- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
M
-
Certification:
-
CE
-
Output Voltage:
-
12V/24V/48v
-
rotor diameter:
-
OEM
-
Start-up wind speed:
-
3m/s
-
Rated wind speed:
-
11m/s
-
Survival wind speed:
-
45m/s
-
Top net weight:
-
51/53/58kg
-
Wheel diameter:
-
2.6/2.88/3.2m
-
Number of blades:
-
3
-
Blades material:
-
Reinforced glass fiber
-
Magnet material:
-
NdFeB
-
Generator case:
-
Casting aluminum alloy
-
Control system:
-
Electromagnet/wind wheel yaw
Quick Details
-
Rated Power:
-
300/400/500/600/700/800//1000W
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Grees
-
Model Number:
-
M
-
Certification:
-
CE
-
Output Voltage:
-
12V/24V/48v
-
rotor diameter:
-
OEM
-
Start-up wind speed:
-
3m/s
-
Rated wind speed:
-
11m/s
-
Survival wind speed:
-
45m/s
-
Top net weight:
-
51/53/58kg
-
Wheel diameter:
-
2.6/2.88/3.2m
-
Number of blades:
-
3
-
Blades material:
-
Reinforced glass fiber
-
Magnet material:
-
NdFeB
-
Generator case:
-
Casting aluminum alloy
-
Control system:
-
Electromagnet/wind wheel yaw
Products Description
Product Features
1.Casting aluminum alloy body, compact, little vibration
2.Easy installation, tube or flange connection optional
3.Reinforced glass fiber blades,matched with optimized aerodynamic shape and structure,which enhance the wind energy utilization and annual output.
4.Tail adopts mechanical yaw technique, making it survive storm and run safely
5.Patented permanent magnet ac generator with special stator,effectively reduce torque, well match the wind wheel and generator,and ensure the performance of whole system.
6.Controller,inverter can be matched accroding to customers' specific needs
1.Casting aluminum alloy body, compact, little vibration
2.Easy installation, tube or flange connection optional
3.Reinforced glass fiber blades,matched with optimized aerodynamic shape and structure,which enhance the wind energy utilization and annual output.
4.Tail adopts mechanical yaw technique, making it survive storm and run safely
5.Patented permanent magnet ac generator with special stator,effectively reduce torque, well match the wind wheel and generator,and ensure the performance of whole system.
6.Controller,inverter can be matched accroding to customers' specific needs
Product Details
|
Model
|
300M
|
400M
|
|
|
Rated power
|
300W
|
400W
|
|
|
Rated voltage
|
12v/24v/48v
|
12v/24v/48v
|
|
|
Start-up wind speed
|
2.5m/s
|
2.5m/s
|
|
|
Rated wind speed
|
11m/s
|
11m/s
|
|
|
Survival wind speed
|
45m/s
|
45m/s
|
|
|
Top net weight
|
11.5kg
|
12kg
|
|
|
Wheel diameter
|
1.35m
|
1.55m/1.35m
|
|
|
Number of blades
|
3/5PIECE
|
|
|
|
Blades material
|
Nylon fiber
|
|
|
|
Generator type
|
Three phase permanent magnet AC synchronous generator
|
|
|
|
Magnet material
|
NdFeB
|
|
|
|
Generator case
|
Casting aluminum alloy
|
|
|
|
Control system
|
Electromagnet/wind wheel yaw
|
|
|
|
Speed regulation
|
Automatically adjust windward direction
|
|
|
|
Working temperature
|
-40°C - 80°C
|
|
|
|
Design life
|
20 y
|
|
|
