- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
30years
-
Brand Name:
-
LONGi
-
Model Number:
-
himo6,himo 5
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
182*182mm, 210*210mm
-
Product name:
-
Monocrystalline Solar Panel,Pv Module
-
Frame:
-
Anodized Aluminum Alloy Frame
-
Junction Box:
-
IP68, three diodes
-
Customized::
-
Accptable
-
Operating Temperature(℃):
-
-40℃~+85℃
-
Maximum system voltage:
-
1500V DC
-
Application:
-
Outdoors
-
Front Cover:
-
3.2 mm Tempered Glass,3.2mm High transmission, low Iron
-
Keyword:
-
Solar Panel Pv Module
-
Cell Type:
-
N type Mono-crystalline,96cells
-
Certificate:
-
TUV/CE/CQC/PV CYCLE
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, Bifacial, Double-glass, All Black, MWT, IBC, HJT, hbc, N-TYPE, TOPCON, BIPV
-
Panel Efficiency:
-
21.5%,22.5%,24%
-
Warranty:
-
30years
-
Brand Name:
-
LONGi
-
Model Number:
-
himo6,himo 5
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
182*182mm, 210*210mm
-
Product name:
-
Monocrystalline Solar Panel,Pv Module
-
Frame:
-
Anodized Aluminum Alloy Frame
-
Junction Box:
-
IP68, three diodes
-
Customized::
-
Accptable
-
Operating Temperature(℃):
-
-40℃~+85℃
-
Maximum system voltage:
-
1500V DC
-
Application:
-
Outdoors
-
Front Cover:
-
3.2 mm Tempered Glass,3.2mm High transmission, low Iron
-
Keyword:
-
Solar Panel Pv Module
-
Cell Type:
-
N type Mono-crystalline,96cells
-
Certificate:
-
TUV/CE/CQC/PV CYCLE
|
Longi solar panels 530 watt to 550watt Electrical Parameters at STC
|
|
|
|
|
|
|||||
|
Rated Maximum Power(Pmax) [W]
|
LR5-72HPH 530M
|
LR5-72HPH 535M
|
LR5-72HPH 540M
|
LR5-72HPH 545M
|
LR5-72HPH 550M
|
|||||
|
Maximum Power Voltage (Vmp) [V]
|
41.50
|
41.65
|
41.80
|
41.95
|
42.10
|
|||||
|
Maximum Power Current (Imp) [V]
|
12.90
|
12.97
|
13.04
|
13.12
|
13.19
|
|||||
|
Open-circuit Voltage (Voc) [A]
|
49.35
|
49.50
|
49.65
|
49.80
|
49.95
|
|||||
|
Short-circuit Current (Isc) [A]
|
13.78
|
13.85
|
13.92
|
13.98
|
14.04
|
|||||
|
Module Efficiency [%]
|
20.9
|
21.1
|
21.3
|
21.5
|
21.7
|
|||||
|
Power Tolerance
|
0~+5W
|
|
|
|
|
|||||
|
Temperature Coefficient of Isc
|
+0.050%/°C
|
|
|
|
|
|||||
|
Temperature Coefficient of Voc
|
-0.265%/°C
|
|
|
|
|
|||||
|
Temperature Coefficient of Pmax
|
-0.340/°C
|
|
|
|
|
|||||
|
STC
|
Irradiance 1000W/m2, cell temperature 25°C, AM1.5
|
|
|
|
|
|||||
