Quick Details
-
Model Number:
-
PDA4800M
-
Output Power:
-
800W*4(8ohm) 1200W*4(4ohm)
-
Bridge Power (8ohm):
-
2400Wx2
-
Frequency:
-
20Hz-20KHz(+/-3dB)
-
Total Harmonic Distortion:
-
<0.05%
-
Noise:
-
<1mv
-
Slew Rate:
-
40V/uS
-
Damping Factor:
-
>300
-
Input Sensitivity:
-
1.2V
-
Input Impedance (ohm):
-
20K OHM
-
Input Connector:
-
3pin XLR,Balance Signal
Quick Details
-
Warranty:
-
3years
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CARD
-
Model Number:
-
PDA4800M
-
Output Power:
-
800W*4(8ohm) 1200W*4(4ohm)
-
Bridge Power (8ohm):
-
2400Wx2
-
Frequency:
-
20Hz-20KHz(+/-3dB)
-
Total Harmonic Distortion:
-
<0.05%
-
Noise:
-
<1mv
-
Slew Rate:
-
40V/uS
-
Damping Factor:
-
>300
-
Input Sensitivity:
-
1.2V
-
Input Impedance (ohm):
-
20K OHM
-
Input Connector:
-
3pin XLR,Balance Signal
Product Description
|
Model
|
PDA4800M
|
Frequency
|
20Hz-20KHz(+/-3dB)
|
||
|
Type
|
class d amplifier
|
Noise
|
<1mv
|
||
|
OUTPUT POWER(8Ω)
|
800Wx4
|
Slew Rate
|
40V/uS
|
||
|
OUTPUT POWER(4Ω)
|
1200Wx4
|
Damping Factor
|
>300
|
||
|
BRIDGE POWER(8Ω)
|
2400Wx2
|
Input Sensitivity
|
1.2V
|
||
|
Input Impedance(Ω)
|
20K OHM
|
Input Connector
|
3pin XLR,Balance Signal
|
||
|
Total Harmonic Distortion
|
<0.05%
|
Output Connector
|
Binding Post
|
||
|
Protection
|
Short-circuit protection,open circuit protection, overheating protection and RF protection, overload protection due to the DC fault
|
|
|
||
|
The Function for Color Screen
|
1. The Working Voltage,Currency, Temperature,and the impedance for each channel,operating power.2. Operation level for each channel; 3. choosing the working mode;4. High-Pass Filter; 5. Impedance Matching switchover;6. with the muting switch
|
|
|
||
|
Heat-Dissipating
|
Fan
|
|
|
||
|
Power Supply Voltage
|
(115V/230V)Different voltages can be provided according to different regions
|
|
|
||
|
Power Supply Fuse
|
20A/10A
|
|
|
||
