Quick Details
-
Place of Origin:
-
Shandong, China
-
Dimension(Long * Breadth * High):
-
N/M
-
Machine Weight:
-
kg
-
Bucket capacity:
-
0.75 cbm, 1 cbm, 1.25 cbm, 1.5 cbm
-
Marketing Type:
-
Hot Product
-
Actuation Time:
-
12 s
-
Engine Type:
-
Diesel, 4-cylinder, 4-stroke,Water-cooled
-
Gradeability:
-
30°
-
Transmission Type:
-
Hydraulic, Automatic
-
Working Pressure:
-
20 MPa
-
Backhoe Bucket Capacity:
-
0.1 cbm, 0.15 cbm, 0.2 cbm, 0.3 cbm
-
After Warranty Service:
-
Video technical support
Quick Details
-
Engine Brand:
-
YUNNEI
-
Power:
-
37 kw, 58 kw, 76 kw, 92 kw
-
Brand Name:
-
SAAO
-
Place of Origin:
-
Shandong, China
-
Dimension(Long * Breadth * High):
-
N/M
-
Machine Weight:
-
kg
-
Bucket capacity:
-
0.75 cbm, 1 cbm, 1.25 cbm, 1.5 cbm
-
Marketing Type:
-
Hot Product
-
Actuation Time:
-
12 s
-
Engine Type:
-
Diesel, 4-cylinder, 4-stroke,Water-cooled
-
Gradeability:
-
30°
-
Transmission Type:
-
Hydraulic, Automatic
-
Working Pressure:
-
20 MPa
-
Backhoe Bucket Capacity:
-
0.1 cbm, 0.15 cbm, 0.2 cbm, 0.3 cbm
-
After Warranty Service:
-
Video technical support
|
Model
|
WZ10-20
|
WZ15-26
|
WZ20-28
|
WZ25-30
|
||||
|
Dimensions
|
5500*1720*2650 mm
|
5800*1850*2750 mm
|
6200*1960*2800 mm
|
6800*2040*2850 mm
|
||||
|
Operating Weight
|
3,400 kg
|
4,800 kg
|
5,400 kg
|
6,000 kg
|
||||
|
Travel Speed
|
0 - 26 km/h
|
0 - 26 km/h
|
0 - 30 km/h
|
0 - 30 km/h
|
||||
|
Gradeability
|
30°
|
30°
|
30°
|
30°
|
||||
|
Wheel Drive
|
4 x 4
|
4 x 4
|
4 x 4
|
4 x 4
|
||||
|
Min. Turning Radius
|
3,500 mm
|
4,000 mm
|
4,500 mm
|
4,500 mm
|
||||
|
Working Pressure
|
20 MPa
|
20 MPa
|
20 MPa
|
20 MPa
|
||||
|
Wheel Tread
|
1,630 mm
|
1,550 mm
|
1,630 mm
|
1,630 mm
|
||||
|
Wheel Base
|
2,670 mm
|
2,150 mm
|
2,670 mm
|
2,670 mm
|
||||
|
Tire
|
4 * 20.5-16
|
4 * 23.5-16
|
4 * 16/70 - 20
|
4 * 16/70 - 20
|
||||
|
Tire Pressure
|
250 KPa
|
250 KPa
|
250 KPa
|
250 KPa
|
||||
|
Transmission Type
|
Hydraulic, Automatic
|
Hydraulic, Automatic
|
Hydraulic, Automatic
|
Hydraulic, Automatic
|
||||
|
Braking System
|
Hydraulic
|
Air Assist
|
Air Assist
|
Air Assist
|
||||
|
Engine
|
|
|
|
|
||||
|
Brand & Model
|
YUNNEI 25GB
|
YUNNEI 490
|
YUNNEI 4102
|
YUNNEI 4108
|
||||
|
Power
|
37 kw (50 hp)
|
58 kw (79 hp)
|
76 kw (104 hp)
|
92 kw (125 hp)
|
||||
|
Type
|
Diesel, 4-cylinder, 4-stroke, Water-cooled
|
|
|
|
||||
|
Loader Performance
|
|
|
|
|
||||
|
Rated Load
|
1,500 kg
|
2,000 kg
|
2,500 kg
|
3,000 kg
|
||||
|
Capacity
|
0.75 m³
|
1.0 m³
|
1.25 m³
|
1.5 m³
|
||||
|
Bucket Width
|
1,800 mm
|
1,900 mm
|
2,000 mm
|
2,200 mm
|
||||
|
Max. Dump Height
|
2,800 mm
|
3,300 mm
|
3,500 mm
|
3,500 mm
|
||||
|
Max. Dump Distance
|
800 mm
|
900 mm
|
900 mm
|
900 mm
|
||||
|
Max. Lift Force
|
36 kn (3,672 kg)
|
36 kn (3,672 kg)
|
42 kn (4,284 kg)
|
42 kn (4,284 kg)
|
||||
|
Actuation Time
|
12 s
|
12 s
|
12 s
|
12 s
|
||||
|
Backhoe Performance
|
|
|
|
|
||||
|
Capacity
|
0.1 m³
|
0.15 m³
|
0.2 m³
|
0.3 m³
|
||||
|
Bucket Width
|
400 mm
|
500 mm
|
550 mm
|
600 mm
|
||||
|
Max. Dig Depth
|
2,000 mm
|
2,700 mm
|
2,600 mm
|
2,600 mm
|
||||
|
Max. Dig Height
|
3,300 mm
|
4,200 mm
|
4,300 mm
|
4,400 mm
|
||||
|
Max. Dig Radius
|
2,900 mm
|
4,600 mm
|
4,600 mm
|
4,600 mm
|
||||
|
Max. Dump Height
|
1,850 mm
|
2,200 mm
|
2,300 mm
|
2,300 mm
|
||||
|
Max. Dig Force
|
25 kn (2,550 kg)
|
28 kn (2,856 kg)
|
28 kn (2,856 kg)
|
28 kn (2,856 kg)
|
||||
