Shock resistance, heat resistance and low temperature resistance Chemical resistance.
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Neider
-
Model Number:
-
ND-MF 12Way
-
External Size:
-
279*222*27
-
Product Name:
-
Power Distribution Box
-
Body material:
-
ABS
-
Transparent Door:
-
PC
-
Certificates:
-
CE, ROHS
-
Installation method:
-
Inside,Outside
Quick Details
-
Protection Level:
-
IP50
-
Type:
-
DISTRIBUTION BOX
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Neider
-
Model Number:
-
ND-MF 12Way
-
External Size:
-
279*222*27
-
Product Name:
-
Power Distribution Box
-
Body material:
-
ABS
-
Transparent Door:
-
PC
-
Certificates:
-
CE, ROHS
-
Installation method:
-
Inside,Outside
Parameter：
Body material: ABS
Transparent door: PC
Earth/Natural bars: Brass
Material characteristics: Impact, heat, low temperature and chemical resistance, excellent electrical performance and surface gloss, etc.
Certificates: CE, ROHS
Protection grade: IP50
Application: Suitable for indoor and outdoor electric, communication, fire fighting apparatus, iron and steel smelting, petrochemical industry, electron, power system, railway, building, mine, air and sea port, hotel, ship, works, waste water treatment equipment, environmental equipment and so on.
Installation: 1,Inside: There are din rail inside for din-rail type circuit breakers, earth bar and natural bar for cable connection.
2,Outside: The products can be directly fixed in the wall with screws or nails via the screw holes in the base.
Outlet hole: The plastic plate in the hole can be knocked off for cables.
|
Model Code
|
Outside Dimenstion（mm）
|
|
|
|
|
|
N.Weight（KG）
|
Qty/Carton
|
Carton Dimenstion（cm）
|
|||||
|
|
L1
|
W1
|
H1
|
L
|
W
|
H
|
|
|
52.5*43*47
|
|||||
|
ND-MF 4Way
|
115
|
197
|
60
|
136
|
222
|
27
|
8.7
|
30
|
52.5*43*47
|
|||||
|
ND-MF 6Way
|
148
|
197
|
60
|
170
|
222
|
27
|
11.1
|
30
|
48.5*47.5*54
|
|||||
|
ND-MF 8Way
|
184
|
197
|
60
|
207
|
222
|
27
|
13.2
|
30
|
64*52.5*46.5
|
|||||
|
ND-MF 10Way
|
222
|
197
|
60
|
243
|
222
|
27
|
9.8
|
20
|
51*47.5*48.5
|
|||||
|
ND-MF 12Way
|
258
|
197
|
60
|
279
|
222
|
27
|
11
|
20
|
47.5*45*60.5
|
|||||
|
ND-MF 15Way
|
310
|
197
|
60
|
334
|
222
|
27
|
9.3
|
15
|
49.5*35.5*71
|
|||||
|
ND-MF 18Way
|
365
|
219
|
67
|
398
|
251
|
27
|
12.6
|
15
|
57.5*42*78
|
|||||
|
ND-MF 24Way
|
258
|
310
|
66
|
300
|
345
|
27
|
10
|
10
|
57*36.5*63
|
|||||
|
ND-MF 36Way
|
258
|
449
|
66
|
300
|
484
|
27
|
14.2
|
5
|
54*31.5*50.2
|
|||||
Pruduct Detail
1.ABS Material
—
2.Built In Bracket
—
35mm guide rail.
Easy installation，Prevent harm.
3.
Transparent Flip Design
—
Effective protection to reduce dust.
Dust prevention
FAQ
1. Q: What is your MOQ?
A: Our MOQ is 1 piece.
2. Q: what is your delivery time?
A: It will be within 3 working days if in stock. If no stock it depends on your quantity.
3.Q: What is your warranty ?
A: The warranty period of our products is 2 years.
4.Q: How about inspection?
A: We have the whole inspection system from raw material to end products, including transient test, delay test, mechanical life
test and so on.
5.Q: Is OEM and ODM OK for you?
A: Yes, we can do both OEM and ODM. We have the professional enginer team which can design and develop the mold to arrive
different customers’ requirement.
6.Q: May I become your Agent / Dealer?
A: Welcome! But please let us know your country/area fisrt, we will have a check and then talk about this. If you want any other
kind of cooperation, do not hesitate to contact us.
A: Our MOQ is 1 piece.
2. Q: what is your delivery time?
A: It will be within 3 working days if in stock. If no stock it depends on your quantity.
3.Q: What is your warranty ?
A: The warranty period of our products is 2 years.
4.Q: How about inspection?
A: We have the whole inspection system from raw material to end products, including transient test, delay test, mechanical life
test and so on.
5.Q: Is OEM and ODM OK for you?
A: Yes, we can do both OEM and ODM. We have the professional enginer team which can design and develop the mold to arrive
different customers’ requirement.
6.Q: May I become your Agent / Dealer?
A: Welcome! But please let us know your country/area fisrt, we will have a check and then talk about this. If you want any other
kind of cooperation, do not hesitate to contact us.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
