Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
zz-motor
-
Model Number:
-
60BLF141-430
-
Torque:
-
1.28 nm
-
Place of origin:
-
Changzhou, China
-
Certification:
-
CE ISO ROHS
-
Brand:
-
ZZ-motor
-
Rated speed:
-
3000
-
Product name:
-
60BLF141-430
-
Diameter:
-
60mm*60mm
-
Motor length:
-
141mm
-
Motor weight:
-
2.05kg
-
VDC:
-
48V 24V 36V
Quick Details
-
Speed(RPM):
-
3000rpm
-
Continuous Current(A):
-
12 A
-
Efficiency:
-
IE 1
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
zz-motor
-
Model Number:
-
60BLF141-430
-
Torque:
-
1.28 nm
-
Place of origin:
-
Changzhou, China
-
Certification:
-
CE ISO ROHS
-
Brand:
-
ZZ-motor
-
Rated speed:
-
3000
-
Product name:
-
60BLF141-430
-
Diameter:
-
60mm*60mm
-
Motor length:
-
141mm
-
Motor weight:
-
2.05kg
-
VDC:
-
48V 24V 36V
Product Description
Electrical Specifications
|
型号 Model
|
60BLF78-430
|
60BLF99-430
|
60BLF120-430
|
60BLF141-430
|
|||
|
极数 Number oF poles
|
8
|
|
|
|
|||
|
相数 Number of phases
|
3
|
|
|
|
|||
|
额定电压 Nominal voltage VDC
|
48
|
24
|
24
|
24
|
|||
|
额定转速 Rated speed RPM
|
3000
|
|
|
|
|||
|
额定扭矩 Rated Torque N-m
|
0.32
|
0.65
|
0.95
|
1.28
|
|||
|
额定电流 Rated Current Amps
|
5.5
|
6.5
|
9.5
|
12
|
|||
|
输出功率 Output power Watts
|
100
|
200
|
300
|
400
|
|||
|
峰值扭矩 Peak Torque N-m
|
0.96
|
1.95
|
2.85
|
3.84
|
|||
|
峰值电流 Peak Current Amps
|
16.5
|
19.5
|
28.5
|
36
|
|||
|
力矩常数 Torque constant N-m/A
|
0.06
|
0.06
|
0.09
|
0.12
|
|||
|
反电势常数 Back EMF V/k RPM
|
4.2
|
4.2
|
6.4
|
8.4
|
|||
|
转动惯量 Rotor Inertia g.c㎡
|
0.24
|
0.48
|
0.72
|
0.96
|
|||
|
机身长度 Body Length (L) mm
|
78
|
99
|
120
|
141
|
|||
|
重量 Mass kg
|
0.85
|
1.25
|
1.65
|
2.05
|
|||
Our products
Products Application
Company Introduction
Chang zhou zhongzhi electric Motor and Electric Appliance CO LTD is a leading manufacturer of electric motors and control systems. Our core products include brushless dc motors,stepper motors,brushless DC servo motors, closed-loop hybrid stepper motors,linear motor and drivers. The products are mainly used in :laboratory equipments. Medical instruments,advertising equipments, subway equipments.,surveillance products,textile industry and other automation equipments
Changzhou zhongzhi motor has become one of the majopr solution provider for domestic and overseas motor and control system market due to its accurate market positioning,highly efficient and professional R&D team as well as high –quality products.
We insist on product innovation and strictly following the iSO9001 procedure and Rohs standard,our six series core products have been certified by CE and widely exported to Europe and many other countries.
Thanks to our high-quality products and excellent customer service. We have obtained great reputation among our domestic and foreign customers.
Changzhou zhongzhi motor has become one of the majopr solution provider for domestic and overseas motor and control system market due to its accurate market positioning,highly efficient and professional R&D team as well as high –quality products.
We insist on product innovation and strictly following the iSO9001 procedure and Rohs standard,our six series core products have been certified by CE and widely exported to Europe and many other countries.
Thanks to our high-quality products and excellent customer service. We have obtained great reputation among our domestic and foreign customers.
Certifications
Packing&Shipping
Packing
Packaging Details: Cartons and pallets
Port:ShangHai
Lead Time :20 days
Delivery
1.Carton box with foam
2.Box can be customized as you require
3.Usually 15-30days.
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: 100% T/T in advance
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: 100% T/T in advance
