Quick Details
-
Bottle Volume(ml):
-
5000 ml
-
Place of Origin:
-
Chine
-
Brand Name:
-
FAYGO
-
Year:
-
2021
-
Voltage:
-
380
-
Dimension(L*W*H):
-
1.8*0.7*1.9
-
Hollow part volume:
-
5-10L
-
Power (kW):
-
40
-
Weight (KG):
-
1380 KG
-
Name:
-
blowing machine
-
Raw material:
-
PET
-
Usage:
-
bottle
-
Keywords:
-
energy saving and high speed
-
Product:
-
plastic bottles
-
Machine type:
-
CM-12
-
Capacity:
-
6500-8000
-
Feature:
-
High capacity
-
Suitable bottle:
-
Water
-
Delivery time:
-
30 Working Days
Quick Details
-
Neck Diameter(mm):
-
15 mm
-
Max.Bottle Diameter(mm):
-
200 mm
-
Max.Bottle Height(mm):
-
350 mm
-
Bottle Volume(ml):
-
5000 ml
-
Place of Origin:
-
Chine
-
Brand Name:
-
FAYGO
-
Year:
-
2021
-
Voltage:
-
380
-
Dimension(L*W*H):
-
1.8*0.7*1.9
-
Hollow part volume:
-
5-10L
-
Power (kW):
-
40
-
Weight (KG):
-
1380 KG
-
Name:
-
blowing machine
-
Raw material:
-
PET
-
Usage:
-
bottle
-
Keywords:
-
energy saving and high speed
-
Product:
-
plastic bottles
-
Machine type:
-
CM-12
-
Capacity:
-
6500-8000
-
Feature:
-
High capacity
-
Suitable bottle:
-
Water
-
Delivery time:
-
30 Working Days
FULLY-AUTOMATIC LINEAR BOTTLE BLOWING MACHINE
Product Overview
1.SMART series of blowing machine fills the gaps in the domestic high-speed linear blowing machine. Currently, China linear single-mold speed still stays around 1200BPH, while international max single-mold has reached 1800BPH. High-speed linear blowing machines rely on imports.
2.In view of this situation, Faygo Union Machinery developed China first high speed linear blowing machine: FG4. The single mold speed can reach 2000 BPH. FG4 has 4 cavities, production capacity is 8000BPH. It is developed completely independently, has ourown intellectual property rights, and has obtained more than 13 national patents.
3.The machine is equipped with automatic perform loading and unloading system. The machine is applicable for all shapes of drinking water bottles. FG4 is composed of three modules: perform elevator, perform unscrambler and host machine.
4.FG4 is completely new generation of linear machine, distinguished by its high speed, low power and low compressed air
comsumption, featured by the excellent structure design, small space occupation, less noise and excellent stability, meanwhile conforms to national beverage sanitary standards. It symbolizes the highest level of national linear blowing machine. It is the ideal bottle making equipment for beverage enterprises.
2.In view of this situation, Faygo Union Machinery developed China first high speed linear blowing machine: FG4. The single mold speed can reach 2000 BPH. FG4 has 4 cavities, production capacity is 8000BPH. It is developed completely independently, has ourown intellectual property rights, and has obtained more than 13 national patents.
3.The machine is equipped with automatic perform loading and unloading system. The machine is applicable for all shapes of drinking water bottles. FG4 is composed of three modules: perform elevator, perform unscrambler and host machine.
4.FG4 is completely new generation of linear machine, distinguished by its high speed, low power and low compressed air
comsumption, featured by the excellent structure design, small space occupation, less noise and excellent stability, meanwhile conforms to national beverage sanitary standards. It symbolizes the highest level of national linear blowing machine. It is the ideal bottle making equipment for beverage enterprises.
Advantages
The unique cam linking system integrates mold-opening, mold-locking and bottom mold-elevating in one movement, equipped with high speed servo driving system which greatly shortens the blowing cycle and accelerates the speed.
Equipped with remote monitoring system, engineers in China headquarter can check the data collected and sent by the PLC anytime with the mobile, feedback will be informed to the client' s site if something abnormal,give the machine 24 hours' baby care in the cradle.
Heater distance in the heating oven is minimized to 38.1mm, compared with the conventional heating oven, it saves more than 30% electricity consumption.
Equipped with the air cycling system and redundant heat discharge system, it ensures the constant temperature in the heating zone.
Equipped with the air cycling system and redundant heat discharge system, it ensures the constant temperature in the heating zone.
The machine adopts modularized design concept to make it convenient and cost-saving for the maintance and changing changeovers. To change mold only need 30 minutes.
Specification
|
Type
|
|
|
FG4
|
FG4F
|
FG6
|
FG8
|
Mark
|
||
|
Bottle specification |
Mould number(piece)
|
|
4
|
4
|
6
|
8
|
|
||
|
|
maxi volume (mL)
|
|
2000
|
1500
|
2000
|
750
|
|
||
|
|
maxi height (mm)
|
|
328
|
328
|
328
|
290
|
|
||
|
|
Round bottle max diameter (mm)
|
|
105
|
105
|
105
|
75
|
|
||
|
|
Max capacity(BPH)
|
|
6500-8000
|
4000-4500
|
9000-12000
|
13000-15000
|
|
||
|
preform Specifications
|
Suitable inner bottle neck (mm)
|
|
20-25
|
20-25
|
20-25
|
20-25
|
|
||
|
|
preform max length (mm)
|
|
150
|
150
|
150
|
140
|
|
||
|
Electricity |
Total installation power (kw)
|
|
51
|
63
|
51
|
97
|
|
||
|
|
Heating oven total power (kw)
|
|
46
|
58
|
46
|
92
|
|
||
|
|
Heating oven real power (kw)
|
|
22
|
28
|
26
|
38
|
|
||
|
|
Voltage / frequency (V / Hz)
|
|
380(50Hz)
|
380(50Hz)
|
380(50Hz)
|
380(50Hz)
|
|
||
|
|
Allowed voltage fluctuation range
|
|
±10%
|
±10%
|
±10%
|
±10%
|
|
||
|
Compressed air |
Pressure(bar)
|
|
30
|
30
|
30
|
30
|
|
||
|
|
Air consumption(m³/min)
|
|
4
|
4
|
6
|
8
|
|
||
|
Cooling Water |
Mold water |
Pressure(bar)
|
4-6
|
4-6
|
4-6
|
4-6
|
Water chiller
5HP |
||
|
|
|
Temperature regulation range(℃)
|
6-13
|
6-13
|
6-13
|
6-13
|
|
||
|
|
|
Flow rate (L / min)
|
45
|
45
|
45
|
45
|
|
||
|
|
Oven water |
Pressure(bar)
|
4-6
|
4-6
|
4-6
|
4-6
|
Water chiller 5HP |
||
|
|
|
Temperature regulation range(℃)
|
6-13
|
6-13
|
6-13
|
6-13
|
|
||
|
|
|
Flow rate(L / min)
|
22
|
22
|
22
|
22
|
|
||
|
Machine Specification
|
Machine dimension (m) (L*W*H)
|
|
3.8*1.3*2.3
|
4.3*1.3*2.3
|
4.8*1.3*2.3
|
5.5*1.3*2.3
|
|
||
|
|
Weight (Kg)
|
|
3500
|
3800
|
4500
|
5000
|
|
||
Application
