Quick Details
-
Brand Name:
-
KACON
-
Model Number:
-
HRF-MD212
-
Max. Current:
-
8A
-
Color:
-
Gray
-
Material:
-
Aluminum die-casting
-
Built-in Switch:
-
V type Micro Switch
-
Rated Current:
-
8A 220VAC
-
Contact Form:
-
1C
-
Degree of Protection:
-
IP54
-
Certification:
-
CE, CCC
Quick Details
-
Whether the smart:
-
NO
-
Max. Voltage:
-
220VAC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
KACON
-
Model Number:
-
HRF-MD212
-
Max. Current:
-
8A
-
Color:
-
Gray
-
Material:
-
Aluminum die-casting
-
Built-in Switch:
-
V type Micro Switch
-
Rated Current:
-
8A 220VAC
-
Contact Form:
-
1C
-
Degree of Protection:
-
IP54
-
Certification:
-
CE, CCC
| Part Number | HRF-MD212 |
| Contact Form | 1C(1a+1b) |
| Rated Current | 8A 250VAC |
| Built-in Switch | V15F-01C(CE, UL certified) + 24k gold plated |
| Material | Aluminium Alloy |
| Cable outlet | 0.5mm² × 3 Wire × 2m |
| Certification | CE, CCC |
| Degree of Protection | IP54 |
| Contact Resistance | <50mΩ |
| Insulation Resistance | above 100mΩ at 500VDC |
| Withstand Voltage | ≥2000VAC(one minute) |
| Mechanical Life | above 10 6 times |
| Electrical Life | above 10 5 times |
| Operating Temperature | -25℃ ~ +70℃ |
| Operating Humidity | 45%≤85%RH |
| HRF-HD, MD Series Part Number Description | |||
| HRF-1, 2, 3, 4 | |||
| 1, Type | M: Medium Duty Type | H: Heavy Duty Type | |
| 2, Material | No mark: Plastic | D: Die-Casting | |
|
3, Safety Cover
(H type only) |
N: top | NX: top + side | NS: top + side + front |
| LX: top + side + safety kick lever | |||
| 4, Operator Type | No mark: Momentary | 3: Maintained | |
Yueqing Cleanlysis Import & Export Co., Ltd. is located in Xinguang Industrial Zone, Liushi town, Wenzhou city, Zhejiang province, China. It's 11 km from the train station, 39 km from the airport.
Main products are industrial relay for auto control, relay socket, time switch, foot switch, AC contactor and so on.
We've got OEM service experience for customers from UK, Germany, Malaysia and so on. MOQ as low as 50 pcs is available for some of our products, such as time switches.
As an officially authorized agent of Korea Kacon Auto Controls Import&Export Co., Ltd, we provide a discount rate of Kacon foot switch, limit switch, micro switch, relay, push button, etc.
