- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
NLK
-
Model Number:
-
NLK-DM001
-
Network:
-
Digital USB camera
-
Video Compression Format:
-
MJPG/YUY2/H.264/H.265
-
CMOS:
-
1/2.9" Sony Starvis WDR senDigital USB sor camera
-
Resolution:
-
1920*1080P
-
Lens:
-
from 2.1mm to 50mm lens
-
IR LED:
-
18Pcs IR Leds, 5M IR distance
-
IR-CUT:
-
Support
-
Waterproof:
-
IP67
-
Power:
-
12V DC/120mA without IR
-
Net Weight:
-
300
-
USB cable:
-
0.6M to 5M for optional
-
Size:
-
94mm(D)*85mm(H)
Quick Details
-
Function:
-
Wide Angle, One-way Audio, NIGHT VISION, Built-in Mic, Infrared USB camera with WDR
-
Data Storage Options:
-
Full HD, Computer Hard Disk
-
Place of Origin:
-
China
-
Brand Name:
-
NLK
-
Model Number:
-
NLK-DM001
-
Network:
-
Digital USB camera
-
Video Compression Format:
-
MJPG/YUY2/H.264/H.265
-
CMOS:
-
1/2.9" Sony Starvis WDR senDigital USB sor camera
-
Resolution:
-
1920*1080P
-
Lens:
-
from 2.1mm to 50mm lens
-
IR LED:
-
18Pcs IR Leds, 5M IR distance
-
IR-CUT:
-
Support
-
Waterproof:
-
IP67
-
Power:
-
12V DC/120mA without IR
-
Net Weight:
-
300
-
USB cable:
-
0.6M to 5M for optional
-
Size:
-
94mm(D)*85mm(H)
1080p Ultra Hd Pc Camera 180 Degree Wide Angle for Vehicle/KIOSK/Cabinet/Vender machines USB OEM Camera module
1.Main Features
· SONY IMX307 STARVIS Sensor, 1/2.8 inch 2 Mega
· Built-in ISP processing
· USB2.0 Interface,USB Video Class( UVC )
· Data fromat : YUY2 / MJPG / H.264
· Standard lens mount
· IR-CUT circuit
· BLC, Digtal WDR, 2D/3D noise reduction, Anti-fog
(1) Double layer front Glasses
(2) IP67 waterproof camera
(3) Provide accessories
2, Main Parameters
|
Technical Details |
|
|
SENSOR |
|
|
Sensor |
SONY IMX307LQD-C STARVIS |
|
Pixels |
2.07M pixels |
|
Resolution |
1920*1080 MAX |
|
Image Size |
Diagonal 6.46 mm (Type 1/2.8) |
|
Unit Cell Size |
2.9um (H)*2.9um(V) |
|
|
0.24lx |
|
ISP |
|
|
YUY2 Frame Rate |
640*360@25fps / 30fps |
|
MJPG Frame Rate |
1920*1080@25fps / 30fps, 1280*720@50fps / 60fps, 640*360@25fps / 30fps |
|
H.264 Frame Rate |
1920*1080@25fps / 30fps, 1280*720@50fps / 60fps, 640*360@25fps / 30fps |
|
Exposure |
Auto or Manual |
|
White Balance |
Auto or Manual |
|
Shutter |
1/25(1/30)s to 1/50,000s |
|
Slow Shutter |
Coming Soon |
|
Denoising |
2D/3D noise reduction |
|
Image Setting |
Brightness, Contrast, Sharpness, Saturation,Flip, Mirror |
|
Image Enhancement |
BLC, Digtal WDR, Defog |
|
WDR |
100db |
|
Day/Night Switch |
Manual or IR-CUT filter with external trigger |
|
Lens & IR-CUT |
|
|
Lens Mount with IR-cut |
Support M12*0.5 ,f =2.8mm, viewing angle(diagonal) = 128 ° |
|
Mounting Hole |
2 screw holes with diameter of 2.2mm,20mm Center-to-Center Spacing |
|
Interface |
|
|
Connector |
MX1.25*4,USB2.0 Interface |
|
Communication Interface |
USB2.0,UVC Protocol |
|
IR-CUT Control |
IR-CUT motor control, 3.3VDC |
|
Day/Night External Trigger |
3.3VDC to 5VDC compatibility |
|
General |
|
|
Operating Conditions |
-10℃~60℃, Humidity 95% or less, non-condensing |
|
Power Supply and Consumption |
5VDC ,1.5W MAX |
|
LED BOARD |
|
|
Power Supply and Consumption |
5VDC , 0.75 W MAX , 12Ø5 850NM LED+IR-ENSOR |
|
LED life |
≥3W hours |
|
Dimension |
38mm*38mm*10mm(not include lens and lens mount) |
Q1: Can I get some samples? Are they free?
A1: Of course you can get sample for testing before bulk order, but samples are not free.
Q2: What's the delivery time?
A2: Depend on product and quantity of your order. Usually, samples can be sent to you in 3 work days after your payment.
Q3: What about payment methods?
A3: Payment terms: Online payment, T/T and Western Union etc.
Q4: Can you list the product of your company?
A4: CCTV camera board,USB Web camera board,LCD memory controller board,LCD display module,Intercom Audio Board,Video Camera board for optical fiber tester
Q5: Where can we download the user manual of your products?
A5: Datesheet will be sent to you by email after get your email.
Q6: Warranty time?
A6: 2 years.
Q7: Can you accept ODM products?
A7: Yes,ODM is our main business. We will make quotation according to your details.
Q8: Product OEM?
A8: Yes, need your Gerber file and Drawing and BOM.
Q9: Customer service?
A9: Any questions of product after you receipt,please contact us,we'll reply you in 24 hours.
Q10: What shiping methods do you have?
A10: Since our products are small and expensive, the common shiping methods are post air mail or fast express.
