Quick Details
-
Brand Name:
-
-
-
Model Number:
-
CE8850E-32CQ-EI
-
Place of Origin:
-
Guangdong, China
-
Device Type:
-
Switch
-
Product Name:
-
Data center switch
-
Forwarding performance:
-
2003Mpps
-
Maximum power consumption:
-
244 W
-
Warranty:
-
1 Year / 12 Months
-
Chassis height(U):
-
1U
-
Dimensions (W x D x H):
-
442 mm*420 mm*43.6 mm
-
Chassis weight:
-
8.6 kg
-
Model:
-
CE8850E-32CQ-EI
Quick Details
-
Transmission Rate:
-
10/100Gbps
-
Communication Mode:
-
Full-Duplex
-
Switch Capacity:
-
6.4Tbps
-
Brand Name:
-
-
-
Model Number:
-
CE8850E-32CQ-EI
-
Place of Origin:
-
Guangdong, China
-
Device Type:
-
Switch
-
Product Name:
-
Data center switch
-
Forwarding performance:
-
2003Mpps
-
Maximum power consumption:
-
244 W
-
Warranty:
-
1 Year / 12 Months
-
Chassis height(U):
-
1U
-
Dimensions (W x D x H):
-
442 mm*420 mm*43.6 mm
-
Chassis weight:
-
8.6 kg
-
Model:
-
CE8850E-32CQ-EI
Products Description
New Original CloudEngine CE8850E-32CQ-EI high quality core switch CE8850E-32CQ-EI enterprise switches
|
Product Characteristics
|
|
1. High density 100GE/40GE convergence, super capacity 2. High reliability, long-distance stacking, excellent performance
3. High reliability of the entire network, with no perception of service in fault scenarios
4. Programmable network devices for flexible customization
5. Virtualization hardware gateway for rapid deployment 6. Zero configuration deployment of equipment, automatic operation and maintenance
7. Intelligent lossless network to meet the high performance requirements of RoCEv2 applications
8. Cooperate with iMaster NCE-FabricInsight to achieve Artificial Intelligence for IT Operations
9. Collaborate with iMaster NCE Fabric to achieve minimal deployment of data center networks
|
|
Item
|
|
CE8850E-32CQ-EI
|
|
|
Physical Features
|
Dimensions (W x D x H)
|
442 mm x 420 mm x 43.6 mm
|
|
|
|
Weight
|
8.6kg
|
|
|
|
Switching capacity
|
6.4Tbps/102.4Tbps
|
|
|
|
Forwarding performance
|
2003Mpps
|
|
|
Ports
|
|
32*100GE QSFP28 and 1*10GE SFP+
|
|
|
Card
|
Number of card slots
|
0
|
|
|
|
Card type
|
Fixed card
|
|
|
|
Card specification
|
N/A
|
|
|
Management
interface |
Out-of-band management
port |
1*GE RJ45 management interfaces
|
|
|
|
Console port
|
1*RJ45 interface
|
|
|
|
USB port
|
1
|
|
|
Power Supply
System |
working voltage
|
600W AC&240V DC power module:
AC: 90V AC~290V AC, 45Hz-65Hz;
DC: 190V DC~290V DC
1000W DC power module: -38.4V DC to -72V DC
1200W high-voltage DC power module: 190V DC~400V DC
|
|
|
|
Typical power consumption
|
203W (100% load, half port all copper cable, room temperature, dual AC power supply)
244W (100% load, half port full short distance Optical module, normal temperature, dual AC power supply)
|
|
|
Environment
specifications |
Long-term operating
temperature (°C) |
0°C to 40°C (0-1800 m)
The temperature decreases by 1°C each time the altitude increases by 220 m. |
|
|
|
Storage temperature (°C)
|
-40°C to +70°C
|
|
|
|
Relative humidity
|
5% to 95%
|
|
|
|
Operating altitude (m)
|
Up to 5000
|
|
|
|
Surge protection
|
AC power supply rotection: 6 kV in common mode and 6 kV in differential mode
DC power supply protection: 4 kV in common mode and 2 kV in differential mode |
|
Product Paramenters
|
Item
|
CE8850E-32CQ-EI
|
|
Device virtualization
|
iStack
|
|
|
M-LAG
|
|
Network virtualization
|
VXLAN in routing and bridging modes
|
|
|
BGP-EVPN
|
|
|
QinQ access VXLAN
|
|
Data center
interconnect (DCI) |
VXLAN mapping, implementing interconnection between multiple DCI networks at Layer 2
|
|
SDN
|
iMaster NCE-Fabric
|
|
Network
convergence |
DCBX, PFC, and ETS
|
|
|
RDMA and RoCE (RoCEv1 and RoCEv2)
|
|
|
FCoE
|
|
Programmability
|
OPS
|
|
|
Ansible-based automatic configuration and open-source module release
|
|
Traffic analysis
|
NetStream
|
|
|
sFlow
|
|
VLAN
|
Adding access, trunk, and hybrid interfaces to VLANs
|
|
|
Default VLAN
|
|
|
QinQ
|
|
|
MUX VLAN
|
|
|
GVRP
|
|
MAC address table
|
Dynamic learning and aging of MAC address entries
|
|
|
Static, dynamic, and blackhole MAC address entries
|
|
|
Packet filtering based on source MAC addresses
|
|
|
MAC address limiting based on ports and VLANs
|
|
IP routing
|
IPv4 routing protocols, such as RIP, OSPF, IS-IS, and BGP
|
|
|
IPv6 routing protocols, such as RIPng, OSPFv3, IS-ISv6, and BGP4+
|
|
IPv6
|
IPv6 Neighbor Discovery (ND)
|
|
|
IPv6 VXLAN over IPv4
|
|
|
Path MTU Discovery (PMTU)
|
|
|
TCP6, IPv6 ping, IPv6 tracert, IPv6 socket, UDP6, and raw IPv6
|
