Quick Details
-
Warranty:
-
12 months
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
VLAIS
-
Model Number:
-
KDE-85T
-
Speed:
-
1500/1800rpm
-
Weight:
-
1250kg
-
Engine Model:
-
6BT5.9-G1/92kw
-
Cylinder Number and Bore*stroke(mm):
-
6 Cylinder and 102*120 mm
-
Engine type:
-
Water cooled, 4 Stroke, Vertical, Direct Injection,Turbo charge
-
Alternator brand:
-
Stamford, Marathon, Leroy somer
-
Alternator Type:
-
Self-excitation, Brushless, AVR, Single bearing, All Copper wire
-
Alternator Model:
-
CP-224F/60kw
-
Control panel:
-
Deepsea / Comap / Harsen / Smartgen 6110
-
Fuel Consumption at full load:
-
19.04L/H
-
Displacement and Compression Ratio:
-
5.9 L and 17.3:1
-
Dimension:
-
2400*1050*1350mm
-
Certification:
-
CE;ISO9001
Quick Details
-
Rated Voltage:
-
110V/220V/380V/440V
-
Rated Current:
-
129 A
-
Frequency:
-
50/60HZ
-
Warranty:
-
12 months
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
VLAIS
-
Model Number:
-
KDE-85T
-
Speed:
-
1500/1800rpm
-
Weight:
-
1250kg
-
Engine Model:
-
6BT5.9-G1/92kw
-
Cylinder Number and Bore*stroke(mm):
-
6 Cylinder and 102*120 mm
-
Engine type:
-
Water cooled, 4 Stroke, Vertical, Direct Injection,Turbo charge
-
Alternator brand:
-
Stamford, Marathon, Leroy somer
-
Alternator Type:
-
Self-excitation, Brushless, AVR, Single bearing, All Copper wire
-
Alternator Model:
-
CP-224F/60kw
-
Control panel:
-
Deepsea / Comap / Harsen / Smartgen 6110
-
Fuel Consumption at full load:
-
19.04L/H
-
Displacement and Compression Ratio:
-
5.9 L and 17.3:1
-
Dimension:
-
2400*1050*1350mm
-
Certification:
-
CE;ISO9001
Product Description
| The Paramter of Engine | Model: | 6BT5.9-G1/92kw |
| Displacement and Bore*Stroke | 5.9L and 102*120mm | |
| Engine type | Water cooled, 6 Cylinder, 4 Stroke, Direct Injection, Electronic Governor, Vertical In Line and Turbo charge | |
| Start-up | Electric start(DC24V) | |
| The Parmter of Alternator | Model: | CP-224G/68kw |
| Type: | AVR, Self-excited, All copper wire, Brushless and single bearing | |
| Electrical phase connection: | 3 phase 4 wire | |
| Insulation class/Protection class: | H/IP23 | |
| The Paramter of control system | Brand: | Mebay DC52D |
| High water temperature protection: | Yes | |
| High and low voltage/frequency: | Yes | |
| Low oil pressure pretection: | Yes | |
