Hours
Quick Details
-
Power:
-
0.55KW-30KW
-
Warranty:
-
1 Year
-
Width or Diameter:
-
100mm
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Hongda
-
Voltage:
-
220V/380V/415V/660V
-
Dimension(L*W*H):
-
As the model
-
Marketing Type:
-
Hot Product 2021
-
Weight (KG):
-
100 kg
-
Product name:
-
Screw Conveyor
-
Application:
-
Chemical / Food / Mining Industry
-
Usage:
-
Conveying Material
-
Feature:
-
Smooth Running
-
Frame Material:
-
SUS304/Carbon Steel
-
Length:
-
Customized 1~100m
-
Advantage:
-
Long Operation Life
-
Motor:
-
Reduction Motor
-
Applicable Material:
-
Dry Powder / Granule
-
After-sales Service:
-
Problems Within 48 Hours
Screw feeder conveyor can be divided into:
1).U-type screw conveyor(Groove type).
2).Tubular screw conveyor
3).Shaftless screw conveyor
4).Flexible screw conveyor with wheels.
5).Vertical screw conveyor.
The screw conveyor can also be designed for horizontal conveying, inclined conveying and vertical conveying according to the application requirements. It can be used to replace the bucket elevator to reduce the manufacturing cost. It can be widely used in flour, coal powder, cement, raw meal, chemical industry, metallurgy and other powders. And the transportation of small granular fluid materials.
| Model | LS-100 | LS-160 | LS-200 | LS-250 | LS-315 | LS-400 | LS-500 |
| Screw Diameter (mm) | 100 | 160 | 200 | 250 | 315 | 400 | 500 |
|
Screw Pith (mm) |
100 | 160 | 200 | 250 | 315 | 355 | 400 |
|
Speed (r/min) |
140 | 112 | 100 | 90 | 80 | 71 | 63 |
|
Capacity (m³) |
2.2 | 8 | 14 | 24 | 34 | 64 | 100 |
Notes:The parameter above is just for reference,Model model pls inquiry us directly.We accept customization.
Features
1. good sealed, large capacity, long conveying distance.
2. good seal performance, good transportation efficiency!
3. flexible technological arrangement, easy to be installed , dismantled and moved, safe operation!
4. compact structure, small cross section, light weight!
5. LS screw conveyor can mixing, heating and colling in the process of conveying.
Applicable materials:
1).the fluidic or low-fluidity materials, like milk powder, Albumen powder, rice powder, coffee powder, solid drink, condiment, white sugar, dextrose, food additive, fodder, pharmaceuticals, agriculture pesticide, and so on.
2).Cement,fine sand,calcium carbonate clay powder, pulverized coal, cement, sand, grain, small piece of coal , cobble, and cast iron filings, etc.
3).Waster water,sludge,garbage etc.
Packaging: Usually wooden case for big model.Full container for big model.
Shipping: 5-7 working days for standard model,10-15 working days for customization model.
1).The capacity(Tons/Hour) that you require?
2).The conveying distance or the conveyor length?
3).The conveying angle?
4).Whats the material to be convey?
5).Other special requirement,like hopper,wheels etc.
