Quick Details
-
Product name:
-
16 in 1 DVB-T Modulator
-
Input:
-
16*Tuner, 16 Tuner with CAM (DVB-T/-(T)/-S/-S2, ATSC, ISDB-T Optional)
-
Output:
-
16*DVB-C/T adjacent carriers
-
Application:
-
IPTV OTT System Total Solution
-
Standard:
-
J.83A (DVB-C), J.83B
-
Bandwidth:
-
6M, 7M, 8M
-
MER:
-
≥42 dB
-
Management:
-
web-based NMS support,Ethernet software upgrading
-
Input Frequency:
-
950-2150MHz
-
Keyword:
-
Modulator digital
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
WOLCK
-
Model Number:
-
WK-3394T
-
Product name:
-
16 in 1 DVB-T Modulator
-
Input:
-
16*Tuner, 16 Tuner with CAM (DVB-T/-(T)/-S/-S2, ATSC, ISDB-T Optional)
-
Output:
-
16*DVB-C/T adjacent carriers
-
Application:
-
IPTV OTT System Total Solution
-
Standard:
-
J.83A (DVB-C), J.83B
-
Bandwidth:
-
6M, 7M, 8M
-
MER:
-
≥42 dB
-
Management:
-
web-based NMS support,Ethernet software upgrading
-
Input Frequency:
-
950-2150MHz
-
Keyword:
-
Modulator digital
16 in 1 Mux-scrambling QAM Modulator
WK-3394T is a high performance and cost-effective QAM modulator designed by us. It supports 16 DVB-C (DVB-T/-(T)/-S/-S2/S2X, ATSC, ISDB-T optional) FTA tuner input, maximum 512 IP input through GE1 and TS input for re-mux through 2 ASI ports. After multiplexing, scrambling and QAM modulating, it gives 16 non-adjacent carriers output and 1 IP (MPTS) output through GE1.
WK-3394T is also characterized with high integrated level, high performance and low cost. It supports dual power supply (optional). This is very adaptable to newly generation CATV broadcasting system.
* 16 DVB-C (DVB-T/-(T)/-S/-S2/-S2X, ATSC, ISDB-T Optional) FTA Tuner + 2 ASI input+512 IP input thru GE1 over UDP and RTP protocol
* 16 DVB-C RF output
* 1 IP (MPTS) output over UDP and RTP/RTSP, as mirror of one carrier
* Support 16 groups multiplexing+16 groups scrambling +16 groups QAM modulating
* Excellent RF output performance index, MER≥40db
* Support accurate PCR adjusting
* Support PSI/SI editing and inserting
* Support Web management, Updates via web
* Redundancy Power Supply (optional)
* 16 DVB-C RF output
* 1 IP (MPTS) output over UDP and RTP/RTSP, as mirror of one carrier
* Support 16 groups multiplexing+16 groups scrambling +16 groups QAM modulating
* Excellent RF output performance index, MER≥40db
* Support accurate PCR adjusting
* Support PSI/SI editing and inserting
* Support Web management, Updates via web
* Redundancy Power Supply (optional)
|
Input |
16 DVB-C (DVB-T/-(T)/-S/-S2/-S2X, ATSC, ISDB-T Optional) FTA Tuner
|
|
|
|
|||
|
|
512 IP input through GE1 over UDP and RTP protocol
|
|
|
|
|||
|
|
2 ASI input, BNC interface
|
|
|
|
|||
|
Tuner Section |
Multi-mode tuners switchable
(New) |
|
Standard
|
J.83A(DVB-C), J.83B, J.83C
|
|||
|
|
|
|
Frequency In
|
60~890MHz
|
|||
|
|
|
|
Constellation
|
16/32/64/128/256 QAM
|
|||
|
|
|
|
Frequency In
|
60~890MHz
|
|||
|
|
|
|
Bandwidth
|
6/7/8 M bandwidth
|
|||
|
|
|
ISDB-T
|
Frequency In
|
60~890MHz
|
|||
|
|
Version 1 |
DVB-S/S2 |
Frequency In
|
950~2150MHz
|
|||
|
|
|
|
Symbol rate
|
QPSK 1~45Mbauds 8PSK 1~45Mbauds
|
|||
|
|
|
|
Code rate
|
1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10
|
|||
|
|
|
|
Constellation
|
QPSK, 8PSK
|
|||
|
|
Version 2 (New) |
DVB-S |
Frequency In
|
950~2150MHz
|
|||
|
|
|
|
Symbol rate
|
0.5~45Msps
|
|||
|
|
|
|
Signal Strength
|
- 65~-25dBm
|
|||
|
|
|
|
FEC
|
1/2, 2/3, 3/4, 5/6, 7/8
|
|||
|
|
|
|
Constellation
|
QPSK
|
|||
|
|
|
|
Max input bitrate
|
≤129 Mbps
|
|||
|
|
|
DVB-S2 |
Frequency In
|
950~2150MHz
|
|||
|
|
|
|
Symbol rate
|
QPSK/8PSK/16APSK: 0.5~45 Msps
32APSK: 0.5~40Msps; |
|||
|
|
|
|
FEC
|
QPSK: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10
8PSK: 3/5, 2/3, 3/4, 5/6, 8/9, 9/10 16APSK: 2/3, 3/4, 4/5, 5/6, 8/9, 9/10 32APSK: 3/4, 4/5, 5/6, 8/9, 9/10 |
|||
