Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM
-
Model Number:
-
V8
-
Product name:
-
Satellite
-
Color:
-
Yellow
-
Feature:
-
Mini Box
-
Warranty:
-
1 Year
-
Function:
-
Receiving Digital Signal
-
Support:
-
H.264/MPEG2/MPEG4
-
Key words:
-
TV Signal Booster Statellite Receiver
-
Tuner:
-
DVB-S2/S
-
Flash Memory:
-
64MB Serial Flash
-
Certification:
-
CE.
Quick Details
-
FTA(Free To Air):
-
Yes
-
Type:
-
Digital
-
High Definition:
-
Yes
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM
-
Model Number:
-
V8
-
Product name:
-
Satellite
-
Color:
-
Yellow
-
Feature:
-
Mini Box
-
Warranty:
-
1 Year
-
Function:
-
Receiving Digital Signal
-
Support:
-
H.264/MPEG2/MPEG4
-
Key words:
-
TV Signal Booster Statellite Receiver
-
Tuner:
-
DVB-S2/S
-
Flash Memory:
-
64MB Serial Flash
-
Certification:
-
CE.
Products Description
|
Model
|
Digital Satellite
|
|
|
Packing
|
1 set with a color box, 10 boxess put in a Carton
|
|
|
Warranty
|
13 months
|
|
|
Transmission standards
|
|
|
|
DVB-S/S2, H.264
|
|
|
|
Satellite input/demodulation
|
|
|
|
Connector type
|
F type
|
|
|
Input frequency
|
950 to 2150 MHz
|
|
|
Signal input level
|
-65 to 25 dBn
|
|
|
Band switch control
|
22KHz
|
|
|
LNB supply
|
13V/18V, Max 400mA
|
|
|
Demodulation type
|
QPSK, 8PSK
|
|
|
Symbol rate
|
2<Rs<45 MBAND(SCPC/MCPC)
|
|
|
LCD features
|
|
|
|
LCD type
|
TFT Transmissive
|
|
|
Numbers of Dots
|
320(RGB)*240
|
|
|
Active area(W*H)
|
70*52.5mn
|
|
|
AV output interface
|
|
|
|
Connector type
|
3.5mn Jack
|
|
|
Video output
|
CVBS, HD OUT
|
|
|
Audio output
|
Stereo audio L/F output
|
|
|
AV input interface
|
|
|
|
Connector type
|
3.5mn Jack
|
|
|
Video output
|
CVBS
|
|
|
Audio output
|
Stereo audio L/F output
|
|
|
Audio/Video processing
|
|
|
|
Video decompression
|
H.264, MP&HP@L4, HW JPEG decording
|
|
|
Resolving rate
|
PAL-25 frame@720*576, NTSC-30 frame@720*480
|
|
|
Signal compatibility
|
Support conversion for different video formats
|
|
|
Video format
|
4:3, 16:9, By Pan & Scan and Letter Box conversion
|
|
|
Audio compression
|
MPEG-1 Layer I/II MPEG-2 Layer I/II
|
|
|
Audio output mode
|
Stereo, Mono, R/L
|
|
|
Data service port
|
|
|
|
Connector
|
USB
|
|
|
Data protocol
|
USB2.0 interface
|
|
|
File management system
|
NTFS, FAT32, FAT16
|
|
|
File format
|
Wma, mp3, mp4, avi, jpg, jpeg, bmp, img
|
|
|
Power supply
|
|
|
|
Power supply
|
7.4V/3000mAh
|
|
|
Adapter
|
OUTPUT: DC12V/1.5A
INPUT: 100-240VAC 50/60Hz |
|
|
Power consumption
|
Max. 10W
|
|
|
PHYSICAL CHARACERTICS
|
|
|
|
Size(W*D*H)
|
95*155*45(mm)
|
|
|
Net weight
|
0.5kg
|
|
