stainless steel wire mesh
is widely used in daily use, petroleum, chemical, food, pharmaceutical, and classifiction, screening and screening of solid, liquid and gas in the fields of mining, metallurgy, aerospace, and mechanical manufacturing.
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Hebei, China
-
Model Number:
-
DCP001
-
Brand Name:
-
Dongce
-
Feature:
-
Corrosion Resistance
-
Color:
-
Silver
-
Surface treatment:
-
stainless steel
-
Length:
-
1-30m
-
Packing:
-
Wooden Box
-
Width:
-
0.5-2m
-
Hole shape:
-
Square Hole
-
Usage:
-
Construction
Quick Details
-
Material:
-
wire mesh
-
Type:
-
stainless steel woven mesh
-
Application:
-
Screen
-
Place of Origin:
-
Hebei, China
-
Model Number:
-
DCP001
-
Brand Name:
-
Dongce
-
Feature:
-
Corrosion Resistance
-
Color:
-
Silver
-
Surface treatment:
-
stainless steel
-
Length:
-
1-30m
-
Packing:
-
Wooden Box
-
Width:
-
0.5-2m
-
Hole shape:
-
Square Hole
-
Usage:
-
Construction
Products Description
|
Material
|
SUS/AISI 201 202 3052 304 304L 316 316L 410 46360 904L stainless steel wire
|
|
Wire diameter
|
0.015-2.03mm
|
|
Weave type
|
Plain/Twill/Dutch weave
|
|
Mesh count
|
Plain weave can be woven up to 400 mesh.
Twill weave can be woven from 2 to 635 mesh.
Dutch weave can be woven up to 500*3500 mesh.
Reverse dutch weave can be woven up to 350*50 mesh.
|
|
Common size
|
1*30m roll usual, the width and length all can be customized
|
|
Features
|
Anti-acid and alkali, Anti-high temperature, Corrosion resistance, Good filter performance, Long using life.
|
|
Applications
|
In acid, alkali environment conditions sieving and filtering. Petroleum industry as mud mesh, Chemical fiber industry as screen mesh. Plating industry as acid cleaning mesh.
|
|
Sample
|
Free to provide
|
|
Customized
|
All sizes can be customized as per your demand.
|
Product Images
What industries are stainless steel wire mesh used in ?
Product Specifications
Stainless steel wire mesh
is made by stainless steel wire and then woven together to form a square opening or oblong opening.
Due to its own characteristics of stainless steel, the stainless steel mesh processed has high wear resistance, long service life, accurate mesh, uniform structure, no curl, easy to use, uniform screen thickness, anti static, anti-acid and alkali resistance Corrosion. The product has the characteristics of acid and alkali resistance, temperature resistance, wear resistance and other properties, therefore, in recent years, stainless steel net is widely used in many different fields.
This is the most commonly used weaving type. Each warp wire crosses alternately above and below each weft wire. Warp and weft wires generally have the same diameter.
The wires of the weft and the warp inter cross two above and two below, inverting the intersections of the warp wire at an established distance and obtaining a rigid, stable and robust type of wire mesh fabric
The wires of the weft and the warp inter cross two above with a larger weft wire than the warp. Such kind of wire mesh allows a greater difference between the diameter and the number of weft and warp wire.
