Quick Details
-
Application:
-
wire and cable ; etc.
-
Width:
-
10-600mm, 10-600mm
-
Grade:
-
copper tape, C1100,C1020,C10200,C10300,C10910,C11000
-
Model Number:
-
c1020
-
Brand Name:
-
shineworld, SHINEWORLD
-
Place of Origin:
-
Shanghai, China
-
Processing Service:
-
Slitting
-
Purity of Cu:
-
≥99.9%
-
Product Name:
-
Copper Foil
-
Appliaction:
-
Power Cable, XLPE cable and so on
-
Thickness:
-
0.05-2.0mm
-
Delivery Time:
-
10 days
Quick Details
-
Material:
-
copper
-
Cu (Min):
-
99.9%
-
Alloy Or Not:
-
Non-Alloy
-
Application:
-
wire and cable ; etc.
-
Width:
-
10-600mm, 10-600mm
-
Grade:
-
copper tape, C1100,C1020,C10200,C10300,C10910,C11000
-
Model Number:
-
c1020
-
Brand Name:
-
shineworld, SHINEWORLD
-
Place of Origin:
-
Shanghai, China
-
Processing Service:
-
Slitting
-
Purity of Cu:
-
≥99.9%
-
Product Name:
-
Copper Foil
-
Appliaction:
-
Power Cable, XLPE cable and so on
-
Thickness:
-
0.05-2.0mm
-
Delivery Time:
-
10 days
TECHNICAL SPECIFICATION FOR COPPER TAPE
The power cable copper foil, or also call copper foils. It has the clean surface, oil-free, deburred edge, high electrical conductivity, paper interleaving. Mainly used to manufacture shielding layer of power cable, which shields signal and interferes electromagnetism.
Product Properties：
◆ CLEAN SURFACE
◆
OIL-FREE
◆
DEBURRED EDGE
◆
HIGH ELECTRICAL CONDUCTIVITY
◆
PAPER INTERLEAVING
Why Choose Us：
◆
Excellent selection of materials
◆
Prompt delivery
◆
Various specifications
◆ A
dequate supply
◆
Attentive service
Product Paramenters
|
Properties
|
Unit
|
VALUE
|
|
Thickness
|
mm
|
0.05-2.0
|
|
Width
|
mm
|
10-600
|
|
Purity of Cu
|
%
|
≥99.9
|
|
Tensile Strength
|
N/mm
2
|
≥195
|
|
Resistivity at 20℃（Conductivity）
|
Ω·mm2/m（%IACS）
|
≤0.017241 (≥100%)
|
|
Standard
|
/
|
GB/T11091, JIS H3100, ASTMB152
|
|
Mark
|
/
|
C1100,C1020,C10200,C10300,C10910,C11000
|
Product Description
Excellent selection
Acceptable plasticity in cold state, good machinability, easy fiber welding and welding
Seiko production
Good mechanical properties, good plasticity in hot state
Higher purity
High purity, fine structure, low oxygen content
Wide range of applications
Can be used to manufacture wires, cables, brushes, magnetic instruments, meters, etc.
Details Images
Packing & Delivery
|
Item
|
Unit
|
VALUE
|
|
CID
|
mm
|
76,100,110,127,150,200 and so on
|
|
COD
|
mm
|
Max 580
|
|
Inner Core
|
/
|
AL or Paper
|
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
